Shaft Diameter (Ds)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip ID (A)	Radial Wall (S) min/max	Groove Width (W)	Indicative Image
Shaft Diameter (Ds) 142.88 mm (Equiv. 5.625 in.)	Clip Thickness (T) 1.83 mm _{+/- 0.10} (Equiv. 0.072 in.)	Groove Dia. (Dg) 139.14 mm (Equiv. 5.478 in.)	Approx. Loose Circlip ID (A) 134.31 mm + 0.00 / - 1.27	Radial Wall (S) min/max 6.35 mm +/- 0.13	Groove Width (W) 2.07 mm +/- 0.18
Material: Carbon Spring Steel Approx. Loose Clip OD: 147.01 +/- 0.06 Category: Retaining Rings - External - Spiral Rings - Medium Duty
Part Number: RS-562 External Retaining Rings - 142.88x1.83x139.14 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 21, 2025 Regular price $32.41 AUD Regular price ~~$38.89 AUD~~ Sale price $32.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Shaft Diameter (Ds)	Clip Thickness (T)	Groove Dia. (Dg)	Approx. Loose Circlip ID (A)	Indicative Image
Shaft Diameter (Ds) 142.88 mm (Equiv. 5.625 in.)	Clip Thickness (T) 1.83 mm _{+/- 0.10} (Equiv. 0.072 in.)	Groove Dia. (Dg) 139.14 mm (Equiv. 5.478 in.)	Approx. Loose Circlip ID (A) 134.31 mm + 0.00 / - 1.27
Material: Carbon Spring Steel Radial Wall (S) min/max: 6.35 mm +/- 0.13 Groove Width (W): 2.07 mm +/- 0.18 Approx. Loose Clip OD: 147.01 +/- 0.06 Category: Retaining Rings - External - Spiral Rings - Medium Duty
Part Number: RS-562 External Retaining Rings - 142.88x1.83x139.14 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 21, 2025 Regular price $32.41 AUD Regular price ~~$38.89 AUD~~ Sale price $32.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
RS-562 --- External Retaining Rings - 142.88x1.83x139.14 mm Spiral Rings - Carbon Spring Steel Spiral Ring Sale RS-562 --- External Retaining Rings - 142.88x1.83x139.14 mm Spiral Rings - Carbon Spring Steel Spiral Ring Regular price $32.41 AUD Regular price ~~$38.89 AUD~~ Sale price $32.41 AUD Unit price per Out of stock! Backorder Now Sale
Shaft Diameter (Ds) 152.40 mm (Equiv. 6 in.)	Clip Thickness (T) 1.83 mm _{+/- 0.10} (Equiv. 0.072 in.)	Groove Dia. (Dg) 148.52 mm (Equiv. 5.847 in.)	Approx. Loose Circlip ID (A) 143.26 mm + 0.00 / - 1.27	Radial Wall (S) min/max 6.35 mm +/- 0.13	Groove Width (W) 2.07 mm +/- 0.17
Material: Carbon Spring Steel Approx. Loose Clip OD: 155.96 +/- 0.06 Category: Retaining Rings - External - Spiral Rings - Medium Duty
Part Number: RS-600 (5 Pcs) External Retaining Rings - 152.4x1.83x148.52 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 21, 2025 Regular price $26.50 AUD Regular price Sale price $26.50 AUD Unit price per Per 5 Quantity Required Backorder: Out of Stock.
Shaft Diameter (Ds) 152.40 mm (Equiv. 6 in.)	Clip Thickness (T) 1.83 mm _{+/- 0.10} (Equiv. 0.072 in.)	Groove Dia. (Dg) 148.52 mm (Equiv. 5.847 in.)	Approx. Loose Circlip ID (A) 143.26 mm + 0.00 / - 1.27
Material: Carbon Spring Steel Radial Wall (S) min/max: 6.35 mm +/- 0.13 Groove Width (W): 2.07 mm +/- 0.17 Approx. Loose Clip OD: 155.96 +/- 0.06 Category: Retaining Rings - External - Spiral Rings - Medium Duty
Part Number: RS-600 (5 Pcs) External Retaining Rings - 152.4x1.83x148.52 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 21, 2025 Regular price $26.50 AUD Regular price Sale price $26.50 AUD Unit price per Per 5 Quantity Required Backorder: Out of Stock.
RS-600 (5 Pcs) --- External Retaining Rings - 152.4x1.83x148.52 mm Spiral Rings - Carbon Spring Steel Spiral Ring RS-600 (5 Pcs) --- External Retaining Rings - 152.4x1.83x148.52 mm Spiral Rings - Carbon Spring Steel Spiral Ring Regular price $26.50 AUD Regular price Sale price $26.50 AUD Unit price per Out of stock! Backorder Now
Shaft Diameter (Ds) 177.80 mm (Equiv. 7 in.)	Clip Thickness (T) 2.19 mm _{+/- 0.11} (Equiv. 0.086 in.)	Groove Dia. (Dg) 173.18 mm (Equiv. 6.818 in.)	Approx. Loose Circlip ID (A) 167.13 mm + 0.00 / - 1.52	Radial Wall (S) min/max 7.93 mm +/- 0.16	Groove Width (W) 2.47 mm +/- 0.20
Material: Carbon Spring Steel Approx. Loose Clip OD: 182.99 +/- 0.08 Category: Retaining Rings - External - Spiral Rings - Medium Duty
Part Number: RS-700 External Retaining Rings - 177.8x2.19x173.18 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 21, 2025 Regular price $36.41 AUD Regular price ~~$43.69 AUD~~ Sale price $36.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Shaft Diameter (Ds) 177.80 mm (Equiv. 7 in.)	Clip Thickness (T) 2.19 mm _{+/- 0.11} (Equiv. 0.086 in.)	Groove Dia. (Dg) 173.18 mm (Equiv. 6.818 in.)	Approx. Loose Circlip ID (A) 167.13 mm + 0.00 / - 1.52
Material: Carbon Spring Steel Radial Wall (S) min/max: 7.93 mm +/- 0.16 Groove Width (W): 2.47 mm +/- 0.20 Approx. Loose Clip OD: 182.99 +/- 0.08 Category: Retaining Rings - External - Spiral Rings - Medium Duty
Part Number: RS-700 External Retaining Rings - 177.8x2.19x173.18 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Sun, Sep 21, 2025 Regular price $36.41 AUD Regular price ~~$43.69 AUD~~ Sale price $36.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
RS-700 --- External Retaining Rings - 177.8x2.19x173.18 mm Spiral Rings - Carbon Spring Steel Spiral Ring Sale RS-700 --- External Retaining Rings - 177.8x2.19x173.18 mm Spiral Rings - Carbon Spring Steel Spiral Ring Regular price $36.41 AUD Regular price ~~$43.69 AUD~~ Sale price $36.41 AUD Unit price per Out of stock! Backorder Now Sale
Shaft Diameter (Ds) 254.00 mm (Equiv. 10 in.)	Clip Thickness (T) 4.75 mm _{+/- 0.13} (Equiv. 0.187 in.)	Groove Dia. (Dg) 243.21 mm (Equiv. 9.575 in.)	Approx. Loose Circlip ID (A) 241.51 mm + 0.00 / - 1.78	Radial Wall (S) min/max 12.70 mm +/- 0.18	Groove Width (W) 5.41 mm +/- 0.20
Material: Carbon Spring Steel Approx. Loose Clip OD: 266.91 +/- 0.10 Category: Retaining Rings - External - Spiral Rings - Heavy Duty
Part Number: RSN-1000 (3 Pcs) External Retaining Rings - 254x4.75x243.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Fri, Oct 03, 2025 Regular price $966.05 AUD Regular price Sale price $966.05 AUD Unit price per Per 3 Quantity Required Backorder: Out of Stock.
Shaft Diameter (Ds) 254.00 mm (Equiv. 10 in.)	Clip Thickness (T) 4.75 mm _{+/- 0.13} (Equiv. 0.187 in.)	Groove Dia. (Dg) 243.21 mm (Equiv. 9.575 in.)	Approx. Loose Circlip ID (A) 241.51 mm + 0.00 / - 1.78
Material: Carbon Spring Steel Radial Wall (S) min/max: 12.70 mm +/- 0.18 Groove Width (W): 5.41 mm +/- 0.20 Approx. Loose Clip OD: 266.91 +/- 0.10 Category: Retaining Rings - External - Spiral Rings - Heavy Duty
Part Number: RSN-1000 (3 Pcs) External Retaining Rings - 254x4.75x243.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring Out of Stock \| Backorder Now \| Orders can be expected around Fri, Oct 03, 2025 Regular price $966.05 AUD Regular price Sale price $966.05 AUD Unit price per Per 3 Quantity Required Backorder: Out of Stock.
RSN-1000 (3 Pcs) --- External Retaining Rings - 254x4.75x243.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring RSN-1000 (3 Pcs) --- External Retaining Rings - 254x4.75x243.21 mm Spiral Rings - Carbon Spring Steel Spiral Ring Regular price $966.05 AUD Regular price Sale price $966.05 AUD Unit price per Out of stock! Backorder Now
