Plungers - Ball Push Fit - Stainless Body - Nylon Ball

Plungers -> Ball Push Fit -> Stainless Body -> Nylon Ball

There are 8 products in the sub-categories of Plungers - Ball Push Fit - Stainless Body - Nylon Ball. Browse the Plungers - Ball Push Fit - Stainless Body - Nylon Ball products table.

Category Details

A selection of Nylon Ball Stainless Body Ball Push Fit Plungers. Unthreaded.

  • Non-threaded, spring-loaded device that uses a ball to secure, locate, or position components in applications like drawers, dies, and fixtures.
  • Installed by simply pushing it into a pre-drilled hole in materials like wood, soft plastic, or aluminum, making it a quick alternative to threaded plungers where they are impractical.

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Plungers - Ball Push Fit - Stainless Body - Nylon Ball category on the Small Parts & Bearings online store.
Body Diameter (D) Length (L) Initial Pressure (F1) Final Pressure (F2) Ball Diameter (D1) Ball Height (H) Indicative
Body Diameter (D)
3.18
mm
+ 0.1 / - 0.0
(Equiv. 0.125 in.)
Length (L)
6.4
mm

(Equiv. 0.252 in.)
Initial Pressure (F1)
1.8
N
Final Pressure (F2)
5.8
N
Ball Diameter (D1)
2.4
mm
Ball Height (H)
0.9
mm
Ball Push Fit Plungers - 3.18x6.4 mm - 1.8 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 4.8 mm
Part Number: PLBP-032-064-SN-006 (Each)
Ball Push Fit Plungers - 3.18x6.4 mm - 1.8 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.41 AUD
$10.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D) Length (L) Initial Pressure (F1) Final Pressure (F2) Indicative
Body Diameter (D)
3.18
mm
+ 0.1 / - 0.0
(Equiv. 0.125 in.)
Length (L)
6.4
mm

(Equiv. 0.252 in.)
Initial Pressure (F1)
1.8
N
Final Pressure (F2)
5.8
N
Ball Push Fit Plungers - 3.18x6.4 mm - 1.8 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 2.4 mm    Ball Height (H): 0.9 mm    Shoulder Diameter (S): 4.8 mm
Part Number: PLBP-032-064-SN-006 (Each)
Ball Push Fit Plungers - 3.18x6.4 mm - 1.8 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.41 AUD
$10.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
3.18
mm
+ 0.1 / - 0.0
(Equiv. 0.125 in.)
Length (L)
6.4
mm

(Equiv. 0.252 in.)
Initial Pressure (F1)
3.3
N
Final Pressure (F2)
11.1
N
Ball Diameter (D1)
2.4
mm
Ball Height (H)
0.9
mm
Ball Push Fit Plungers - 3.18x6.4 mm - 3.3 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 4.8 mm
Part Number: PLBP-032-064-SN-011 (Each)
Ball Push Fit Plungers - 3.18x6.4 mm - 3.3 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$16.05 AUD
$19.25 AUD $16.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
3.18
mm
+ 0.1 / - 0.0
(Equiv. 0.125 in.)
Length (L)
6.4
mm

(Equiv. 0.252 in.)
Initial Pressure (F1)
3.3
N
Final Pressure (F2)
11.1
N
Ball Push Fit Plungers - 3.18x6.4 mm - 3.3 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 2.4 mm    Ball Height (H): 0.9 mm    Shoulder Diameter (S): 4.8 mm
Part Number: PLBP-032-064-SN-011 (Each)
Ball Push Fit Plungers - 3.18x6.4 mm - 3.3 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$16.05 AUD
$19.25 AUD $16.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
4.78
mm
+ 0.1 / - 0.0
(Equiv. 0.188 in.)
Length (L)
10.0
mm

(Equiv. 0.394 in.)
Initial Pressure (F1)
8.9
N
Final Pressure (F2)
22.2
N
Ball Diameter (D1)
4.0
mm
Ball Height (H)
1.5
mm
Ball Push Fit Plungers - 4.78x10 mm - 8.9 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 6.4 mm
Part Number: PLBP-048-100-SN-022 (Each)
Ball Push Fit Plungers - 4.78x10 mm - 8.9 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$11.23 AUD
$13.47 AUD $11.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
4.78
mm
+ 0.1 / - 0.0
(Equiv. 0.188 in.)
Length (L)
10.0
mm

(Equiv. 0.394 in.)
Initial Pressure (F1)
8.9
N
Final Pressure (F2)
22.2
N
Ball Push Fit Plungers - 4.78x10 mm - 8.9 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 4.0 mm    Ball Height (H): 1.5 mm    Shoulder Diameter (S): 6.4 mm
Part Number: PLBP-048-100-SN-022 (Each)
Ball Push Fit Plungers - 4.78x10 mm - 8.9 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$11.23 AUD
$13.47 AUD $11.23 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
4.78
mm
+ 0.1 / - 0.0
(Equiv. 0.188 in.)
Length (L)
10.3
mm

(Equiv. 0.406 in.)
Initial Pressure (F1)
4.5
N
Final Pressure (F2)
11.1
N
Ball Diameter (D1)
4.0
mm
Ball Height (H)
1.5
mm
Ball Push Fit Plungers - 4.78x10.3 mm - 4.5 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 6.4 mm
Part Number: PLBP-048-103-SN-011 (Each)
Ball Push Fit Plungers - 4.78x10.3 mm - 4.5 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.32 AUD
$12.38 AUD $10.32 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
4.78
mm
+ 0.1 / - 0.0
(Equiv. 0.188 in.)
Length (L)
10.3
mm

(Equiv. 0.406 in.)
Initial Pressure (F1)
4.5
N
Final Pressure (F2)
11.1
N
Ball Push Fit Plungers - 4.78x10.3 mm - 4.5 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 4.0 mm    Ball Height (H): 1.5 mm    Shoulder Diameter (S): 6.4 mm
Part Number: PLBP-048-103-SN-011 (Each)
Ball Push Fit Plungers - 4.78x10.3 mm - 4.5 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.32 AUD
$12.38 AUD $10.32 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
6.35
mm
+ 0.1 / - 0.0
(Equiv. 0.25 in.)
Length (L)
12.0
mm

(Equiv. 0.472 in.)
Initial Pressure (F1)
13.4
N
Final Pressure (F2)
31.1
N
Ball Diameter (D1)
4.8
mm
Ball Height (H)
1.8
mm
Ball Push Fit Plungers - 6.35x12 mm - 13.4 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 7.9 mm
Part Number: PLBP-064-120-SN-031 (Each)
Ball Push Fit Plungers - 6.35x12 mm - 13.4 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.77 AUD
$12.93 AUD $10.77 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
6.35
mm
+ 0.1 / - 0.0
(Equiv. 0.25 in.)
Length (L)
12.0
mm

(Equiv. 0.472 in.)
Initial Pressure (F1)
13.4
N
Final Pressure (F2)
31.1
N
Ball Push Fit Plungers - 6.35x12 mm - 13.4 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 4.8 mm    Ball Height (H): 1.8 mm    Shoulder Diameter (S): 7.9 mm
Part Number: PLBP-064-120-SN-031 (Each)
Ball Push Fit Plungers - 6.35x12 mm - 13.4 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.77 AUD
$12.93 AUD $10.77 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
6.35
mm
+ 0.1 / - 0.0
(Equiv. 0.25 in.)
Length (L)
12.2
mm

(Equiv. 0.48 in.)
Initial Pressure (F1)
6.7
N
Final Pressure (F2)
15.6
N
Ball Diameter (D1)
4.8
mm
Ball Height (H)
1.8
mm
Ball Push Fit Plungers - 6.35x12.2 mm - 6.7 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 7.9 mm
Part Number: PLBP-064-122-SN-016 (Each)
Ball Push Fit Plungers - 6.35x12.2 mm - 6.7 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.86 AUD
$13.04 AUD $10.86 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
6.35
mm
+ 0.1 / - 0.0
(Equiv. 0.25 in.)
Length (L)
12.2
mm

(Equiv. 0.48 in.)
Initial Pressure (F1)
6.7
N
Final Pressure (F2)
15.6
N
Ball Push Fit Plungers - 6.35x12.2 mm - 6.7 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 4.8 mm    Ball Height (H): 1.8 mm    Shoulder Diameter (S): 7.9 mm
Part Number: PLBP-064-122-SN-016 (Each)
Ball Push Fit Plungers - 6.35x12.2 mm - 6.7 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$10.86 AUD
$13.04 AUD $10.86 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
9.53
mm
+ 0.1 / - 0.0
(Equiv. 0.375 in.)
Length (L)
19.9
mm

(Equiv. 0.783 in.)
Initial Pressure (F1)
11.1
N
Final Pressure (F2)
31.1
N
Ball Diameter (D1)
7.9
mm
Ball Height (H)
2.8
mm
Ball Push Fit Plungers - 9.53x19.9 mm - 11.1 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 12.7 mm
Part Number: PLBP-095-199-SN-031 (Each)
Ball Push Fit Plungers - 9.53x19.9 mm - 11.1 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$12.05 AUD
$14.45 AUD $12.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
9.53
mm
+ 0.1 / - 0.0
(Equiv. 0.375 in.)
Length (L)
19.9
mm

(Equiv. 0.783 in.)
Initial Pressure (F1)
11.1
N
Final Pressure (F2)
31.1
N
Ball Push Fit Plungers - 9.53x19.9 mm - 11.1 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 7.9 mm    Ball Height (H): 2.8 mm    Shoulder Diameter (S): 12.7 mm
Part Number: PLBP-095-199-SN-031 (Each)
Ball Push Fit Plungers - 9.53x19.9 mm - 11.1 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$12.05 AUD
$14.45 AUD $12.05 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
9.53
mm
+ 0.1 / - 0.0
(Equiv. 0.375 in.)
Length (L)
20.0
mm

(Equiv. 0.787 in.)
Initial Pressure (F1)
22.2
N
Final Pressure (F2)
62.3
N
Ball Diameter (D1)
7.9
mm
Ball Height (H)
2.8
mm
Ball Push Fit Plungers - 9.53x20 mm - 22.2 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Shoulder Diameter (S): 12.7 mm
Part Number: PLBP-095-200-SN-062 (Each)
Ball Push Fit Plungers - 9.53x20 mm - 22.2 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$12.41 AUD
$14.89 AUD $12.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
Body Diameter (D)
9.53
mm
+ 0.1 / - 0.0
(Equiv. 0.375 in.)
Length (L)
20.0
mm

(Equiv. 0.787 in.)
Initial Pressure (F1)
22.2
N
Final Pressure (F2)
62.3
N
Ball Push Fit Plungers - 9.53x20 mm - 22.2 N Stainless Body - Nylon Polyamide 6/6
Material: Nylon (Polyamide 6/6)    Ball Diameter (D1): 7.9 mm    Ball Height (H): 2.8 mm    Shoulder Diameter (S): 12.7 mm
Part Number: PLBP-095-200-SN-062 (Each)
Ball Push Fit Plungers - 9.53x20 mm - 22.2 N Stainless Body - Nylon Polyamide 6/6 Plunger
Out of Stock | Backorder Now | Orders can be expected around Tue, Dec 30, 2025
$12.41 AUD
$14.89 AUD $12.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

Backorder: Out of Stock.
