Gears - Spur - Standard - Module 0.7 Plastic

Gears -> Spur -> Standard -> Module 0.7 Plastic

There is only 1 product in the sub-categories of Gears - Spur - Standard - Module 0.7 Plastic. Browse the Gears - Spur - Standard - Module 0.7 Plastic products table.

Category Details

A selection of Module 0.7 Plastic Standard Spur Gears. PCD in mm = No. of Teeth x 0.7. 20 Degree Pressure Angle.

  • The diameter increases by 0.7mm per tooth
  • Module 0.7. Approximately 2.19mm between the teeth.

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Gears - Spur - Standard - Module 0.7 Plastic category on the Small Parts & Bearings online store.
Number of Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Face Width (FW) Type Indicative
Number of Teeth
17

Pitch Circle Diameter (PD)
11.90
mm

(Equiv. 0.469 in.)
Bore (d)
4.000
mm

(Equiv. 0.157 in.)
Outside Diameter (OD)
13.300
mm
Face Width (FW)
6.000
mm
Type
Hubbed
Spur Gears - 17 tooth - 11.9x4 mm Hubbed - Acetal - No Insert Gear
Material: Acetal - No Insert    Hub Diameter (D1): 9.00 mm    Hub Projection (HL): 9.00 mm    Locking Method: None    Quality: Commercial - Molded
Part Number: G012B-017-M07-060-040-A-P (2 Pcs)
Spur Gears - 17 tooth - 11.9x4 mm Hubbed - Acetal - No Insert Gear
5 units (10 pcs) Available Now | Item Discontinued - Up to 5 may be ordered online. No backorders. Please contact us if you need a larger quantity
$8.00 AUD
$15.20 AUD $8.00 AUD
Per 2
Quantity Required

5 units (10 pcs) Available Now. These are priced to quit. Please contact us for a quote if you require more.
Number of Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Indicative
Number of Teeth
17

Pitch Circle Diameter (PD)
11.90
mm

(Equiv. 0.469 in.)
Bore (d)
4.000
mm

(Equiv. 0.157 in.)
Outside Diameter (OD)
13.300
mm
Spur Gears - 17 tooth - 11.9x4 mm Hubbed - Acetal - No Insert Gear
Material: Acetal - No Insert    Face Width (FW): 6.000 mm    Type: Hubbed    Hub Diameter (D1): 9.00 mm    Hub Projection (HL): 9.00 mm    Locking Method: None    Quality: Commercial - Molded
Part Number: G012B-017-M07-060-040-A-P (2 Pcs)
Spur Gears - 17 tooth - 11.9x4 mm Hubbed - Acetal - No Insert Gear
5 units (10 pcs) Available Now | Item Discontinued - Up to 5 may be ordered online. No backorders. Please contact us if you need a larger quantity
$8.00 AUD
$15.20 AUD $8.00 AUD
Per 2
Quantity Required

5 units (10 pcs) Available Now. These are priced to quit. Please contact us for a quote if you require more.
