PDBS040-0439-S (PK-2)
Posi-Drive Belts - 438.9 mm - 4.6 kg - 183 4.00 mm Circular Pitch Single Core - Molded Polyurethane / Stainless Steel Belt
MBA
Store: Minibearings - Miniature Bearings Australia - Online, Pick-Up, Retail, Distributors, WholesaleCouldn't load pickup availability
438.9 mm - 4.6 kg - 183 Posi-Drive Belts - Molded Polyurethane / Stainless Steel - Sold per pack of 2:
Base Category: Belts - Posi-Drive
Top Level Category: Belts - Posi-Drive - 4.00 mm Circular Pitch Single Core
Product Details
Deleted Item. Available while stocks last.
Pitch Length: 438.9mm
(438.9mm is 17.28 in.)
Molded Polyurethane / Stainless Steel
- Pitch Length: 438.9mm
(438.9mm is 17.28 in.)
- Max Tension: 4.6kg
- Max Speed Loaded (Mtr/Min): 183
- Min. Teeth in Mesh: 6
- Min. Pulley Diameter: 19.1mm
- Belt Type: Single Core
- Teeth: 110
- Max Speed Unloaded (Mtr/Min): 335
Brand: MBA
Country of Origin: US
Please contact us if you would like a price and delivery for a larger quantity than the available stock.
Product Compliance and Data
Similar to
- S7913YM20SS110
We offer equivalents to many brands including Anderton, Barden, Berg, Designatronics, EZO, ISC, Koyo, Myonic, NMB, Nordex, NSK, Ondrives, Reid Industrial, RMB, SDP-SI, Seeger, SKF, and more.
PDBS0400439S, PDBS0400439
