Collection: Snap Buttons - Flat Type

Snap Buttons -> Flat Type

There is only 1 product in the sub-categories of Snap Buttons - Flat Type. Browse the Snap Buttons - Flat Type products table.

Category Details

A selection of Flat Type Snap Buttons. Fasteners for telescoping tubing help reduce assembly time whilst improving your product functionality. Also called button clips or spring buttons.

  • Eliminates the need for rivets and screws.
  • Simply snap into place in square or round tubing.
  • Made from 1050 heat treated spring steel with minimum 0.005mm (0.0002 inch) zinc plating

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Snap Buttons - Flat Type category on the Small Parts & Bearings online store.
Button Diameter (A) Button Height (B) Material Thickness Clip Width Hole Diameter Centre Distrnce (C) Indicative
Button Diameter (A)
6.35
mm

(Equiv. 0.25 in.)
Button Height (B)
5.33
mm

(Equiv. 0.21 in.)
Material Thickness
0.457
mm

(Equiv. 0.018 in.)
Clip Width
9.27
mm
Hole Diameter
3.25
mm
Centre Distrnce (C)
21.3
mm
Flat Type Snap Buttons - 6.35x5.33x0.457 mm
Material: Carbon Spring Steel    Length (D): 31.750 mm
Part Number: SBTN-0635-FL
Flat Type Snap Buttons - 6.35x5.33x0.457 mm Snap Button
49 Available Now | Further orders can be expected around Sat, Nov 01, 2025
Regular price $5.41 AUD
Regular price Sale price $5.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

49 Available Now. Backorder if more than 49.
Button Diameter (A) Button Height (B) Material Thickness Clip Width Indicative
Button Diameter (A)
6.35
mm

(Equiv. 0.25 in.)
Button Height (B)
5.33
mm

(Equiv. 0.21 in.)
Material Thickness
0.457
mm

(Equiv. 0.018 in.)
Clip Width
9.27
mm
Flat Type Snap Buttons - 6.35x5.33x0.457 mm
Material: Carbon Spring Steel    Hole Diameter: 3.25 mm    Centre Distrnce (C): 21.3 mm    Length (D): 31.750 mm
Part Number: SBTN-0635-FL
Flat Type Snap Buttons - 6.35x5.33x0.457 mm Snap Button
49 Available Now | Further orders can be expected around Sat, Nov 01, 2025
Regular price $5.41 AUD
Regular price Sale price $5.41 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

49 Available Now. Backorder if more than 49.
