Gears - Spur - Standard - 24DP - 14.5 Degree - Brass

Gears -> Spur -> Standard -> 24DP -> 14.5 Degree -> Brass

There are 2 products in the sub-categories of Gears - Spur - Standard - 24DP - 14.5 Degree - Brass. Browse the Gears - Spur - Standard - 24DP - 14.5 Degree - Brass products table.

Category Details

A selection of Brass 14.5 Degree 24DP Standard Spur Gears. PCD in mm = No. of Teeth x 1.05833 (1/24 in.). 14.5 Degree Pressure Angle. DP stands for Diametrical Pitch and is an imperial measurement system.

  • The diameter increases by 1 inch for every 24 teeth
  • 24 Diametrical Pitch. Approx 3.33mm between the teeth.

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Gears - Spur - Standard - 24DP - 14.5 Degree - Brass category on the Small Parts & Bearings online store.
Number of Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Face Width (FW) Type Indicative
Number of Teeth
18

Pitch Circle Diameter (PD)
19.05
mm

(Equiv. 0.75 in.)
Bore (d)
4.762
mm

(Equiv. 0.187 in.)
Outside Diameter (OD)
21.158
mm
Face Width (FW)
6.35
mm
Type
Hubbed
Spur Gears - 18 tooth - 19.05x4.762 mm Hubbed - Brass Gear
Material: Brass    Hub Diameter (D1): 12.70 mm    Hub Projection (HL): 6.35 mm    Locking Method: None    Quality: Commercial
Part Number: G019B-018-V24-064-048-B-P
Spur Gears - 18 tooth - 19.05x4.762 mm Hubbed - Brass Gear
1 Available Now | Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity
$20.00 AUD
$38.00 AUD $20.00 AUD
Each
Quantity Required

1 Available Now. These are priced to quit. Please contact us for a quote if you require more.
Number of Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Indicative
Number of Teeth
18

Pitch Circle Diameter (PD)
19.05
mm

(Equiv. 0.75 in.)
Bore (d)
4.762
mm

(Equiv. 0.187 in.)
Outside Diameter (OD)
21.158
mm
Spur Gears - 18 tooth - 19.05x4.762 mm Hubbed - Brass Gear
Material: Brass    Face Width (FW): 6.35 mm    Type: Hubbed    Hub Diameter (D1): 12.70 mm    Hub Projection (HL): 6.35 mm    Locking Method: None    Quality: Commercial
Part Number: G019B-018-V24-064-048-B-P
Spur Gears - 18 tooth - 19.05x4.762 mm Hubbed - Brass Gear
1 Available Now | Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity
$20.00 AUD
$38.00 AUD $20.00 AUD
Each
Quantity Required

1 Available Now. These are priced to quit. Please contact us for a quote if you require more.
Number of Teeth
54

Pitch Circle Diameter (PD)
57.15
mm

(Equiv. 2.25 in.)
Bore (d)
7.938
mm

(Equiv. 0.313 in.)
Outside Diameter (OD)
59.258
mm
Face Width (FW)
6.35
mm
Type
Hubbed
Spur Gears - 54 tooth - 57.15x7.938 mm Hubbed - Brass Gear
Material: Brass    Hub Diameter (D1): 17.46 mm    Hub Projection (HL): 7.94 mm    Locking Method: None    Quality: Commercial
Part Number: G057B-054-V24-064-079-B-P
Spur Gears - 54 tooth - 57.15x7.938 mm Hubbed - Brass Gear
1 Available Now | Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity
$25.00 AUD
$47.50 AUD $25.00 AUD
Each
Quantity Required

1 Available Now. These are priced to quit. Please contact us for a quote if you require more.
Number of Teeth
54

Pitch Circle Diameter (PD)
57.15
mm

(Equiv. 2.25 in.)
Bore (d)
7.938
mm

(Equiv. 0.313 in.)
Outside Diameter (OD)
59.258
mm
Spur Gears - 54 tooth - 57.15x7.938 mm Hubbed - Brass Gear
Material: Brass    Face Width (FW): 6.35 mm    Type: Hubbed    Hub Diameter (D1): 17.46 mm    Hub Projection (HL): 7.94 mm    Locking Method: None    Quality: Commercial
Part Number: G057B-054-V24-064-079-B-P
Spur Gears - 54 tooth - 57.15x7.938 mm Hubbed - Brass Gear
1 Available Now | Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity
$25.00 AUD
$47.50 AUD $25.00 AUD
Each
Quantity Required

1 Available Now. These are priced to quit. Please contact us for a quote if you require more.
