Shaft Diameter (Ds)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip ID (A)	Radial Wall (S) min/max	Groove Width (W)	Indicative Image
Shaft Diameter (Ds) 7.14 mm (Equiv. 0.281 in.)	Clip Thickness (T) 0.56 mm (Equiv. 0.022 in.)	Groove Dia. (Dg) 6.58 mm (Equiv. 0.259 in.)	Approx. Loose Circlip ID (A) 6.38 mm	Radial Wall (S) min/max 6.58 mm + 0.08 / - 0.00	Groove Width (W) 0.58 mm + 0.08 / - 0.00
Material: Carbon Spring Steel Free Outside Dia (Dr): 7.5 Section Profile: Round Section
Part Number: WRE-0071-RD External Retaining Rings - 7.14x0.56x6.58 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip ID (A)	Indicative Image
Shaft Diameter (Ds) 7.14 mm (Equiv. 0.281 in.)	Clip Thickness (T) 0.56 mm (Equiv. 0.022 in.)	Groove Dia. (Dg) 6.58 mm (Equiv. 0.259 in.)	Approx. Loose Circlip ID (A) 6.38 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 6.58 mm + 0.08 / - 0.00 Groove Width (W): 0.58 mm + 0.08 / - 0.00 Free Outside Dia (Dr): 7.5 Section Profile: Round Section
Part Number: WRE-0071-RD External Retaining Rings - 7.14x0.56x6.58 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.14 mm (Equiv. 0.281 in.)	Clip Thickness (T) 0.74 mm _{+/- 0.10} (Equiv. 0.029 in.)	Groove Dia. (Dg) 6.68 mm _{+ 0.08 / - 0.00} (Equiv. 0.263 in.)	Approx. Loose Circlip ID (A) 6.60 mm	Radial Wall (S) min/max 6.68 mm	Groove Width (W) 0.79 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 8.08 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0071-RD-C (50 Pcs) External Retaining Rings - 7.14x0.74x6.68 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.14 mm (Equiv. 0.281 in.)	Clip Thickness (T) 0.74 mm _{+/- 0.10} (Equiv. 0.029 in.)	Groove Dia. (Dg) 6.68 mm _{+ 0.08 / - 0.00} (Equiv. 0.263 in.)	Approx. Loose Circlip ID (A) 6.60 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 6.68 mm Groove Width (W): 0.79 mm Free Outside Dia (Dr): 8.08 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0071-RD-C (50 Pcs) External Retaining Rings - 7.14x0.74x6.68 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.14 mm (Equiv. 0.281 in.)	Clip Thickness (T) 0.74 mm _{+/- 0.10} (Equiv. 0.029 in.)	Groove Dia. (Dg) 6.68 mm _{+ 0.08 / - 0.00} (Equiv. 0.263 in.)	Approx. Loose Circlip ID (A) 6.60 mm	Radial Wall (S) min/max 6.68 mm	Groove Width (W) 0.79 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 8.08 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0071-RD-O External Retaining Rings - 7.14x0.74x6.68 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.14 mm (Equiv. 0.281 in.)	Clip Thickness (T) 0.74 mm _{+/- 0.10} (Equiv. 0.029 in.)	Groove Dia. (Dg) 6.68 mm _{+ 0.08 / - 0.00} (Equiv. 0.263 in.)	Approx. Loose Circlip ID (A) 6.60 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 6.68 mm Groove Width (W): 0.79 mm Free Outside Dia (Dr): 8.08 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0071-RD-O External Retaining Rings - 7.14x0.74x6.68 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.56 mm (Equiv. 0.022 in.)	Groove Dia. (Dg) 7.37 mm (Equiv. 0.29 in.)	Approx. Loose Circlip ID (A) 7.14 mm	Radial Wall (S) min/max 7.37 mm + 0.08 / - 0.00	Groove Width (W) 0.58 mm + 0.08 / - 0.00
Material: Carbon Spring Steel Free Outside Dia (Dr): 8.26 Section Profile: Round Section
Part Number: WRE-0079-RD External Retaining Rings - 7.93x0.56x7.37 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.56 mm (Equiv. 0.022 in.)	Groove Dia. (Dg) 7.37 mm (Equiv. 0.29 in.)	Approx. Loose Circlip ID (A) 7.14 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 7.37 mm + 0.08 / - 0.00 Groove Width (W): 0.58 mm + 0.08 / - 0.00 Free Outside Dia (Dr): 8.26 Section Profile: Round Section
Part Number: WRE-0079-RD External Retaining Rings - 7.93x0.56x7.37 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.56 mm _{+/- 0.10} (Equiv. 0.022 in.)	Groove Dia. (Dg) 7.57 mm _{+ 0.08 / - 0.00} (Equiv. 0.298 in.)	Approx. Loose Circlip ID (A) 7.52 mm	Radial Wall (S) min/max 7.57 mm	Groove Width (W) 0.61 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 8.64 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0079-RD-O External Retaining Rings - 7.93x0.56x7.57 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.56 mm _{+/- 0.10} (Equiv. 0.022 in.)	Groove Dia. (Dg) 7.57 mm _{+ 0.08 / - 0.00} (Equiv. 0.298 in.)	Approx. Loose Circlip ID (A) 7.52 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 7.57 mm Groove Width (W): 0.61 mm Free Outside Dia (Dr): 8.64 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0079-RD-O External Retaining Rings - 7.93x0.56x7.57 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.56 mm _{+/- 0.10} (Equiv. 0.022 in.)	Groove Dia. (Dg) 7.57 mm _{+ 0.08 / - 0.00} (Equiv. 0.298 in.)	Approx. Loose Circlip ID (A) 7.52 mm	Radial Wall (S) min/max 7.57 mm	Groove Width (W) 0.61 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 8.64 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0079-RD-C External Retaining Rings - 7.93x0.56x7.57 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.56 mm _{+/- 0.10} (Equiv. 0.022 in.)	Groove Dia. (Dg) 7.57 mm _{+ 0.08 / - 0.00} (Equiv. 0.298 in.)	Approx. Loose Circlip ID (A) 7.52 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 7.57 mm Groove Width (W): 0.61 mm Free Outside Dia (Dr): 8.64 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0079-RD-C External Retaining Rings - 7.93x0.56x7.57 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 7.37 mm _{+ 0.08 / - 0.00} (Equiv. 0.29 in.)	Approx. Loose Circlip ID (A) 7.32 mm	Radial Wall (S) min/max 7.37 mm	Groove Width (W) 0.94 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 9.1 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0079-RD-HO External Retaining Rings - 7.93x0.89x7.37 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 7.37 mm _{+ 0.08 / - 0.00} (Equiv. 0.29 in.)	Approx. Loose Circlip ID (A) 7.32 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 7.37 mm Groove Width (W): 0.94 mm Free Outside Dia (Dr): 9.1 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0079-RD-HO External Retaining Rings - 7.93x0.89x7.37 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 7.37 mm _{+ 0.08 / - 0.00} (Equiv. 0.29 in.)	Approx. Loose Circlip ID (A) 7.32 mm	Radial Wall (S) min/max 7.37 mm	Groove Width (W) 0.94 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 9.1 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0079-RD-HC External Retaining Rings - 7.93x0.89x7.37 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 7.93 mm (Equiv. 0.312 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 7.37 mm _{+ 0.08 / - 0.00} (Equiv. 0.29 in.)	Approx. Loose Circlip ID (A) 7.32 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 7.37 mm Groove Width (W): 0.94 mm Free Outside Dia (Dr): 9.1 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0079-RD-HC External Retaining Rings - 7.93x0.89x7.37 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 8.00 mm (Equiv. 0.315 in.)	Clip Thickness (T) 0.80 mm (Equiv. 0.031 in.)	Groove Dia. (Dg) 7.2 mm _{+ 0 / - 0.30} (Equiv. 0.283 in.)	Approx. Loose Circlip ID (A) 7.1 mm	Radial Wall (S) min/max 7.2 mm +/- 0.05	Groove Width (W) 1.0 mm Min.
Material: Carbon Spring Steel Free Outside Dia (Dr): 8.7 Section Profile: Round Section
Part Number: WRE-0080-RD (100 Pcs) External Retaining Rings - 8x0.8x7.2 mm Round Wire - Carbon Spring Steel Circlip 6 units (600 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $13.05 AUD Regular price Sale price $13.05 AUD Unit price per Per 100 Quantity Required 6 units (600 pcs) Available Now. Backorder if more than 6.
Shaft Diameter (Ds) 8.00 mm (Equiv. 0.315 in.)	Clip Thickness (T) 0.80 mm (Equiv. 0.031 in.)	Groove Dia. (Dg) 7.2 mm _{+ 0 / - 0.30} (Equiv. 0.283 in.)	Approx. Loose Circlip ID (A) 7.1 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 7.2 mm +/- 0.05 Groove Width (W): 1.0 mm Min. Free Outside Dia (Dr): 8.7 Section Profile: Round Section
Part Number: WRE-0080-RD (100 Pcs) External Retaining Rings - 8x0.8x7.2 mm Round Wire - Carbon Spring Steel Circlip 6 units (600 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $13.05 AUD Regular price Sale price $13.05 AUD Unit price per Per 100 Quantity Required 6 units (600 pcs) Available Now. Backorder if more than 6.
WRE-0080-RD (100 Pcs) --- External Retaining Rings - 8x0.8x7.2 mm Round Wire - Carbon Spring Steel Circlip WRE-0080-RD (100 Pcs) --- External Retaining Rings - 8x0.8x7.2 mm Round Wire - Carbon Spring Steel Circlip Regular price $13.05 AUD Regular price Sale price $13.05 AUD Unit price per 6 Available Now
Shaft Diameter (Ds) 8.74 mm (Equiv. 0.344 in.)	Clip Thickness (T) 0.56 mm (Equiv. 0.022 in.)	Groove Dia. (Dg) 8.18 mm (Equiv. 0.322 in.)	Approx. Loose Circlip ID (A) 7.93 mm	Radial Wall (S) min/max 8.18 mm + 0.08 / - 0.00	Groove Width (W) 0.58 mm + 0.08 / - 0.00
Material: Carbon Spring Steel Free Outside Dia (Dr): 9.05 Section Profile: Round Section
Part Number: WRE-0087-RD External Retaining Rings - 8.74x0.56x8.18 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 8.74 mm (Equiv. 0.344 in.)	Clip Thickness (T) 0.56 mm (Equiv. 0.022 in.)	Groove Dia. (Dg) 8.18 mm (Equiv. 0.322 in.)	Approx. Loose Circlip ID (A) 7.93 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 8.18 mm + 0.08 / - 0.00 Groove Width (W): 0.58 mm + 0.08 / - 0.00 Free Outside Dia (Dr): 9.05 Section Profile: Round Section
Part Number: WRE-0087-RD External Retaining Rings - 8.74x0.56x8.18 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 0.74 mm _{+/- 0.10} (Equiv. 0.029 in.)	Groove Dia. (Dg) 9.07 mm _{+ 0.08 / - 0.00} (Equiv. 0.357 in.)	Approx. Loose Circlip ID (A) 8.97 mm	Radial Wall (S) min/max 9.07 mm	Groove Width (W) 0.79 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 10.45 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0095-RD-O External Retaining Rings - 9.53x0.74x9.07 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 0.74 mm _{+/- 0.10} (Equiv. 0.029 in.)	Groove Dia. (Dg) 9.07 mm _{+ 0.08 / - 0.00} (Equiv. 0.357 in.)	Approx. Loose Circlip ID (A) 8.97 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 9.07 mm Groove Width (W): 0.79 mm Free Outside Dia (Dr): 10.45 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0095-RD-O External Retaining Rings - 9.53x0.74x9.07 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 8.61 mm (Equiv. 0.339 in.)	Approx. Loose Circlip ID (A) 8.36 mm	Radial Wall (S) min/max 8.61 mm + 0.08 / - 0.00	Groove Width (W) 0.97 mm + 0.08 / - 0.00
Material: Carbon Spring Steel Free Outside Dia (Dr): 10.18 Section Profile: Round Section
Part Number: WRE-0095-RD External Retaining Rings - 9.53x0.91x8.61 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 8.61 mm (Equiv. 0.339 in.)	Approx. Loose Circlip ID (A) 8.36 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 8.61 mm + 0.08 / - 0.00 Groove Width (W): 0.97 mm + 0.08 / - 0.00 Free Outside Dia (Dr): 10.18 Section Profile: Round Section
Part Number: WRE-0095-RD External Retaining Rings - 9.53x0.91x8.61 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 1.09 mm _{+/- 0.10} (Equiv. 0.043 in.)	Groove Dia. (Dg) 8.87 mm _{+ 0.08 / - 0.00} (Equiv. 0.349 in.)	Approx. Loose Circlip ID (A) 8.76 mm	Radial Wall (S) min/max 8.87 mm	Groove Width (W) 1.14 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 10.94 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0095-RD-HC External Retaining Rings - 9.53x1.09x8.87 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 1.09 mm _{+/- 0.10} (Equiv. 0.043 in.)	Groove Dia. (Dg) 8.87 mm _{+ 0.08 / - 0.00} (Equiv. 0.349 in.)	Approx. Loose Circlip ID (A) 8.76 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 8.87 mm Groove Width (W): 1.14 mm Free Outside Dia (Dr): 10.94 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0095-RD-HC External Retaining Rings - 9.53x1.09x8.87 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 1.09 mm _{+/- 0.10} (Equiv. 0.043 in.)	Groove Dia. (Dg) 8.87 mm _{+ 0.08 / - 0.00} (Equiv. 0.349 in.)	Approx. Loose Circlip ID (A) 8.76 mm	Radial Wall (S) min/max 8.87 mm	Groove Width (W) 1.14 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 10.94 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0095-RD-HO (3 Pcs) External Retaining Rings - 9.53x1.09x8.87 mm Round Wire - Carbon Spring Steel 3 units (9 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $15.95 AUD Regular price Sale price $15.95 AUD Unit price per Per 3 Quantity Required 3 units (9 pcs) Available Now. Backorder if more than 3.
Shaft Diameter (Ds) 9.53 mm (Equiv. 0.375 in.)	Clip Thickness (T) 1.09 mm _{+/- 0.10} (Equiv. 0.043 in.)	Groove Dia. (Dg) 8.87 mm _{+ 0.08 / - 0.00} (Equiv. 0.349 in.)	Approx. Loose Circlip ID (A) 8.76 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 8.87 mm Groove Width (W): 1.14 mm Free Outside Dia (Dr): 10.94 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0095-RD-HO (3 Pcs) External Retaining Rings - 9.53x1.09x8.87 mm Round Wire - Carbon Spring Steel 3 units (9 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $15.95 AUD Regular price Sale price $15.95 AUD Unit price per Per 3 Quantity Required 3 units (9 pcs) Available Now. Backorder if more than 3.
WRE-0095-RD-HO (3 Pcs) --- External Retaining Rings - 9.53x1.09x8.87 mm Round Wire - Carbon Spring Steel WRE-0095-RD-HO (3 Pcs) --- External Retaining Rings - 9.53x1.09x8.87 mm Round Wire - Carbon Spring Steel Regular price $15.95 AUD Regular price Sale price $15.95 AUD Unit price per 3 Available Now
Shaft Diameter (Ds) 10.00 mm (Equiv. 0.394 in.)	Clip Thickness (T) 0.80 mm (Equiv. 0.031 in.)	Groove Dia. (Dg) 9.2 mm _{+ 0 / - 0.30} (Equiv. 0.362 in.)	Approx. Loose Circlip ID (A) 9.1 mm	Radial Wall (S) min/max 9.2 mm +/- 0.05	Groove Width (W) 1.0 mm Min.
Material: Carbon Spring Steel Free Outside Dia (Dr): 10.7 Section Profile: Round Section
Part Number: WRE-0100-RD (10 Pcs) External Retaining Rings - 10x0.8x9.2 mm Round Wire - Carbon Spring Steel Circlip 501 units (5010 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $6.86 AUD Regular price Sale price $6.86 AUD Unit price per Per 10 Quantity Required 501 units (5010 pcs) Available Now. Backorder if more than 501.
Shaft Diameter (Ds) 10.00 mm (Equiv. 0.394 in.)	Clip Thickness (T) 0.80 mm (Equiv. 0.031 in.)	Groove Dia. (Dg) 9.2 mm _{+ 0 / - 0.30} (Equiv. 0.362 in.)	Approx. Loose Circlip ID (A) 9.1 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 9.2 mm +/- 0.05 Groove Width (W): 1.0 mm Min. Free Outside Dia (Dr): 10.7 Section Profile: Round Section
Part Number: WRE-0100-RD (10 Pcs) External Retaining Rings - 10x0.8x9.2 mm Round Wire - Carbon Spring Steel Circlip 501 units (5010 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $6.86 AUD Regular price Sale price $6.86 AUD Unit price per Per 10 Quantity Required 501 units (5010 pcs) Available Now. Backorder if more than 501.
WRE-0100-RD (10 Pcs) --- External Retaining Rings - 10x0.8x9.2 mm Round Wire - Carbon Spring Steel Circlip WRE-0100-RD (10 Pcs) --- External Retaining Rings - 10x0.8x9.2 mm Round Wire - Carbon Spring Steel Circlip Regular price $6.86 AUD Regular price Sale price $6.86 AUD Unit price per 501 Available Now
Shaft Diameter (Ds) 10.31 mm (Equiv. 0.406 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 9.40 mm (Equiv. 0.37 in.)	Approx. Loose Circlip ID (A) 9.12 mm	Radial Wall (S) min/max 9.40 mm + 0.08 / - 0.00	Groove Width (W) 0.97 mm + 0.08 / - 0.00
Material: Carbon Spring Steel Free Outside Dia (Dr): 10.94 Section Profile: Round Section
Part Number: WRE-0103-RD External Retaining Rings - 10.31x0.91x9.4 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 10.31 mm (Equiv. 0.406 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 9.40 mm (Equiv. 0.37 in.)	Approx. Loose Circlip ID (A) 9.12 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 9.40 mm + 0.08 / - 0.00 Groove Width (W): 0.97 mm + 0.08 / - 0.00 Free Outside Dia (Dr): 10.94 Section Profile: Round Section
Part Number: WRE-0103-RD External Retaining Rings - 10.31x0.91x9.4 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 10.54 mm _{+ 0.08 / - 0.00} (Equiv. 0.415 in.)	Approx. Loose Circlip ID (A) 10.47 mm	Radial Wall (S) min/max 10.54 mm	Groove Width (W) 0.94 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 12.25 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0111-RD-C External Retaining Rings - 11.13x0.89x10.54 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 10.54 mm _{+ 0.08 / - 0.00} (Equiv. 0.415 in.)	Approx. Loose Circlip ID (A) 10.47 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 10.54 mm Groove Width (W): 0.94 mm Free Outside Dia (Dr): 12.25 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0111-RD-C External Retaining Rings - 11.13x0.89x10.54 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 10.21 mm (Equiv. 0.402 in.)	Approx. Loose Circlip ID (A) 9.91 mm	Radial Wall (S) min/max 10.21 mm + 0.08 / - 0.00	Groove Width (W) 0.97 mm + 0.08 / - 0.00
Material: Carbon Spring Steel Free Outside Dia (Dr): 11.73 Section Profile: Round Section
Part Number: WRE-0111-RD External Retaining Rings - 11.13x0.91x10.21 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 10.21 mm (Equiv. 0.402 in.)	Approx. Loose Circlip ID (A) 9.91 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 10.21 mm + 0.08 / - 0.00 Groove Width (W): 0.97 mm + 0.08 / - 0.00 Free Outside Dia (Dr): 11.73 Section Profile: Round Section
Part Number: WRE-0111-RD External Retaining Rings - 11.13x0.91x10.21 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 10.54 mm _{+ 0.08 / - 0.00} (Equiv. 0.415 in.)	Approx. Loose Circlip ID (A) 10.47 mm	Radial Wall (S) min/max 10.54 mm	Groove Width (W) 0.94 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 12.25 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0111-RD-O External Retaining Rings - 11.13x0.89x10.54 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 0.89 mm _{+/- 0.10} (Equiv. 0.035 in.)	Groove Dia. (Dg) 10.54 mm _{+ 0.08 / - 0.00} (Equiv. 0.415 in.)	Approx. Loose Circlip ID (A) 10.47 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 10.54 mm Groove Width (W): 0.94 mm Free Outside Dia (Dr): 12.25 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0111-RD-O External Retaining Rings - 11.13x0.89x10.54 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 1.30 mm _{+/- 0.06} (Equiv. 0.051 in.)	Groove Dia. (Dg) 10.29 mm _{+ 0.08 / - 0.00} (Equiv. 0.405 in.)	Approx. Loose Circlip ID (A) 10.21 mm	Radial Wall (S) min/max 10.29 mm	Groove Width (W) 1.35 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 12.81 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0111-RD-HC External Retaining Rings - 11.13x1.3x10.29 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 1.30 mm _{+/- 0.06} (Equiv. 0.051 in.)	Groove Dia. (Dg) 10.29 mm _{+ 0.08 / - 0.00} (Equiv. 0.405 in.)	Approx. Loose Circlip ID (A) 10.21 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 10.29 mm Groove Width (W): 1.35 mm Free Outside Dia (Dr): 12.81 Section Profile: Round Section Info: Axial Assembly - Closed Gap
Part Number: WRE-0111-RD-HC External Retaining Rings - 11.13x1.3x10.29 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 1.30 mm _{+/- 0.06} (Equiv. 0.051 in.)	Groove Dia. (Dg) 10.29 mm _{+ 0.08 / - 0.00} (Equiv. 0.405 in.)	Approx. Loose Circlip ID (A) 10.21 mm	Radial Wall (S) min/max 10.29 mm	Groove Width (W) 1.35 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 12.81 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0111-RD-HO External Retaining Rings - 11.13x1.3x10.29 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.13 mm (Equiv. 0.438 in.)	Clip Thickness (T) 1.30 mm _{+/- 0.06} (Equiv. 0.051 in.)	Groove Dia. (Dg) 10.29 mm _{+ 0.08 / - 0.00} (Equiv. 0.405 in.)	Approx. Loose Circlip ID (A) 10.21 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 10.29 mm Groove Width (W): 1.35 mm Free Outside Dia (Dr): 12.81 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0111-RD-HO External Retaining Rings - 11.13x1.3x10.29 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.91 mm (Equiv. 0.469 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 11.00 mm (Equiv. 0.433 in.)	Approx. Loose Circlip ID (A) 10.67 mm	Radial Wall (S) min/max 11.00 mm + 0.08 / - 0.00	Groove Width (W) 0.97 mm + 0.08 / - 0.00
Material: Carbon Spring Steel Free Outside Dia (Dr): 12.49 Section Profile: Round Section
Part Number: WRE-0119-RD External Retaining Rings - 11.91x0.91x11 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 11.91 mm (Equiv. 0.469 in.)	Clip Thickness (T) 0.91 mm (Equiv. 0.036 in.)	Groove Dia. (Dg) 11.00 mm (Equiv. 0.433 in.)	Approx. Loose Circlip ID (A) 10.67 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 11.00 mm + 0.08 / - 0.00 Groove Width (W): 0.97 mm + 0.08 / - 0.00 Free Outside Dia (Dr): 12.49 Section Profile: Round Section
Part Number: WRE-0119-RD External Retaining Rings - 11.91x0.91x11 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 12.00 mm (Equiv. 0.472 in.)	Clip Thickness (T) 1.00 mm (Equiv. 0.039 in.)	Groove Dia. (Dg) 11.0 mm _{+ 0 / - 0.40} (Equiv. 0.433 in.)	Approx. Loose Circlip ID (A) 10.8 mm	Radial Wall (S) min/max 11.0 mm +/- 0.05	Groove Width (W) 1.2 mm Min.
Material: Carbon Spring Steel Free Outside Dia (Dr): 12.8 Section Profile: Round Section
Part Number: WRE-0120-RD (50 Pcs) External Retaining Rings - 12x1x11 mm Round Wire - Carbon Spring Steel Circlip 8 units (400 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Per 50 Quantity Required 8 units (400 pcs) Available Now. Backorder if more than 8.
Shaft Diameter (Ds) 12.00 mm (Equiv. 0.472 in.)	Clip Thickness (T) 1.00 mm (Equiv. 0.039 in.)	Groove Dia. (Dg) 11.0 mm _{+ 0 / - 0.40} (Equiv. 0.433 in.)	Approx. Loose Circlip ID (A) 10.8 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 11.0 mm +/- 0.05 Groove Width (W): 1.2 mm Min. Free Outside Dia (Dr): 12.8 Section Profile: Round Section
Part Number: WRE-0120-RD (50 Pcs) External Retaining Rings - 12x1x11 mm Round Wire - Carbon Spring Steel Circlip 8 units (400 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Per 50 Quantity Required 8 units (400 pcs) Available Now. Backorder if more than 8.
WRE-0120-RD (50 Pcs) --- External Retaining Rings - 12x1x11 mm Round Wire - Carbon Spring Steel Circlip WRE-0120-RD (50 Pcs) --- External Retaining Rings - 12x1x11 mm Round Wire - Carbon Spring Steel Circlip Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per 8 Available Now
Shaft Diameter (Ds) 12.70 mm (Equiv. 0.5 in.)	Clip Thickness (T) 1.09 mm _{+/- 0.06} (Equiv. 0.043 in.)	Groove Dia. (Dg) 12.04 mm _{+ 0.08 / - 0.00} (Equiv. 0.474 in.)	Approx. Loose Circlip ID (A) 11.89 mm	Radial Wall (S) min/max 12.04 mm	Groove Width (W) 1.14 mm
Material: Carbon Spring Steel Free Outside Dia (Dr): 14.07 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0127-RD-O External Retaining Rings - 12.7x1.09x12.04 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Shaft Diameter (Ds) 12.70 mm (Equiv. 0.5 in.)	Clip Thickness (T) 1.09 mm _{+/- 0.06} (Equiv. 0.043 in.)	Groove Dia. (Dg) 12.04 mm _{+ 0.08 / - 0.00} (Equiv. 0.474 in.)	Approx. Loose Circlip ID (A) 11.89 mm
Material: Carbon Spring Steel Radial Wall (S) min/max: 12.04 mm Groove Width (W): 1.14 mm Free Outside Dia (Dr): 14.07 Section Profile: Round Section Info: Radial Assembly - Open Gap
Part Number: WRE-0127-RD-O External Retaining Rings - 12.7x1.09x12.04 mm Round Wire - Carbon Spring Steel Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
