Collection: Shock Absorbers - Hydraulic - Non-Adjustable - C-Jac

Shock Absorbers -> Hydraulic -> Non-Adjustable -> C-Jac

There are 28 products in the sub-categories of Shock Absorbers - Hydraulic - Non-Adjustable - C-Jac. Scroll down or follow the link to Shock Absorbers - Hydraulic - Non-Adjustable - C-Jac in the products table to see all these items combined into a handy table with filters.

Category Details

A selection of C-Jac Non-Adjustable Hydraulic Shock Absorbers. Self compensation

Miniature Bearings Australia - MBA Minibearings

Additional resources:

A more concise listing may be found in the Shock Absorbers - Hydraulic - Non-Adjustable - C-Jac category on the Small Parts & Bearings online store.

Stroke	Thread (C)	Length (A)	Shaft Size (D)	Max. Effective Mass	Max. Nm Per Cycle
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 155.5 mm (Equiv. 6.122 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 1500 Kg	Max. Nm Per Cycle 80
Max. Nm Per Hour: 54000 Max Impact Speed: 1.0 m/s Weight: 330 g Body Length (B): 101 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2
Part Number: AC-2525-3 Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable 7 Available Now \| Item Discontinued - Up to 7 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $60.00 AUD Regular price ~~$193.37 AUD~~ Sale price $60.00 AUD Unit price per Each Quantity Required 7 Available Now. These are priced to quit. Please contact us for a quote if you require more.
Stroke	Thread (C)	Length (A)	Shaft Size (D)	Indicative Image
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 155.5 mm (Equiv. 6.122 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 1500 Kg Max. Nm Per Cycle: 80 Max. Nm Per Hour: 54000 Max Impact Speed: 1.0 m/s Weight: 330 g Body Length (B): 101 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2
Part Number: AC-2525-3 Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable 7 Available Now \| Item Discontinued - Up to 7 may be ordered online. No backorders. Please contact us if you need a larger quantity Regular price $60.00 AUD Regular price ~~$193.37 AUD~~ Sale price $60.00 AUD Unit price per Each Quantity Required 7 Available Now. These are priced to quit. Please contact us for a quote if you require more.
AC-2525-3 --- Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable Sale AC-2525-3 --- Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable Regular price $60.00 AUD Regular price ~~$193.37 AUD~~ Sale price $60.00 AUD Unit price per 7 Available Now Sale
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 155.5 mm (Equiv. 6.122 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 800 Kg	Max. Nm Per Cycle 80
Max. Nm Per Hour: 54000 Max Impact Speed: 2.5 m/s Weight: 330 g Body Length (B): 101 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2525-2 Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable 2 Available Now \| Further orders can be expected around Wed, Oct 01, 2025 Regular price $75.41 AUD Regular price ~~$193.37 AUD~~ Sale price $75.41 AUD Unit price per Each Quantity Required 2 Available Now. Backorder if more than 2.
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 155.5 mm (Equiv. 6.122 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 800 Kg Max. Nm Per Cycle: 80 Max. Nm Per Hour: 54000 Max Impact Speed: 2.5 m/s Weight: 330 g Body Length (B): 101 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2525-2 Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable 2 Available Now \| Further orders can be expected around Wed, Oct 01, 2025 Regular price $75.41 AUD Regular price ~~$193.37 AUD~~ Sale price $75.41 AUD Unit price per Each Quantity Required 2 Available Now. Backorder if more than 2.
AC-2525-2 --- Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable Sale AC-2525-2 --- Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable Regular price $75.41 AUD Regular price ~~$193.37 AUD~~ Sale price $75.41 AUD Unit price per 2 Available Now Sale
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 141.5 mm (Equiv. 5.571 in.)	Shaft Size (D) 8.0 mm
Material: Steel Weight: 330 g Body Length (B): 90.0 mm Tip Length x Diameter (CxE): 18.5 x 22 mm Figure: Special Preset Damping
Part Number: AC-2525-S Hydraulic Shock Absorbers - 25 mm M25x1.5 141.5 mm Non-Adjustable - Steel Shock Absorber Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 04, 2025 Regular price $96.68 AUD Regular price ~~$204.28 AUD~~ Sale price $96.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 141.5 mm (Equiv. 5.571 in.)	Shaft Size (D) 8.0 mm
Material: Steel Weight: 330 g Body Length (B): 90.0 mm Tip Length x Diameter (CxE): 18.5 x 22 mm Figure: Special Preset Damping
Part Number: AC-2525-S Hydraulic Shock Absorbers - 25 mm M25x1.5 141.5 mm Non-Adjustable - Steel Shock Absorber Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 04, 2025 Regular price $96.68 AUD Regular price ~~$204.28 AUD~~ Sale price $96.68 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
AC-2525-S --- Hydraulic Shock Absorbers - 25 mm M25x1.5 141.5 mm Non-Adjustable - Steel Shock Absorber Sale AC-2525-S --- Hydraulic Shock Absorbers - 25 mm M25x1.5 141.5 mm Non-Adjustable - Steel Shock Absorber Regular price $96.68 AUD Regular price ~~$204.28 AUD~~ Sale price $96.68 AUD Unit price per Out of stock! Backorder Now Sale
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 155.5 mm (Equiv. 6.122 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 200 Kg	Max. Nm Per Cycle 80
Max. Nm Per Hour: 54000 Max Impact Speed: 4.0 m/s Weight: 330 g Body Length (B): 101 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2525-1 Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $194.41 AUD Regular price Sale price $194.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
Stroke 25.0 mm (Equiv. 0.984 in.)	Thread (C) M25x1.5	Length (A) 155.5 mm (Equiv. 6.122 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 200 Kg Max. Nm Per Cycle: 80 Max. Nm Per Hour: 54000 Max Impact Speed: 4.0 m/s Weight: 330 g Body Length (B): 101 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2525-1 Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $194.41 AUD Regular price Sale price $194.41 AUD Unit price per Each Quantity Required Backorder: Out of Stock.
AC-2525-1 --- Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable AC-2525-1 --- Hydraulic Shock Absorbers - 25 mm M25x1.5 155.5 mm Non-Adjustable Regular price $194.41 AUD Regular price Sale price $194.41 AUD Unit price per Out of stock! Backorder Now
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 158.0 mm (Equiv. 6.22 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 200 Kg	Max. Nm Per Cycle 50
Max. Nm Per Hour: 48000 Max Impact Speed: 2.0 m/s Weight: 220 g Body Length (B): 110 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2030-2 Hydraulic Shock Absorbers - 30 mm M20x1.5 158 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 158.0 mm (Equiv. 6.22 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 200 Kg Max. Nm Per Cycle: 50 Max. Nm Per Hour: 48000 Max Impact Speed: 2.0 m/s Weight: 220 g Body Length (B): 110 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2030-2 Hydraulic Shock Absorbers - 30 mm M20x1.5 158 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 158.0 mm (Equiv. 6.22 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 30 Kg	Max. Nm Per Cycle 50
Max. Nm Per Hour: 48000 Max Impact Speed: 3.5 m/s Weight: 220 g Body Length (B): 110 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2030-1 Hydraulic Shock Absorbers - 30 mm M20x1.5 158 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 158.0 mm (Equiv. 6.22 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 30 Kg Max. Nm Per Cycle: 50 Max. Nm Per Hour: 48000 Max Impact Speed: 3.5 m/s Weight: 220 g Body Length (B): 110 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2030-1 Hydraulic Shock Absorbers - 30 mm M20x1.5 158 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 158.0 mm (Equiv. 6.22 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 700 Kg	Max. Nm Per Cycle 50
Max. Nm Per Hour: 48000 Max Impact Speed: 1.0 m/s Weight: 220 g Body Length (B): 110 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2030-3 Hydraulic Shock Absorbers - 30 mm M20x1.5 158 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 158.0 mm (Equiv. 6.22 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 700 Kg Max. Nm Per Cycle: 50 Max. Nm Per Hour: 48000 Max Impact Speed: 1.0 m/s Weight: 220 g Body Length (B): 110 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2030-3 Hydraulic Shock Absorbers - 30 mm M20x1.5 158 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 189.0 mm (Equiv. 7.441 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 300 Kg	Max. Nm Per Cycle 45
Max. Nm Per Hour: 55000 Max Impact Speed: 2.0 m/s Weight: 220 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: ACD-2030-2 Hydraulic Shock Absorbers - 30 mm M20x1.5 189 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 189.0 mm (Equiv. 7.441 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 300 Kg Max. Nm Per Cycle: 45 Max. Nm Per Hour: 55000 Max Impact Speed: 2.0 m/s Weight: 220 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: ACD-2030-2 Hydraulic Shock Absorbers - 30 mm M20x1.5 189 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 189.0 mm (Equiv. 7.441 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 40 Kg	Max. Nm Per Cycle 45
Max. Nm Per Hour: 55000 Max Impact Speed: 3.5 m/s Weight: 220 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: ACD-2030-1 Hydraulic Shock Absorbers - 30 mm M20x1.5 189 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 189.0 mm (Equiv. 7.441 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 40 Kg Max. Nm Per Cycle: 45 Max. Nm Per Hour: 55000 Max Impact Speed: 3.5 m/s Weight: 220 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: ACD-2030-1 Hydraulic Shock Absorbers - 30 mm M20x1.5 189 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 189.0 mm (Equiv. 7.441 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 900 Kg	Max. Nm Per Cycle 45
Max. Nm Per Hour: 55000 Max Impact Speed: 1.0 m/s Weight: 220 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: ACD-2030-3 Hydraulic Shock Absorbers - 30 mm M20x1.5 189 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 30.0 mm (Equiv. 1.181 in.)	Thread (C) M20x1.5	Length (A) 189.0 mm (Equiv. 7.441 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 900 Kg Max. Nm Per Cycle: 45 Max. Nm Per Hour: 55000 Max Impact Speed: 1.0 m/s Weight: 220 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: ACD-2030-3 Hydraulic Shock Absorbers - 30 mm M20x1.5 189 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 35.0 mm (Equiv. 1.378 in.)	Thread (C) M20x1.5	Length (A) 223.0 mm (Equiv. 8.78 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 200 Kg	Max. Nm Per Cycle 52
Max. Nm Per Hour: 63000 Max Impact Speed: 2.0 m/s Weight: 210 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x15 mm Figure: Figure 2.
Part Number: ACD-2035-2 Hydraulic Shock Absorbers - 35 mm M20x1.5 223 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 35.0 mm (Equiv. 1.378 in.)	Thread (C) M20x1.5	Length (A) 223.0 mm (Equiv. 8.78 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 200 Kg Max. Nm Per Cycle: 52 Max. Nm Per Hour: 63000 Max Impact Speed: 2.0 m/s Weight: 210 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x15 mm Figure: Figure 2.
Part Number: ACD-2035-2 Hydraulic Shock Absorbers - 35 mm M20x1.5 223 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 35.0 mm (Equiv. 1.378 in.)	Thread (C) M20x1.5	Length (A) 223.0 mm (Equiv. 8.78 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 40 Kg	Max. Nm Per Cycle 52
Max. Nm Per Hour: 63000 Max Impact Speed: 3.5 m/s Weight: 210 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x15 mm Figure: Figure 2.
Part Number: ACD-2035-1 Hydraulic Shock Absorbers - 35 mm M20x1.5 223 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 35.0 mm (Equiv. 1.378 in.)	Thread (C) M20x1.5	Length (A) 223.0 mm (Equiv. 8.78 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 40 Kg Max. Nm Per Cycle: 52 Max. Nm Per Hour: 63000 Max Impact Speed: 3.5 m/s Weight: 210 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x15 mm Figure: Figure 2.
Part Number: ACD-2035-1 Hydraulic Shock Absorbers - 35 mm M20x1.5 223 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 35.0 mm (Equiv. 1.378 in.)	Thread (C) M20x1.5	Length (A) 223.0 mm (Equiv. 8.78 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 650 Kg	Max. Nm Per Cycle 52
Max. Nm Per Hour: 63000 Max Impact Speed: 1.0 m/s Weight: 210 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x15 mm Figure: Figure 2.
Part Number: ACD-2035-3 Hydraulic Shock Absorbers - 35 mm M20x1.5 223 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 35.0 mm (Equiv. 1.378 in.)	Thread (C) M20x1.5	Length (A) 223.0 mm (Equiv. 8.78 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 650 Kg Max. Nm Per Cycle: 52 Max. Nm Per Hour: 63000 Max Impact Speed: 1.0 m/s Weight: 210 g Body Length (B): 123 mm Tip Length x Diameter (CxE): 18x15 mm Figure: Figure 2.
Part Number: ACD-2035-3 Hydraulic Shock Absorbers - 35 mm M20x1.5 223 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 40.0 mm (Equiv. 1.575 in.)	Thread (C) M25x1.5	Length (A) 213.0 mm (Equiv. 8.386 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 1200 Kg	Max. Nm Per Cycle 120
Max. Nm Per Hour: 75000 Max Impact Speed: 2.5 m/s Weight: 430 g Body Length (B): 117 mm Tip Length x Diameter (CxE): 22x36 mm Figure: Figure 1.
Part Number: AC-2540-2 Hydraulic Shock Absorbers - 40 mm M25x1.5 213 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 40.0 mm (Equiv. 1.575 in.)	Thread (C) M25x1.5	Length (A) 213.0 mm (Equiv. 8.386 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 1200 Kg Max. Nm Per Cycle: 120 Max. Nm Per Hour: 75000 Max Impact Speed: 2.5 m/s Weight: 430 g Body Length (B): 117 mm Tip Length x Diameter (CxE): 22x36 mm Figure: Figure 1.
Part Number: AC-2540-2 Hydraulic Shock Absorbers - 40 mm M25x1.5 213 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 40.0 mm (Equiv. 1.575 in.)	Thread (C) M25x1.5	Length (A) 213.0 mm (Equiv. 8.386 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 2000 Kg	Max. Nm Per Cycle 120
Max. Nm Per Hour: 75000 Max Impact Speed: 4.0 m/s Weight: 430 g Body Length (B): 117 mm Tip Length x Diameter (CxE): 22x36 mm Figure: Figure 1.
Part Number: AC-2540-3 Hydraulic Shock Absorbers - 40 mm M25x1.5 213 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 40.0 mm (Equiv. 1.575 in.)	Thread (C) M25x1.5	Length (A) 213.0 mm (Equiv. 8.386 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 2000 Kg Max. Nm Per Cycle: 120 Max. Nm Per Hour: 75000 Max Impact Speed: 4.0 m/s Weight: 430 g Body Length (B): 117 mm Tip Length x Diameter (CxE): 22x36 mm Figure: Figure 1.
Part Number: AC-2540-3 Hydraulic Shock Absorbers - 40 mm M25x1.5 213 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 40.0 mm (Equiv. 1.575 in.)	Thread (C) M25x1.5	Length (A) 213.0 mm (Equiv. 8.386 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 300 Kg	Max. Nm Per Cycle 120
Max. Nm Per Hour: 75000 Max Impact Speed: 4.0 m/s Weight: 430 g Body Length (B): 117 mm Tip Length x Diameter (CxE): 22x36 mm Figure: Figure 1.
Part Number: AC-2540-1 Hydraulic Shock Absorbers - 40 mm M25x1.5 213 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 40.0 mm (Equiv. 1.575 in.)	Thread (C) M25x1.5	Length (A) 213.0 mm (Equiv. 8.386 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 300 Kg Max. Nm Per Cycle: 120 Max. Nm Per Hour: 75000 Max Impact Speed: 4.0 m/s Weight: 430 g Body Length (B): 117 mm Tip Length x Diameter (CxE): 22x36 mm Figure: Figure 1.
Part Number: AC-2540-1 Hydraulic Shock Absorbers - 40 mm M25x1.5 213 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M20x1.5	Length (A) 235.0 mm (Equiv. 9.252 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 1200 Kg	Max. Nm Per Cycle 60
Max. Nm Per Hour: 60000 Max Impact Speed: 1.0 m/s Weight: 300 g Body Length (B): 167 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2050-3 Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M20x1.5	Length (A) 235.0 mm (Equiv. 9.252 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 1200 Kg Max. Nm Per Cycle: 60 Max. Nm Per Hour: 60000 Max Impact Speed: 1.0 m/s Weight: 300 g Body Length (B): 167 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2050-3 Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M20x1.5	Length (A) 235.0 mm (Equiv. 9.252 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 400 Kg	Max. Nm Per Cycle 60
Max. Nm Per Hour: 60000 Max Impact Speed: 2.0 m/s Weight: 300 g Body Length (B): 167 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2050-2 Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M20x1.5	Length (A) 235.0 mm (Equiv. 9.252 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 400 Kg Max. Nm Per Cycle: 60 Max. Nm Per Hour: 60000 Max Impact Speed: 2.0 m/s Weight: 300 g Body Length (B): 167 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2050-2 Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M20x1.5	Length (A) 235.0 mm (Equiv. 9.252 in.)	Shaft Size (D) 6.0 mm	Max. Effective Mass 60 Kg	Max. Nm Per Cycle 60
Max. Nm Per Hour: 60000 Max Impact Speed: 3.5 m/s Weight: 300 g Body Length (B): 167 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2050-1 Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable 2 Available Now \| Further orders can be expected around Wed, Oct 01, 2025 Regular price $199.95 AUD Regular price Sale price $199.95 AUD Unit price per Each Quantity Required 2 Available Now. Backorder if more than 2.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M20x1.5	Length (A) 235.0 mm (Equiv. 9.252 in.)	Shaft Size (D) 6.0 mm
Max. Effective Mass: 60 Kg Max. Nm Per Cycle: 60 Max. Nm Per Hour: 60000 Max Impact Speed: 3.5 m/s Weight: 300 g Body Length (B): 167 mm Tip Length x Diameter (CxE): 18x18 mm Figure: Figure 1.
Part Number: AC-2050-1 Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable 2 Available Now \| Further orders can be expected around Wed, Oct 01, 2025 Regular price $199.95 AUD Regular price Sale price $199.95 AUD Unit price per Each Quantity Required 2 Available Now. Backorder if more than 2.
AC-2050-1 --- Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable AC-2050-1 --- Hydraulic Shock Absorbers - 50 mm M20x1.5 235 mm Non-Adjustable Regular price $199.95 AUD Regular price Sale price $199.95 AUD Unit price per 2 Available Now
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M25x1.5	Length (A) 240.0 mm (Equiv. 9.449 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 15 Kg	Max. Nm Per Cycle 98
Max. Nm Per Hour: 90000 Max Impact Speed: 2.5 m/s Weight: 435 g Body Length (B): 100 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2550-1 Hydraulic Shock Absorbers - 50 mm M25x1.5 240 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M25x1.5	Length (A) 240.0 mm (Equiv. 9.449 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 15 Kg Max. Nm Per Cycle: 98 Max. Nm Per Hour: 90000 Max Impact Speed: 2.5 m/s Weight: 435 g Body Length (B): 100 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2550-1 Hydraulic Shock Absorbers - 50 mm M25x1.5 240 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M25x1.5	Length (A) 240.0 mm (Equiv. 9.449 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 160 Kg	Max. Nm Per Cycle 98
Max. Nm Per Hour: 90000 Max Impact Speed: 2.5 m/s Weight: 435 g Body Length (B): 100 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2550-3 Hydraulic Shock Absorbers - 50 mm M25x1.5 240 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M25x1.5	Length (A) 240.0 mm (Equiv. 9.449 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 160 Kg Max. Nm Per Cycle: 98 Max. Nm Per Hour: 90000 Max Impact Speed: 2.5 m/s Weight: 435 g Body Length (B): 100 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2550-3 Hydraulic Shock Absorbers - 50 mm M25x1.5 240 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M25x1.5	Length (A) 240.0 mm (Equiv. 9.449 in.)	Shaft Size (D) 8.0 mm	Max. Effective Mass 40 Kg	Max. Nm Per Cycle 98
Max. Nm Per Hour: 90000 Max Impact Speed: 4.0 m/s Weight: 435 g Body Length (B): 100 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2550-2 Hydraulic Shock Absorbers - 50 mm M25x1.5 240 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 50.0 mm (Equiv. 1.969 in.)	Thread (C) M25x1.5	Length (A) 240.0 mm (Equiv. 9.449 in.)	Shaft Size (D) 8.0 mm
Max. Effective Mass: 40 Kg Max. Nm Per Cycle: 98 Max. Nm Per Hour: 90000 Max Impact Speed: 4.0 m/s Weight: 435 g Body Length (B): 100 mm Tip Length x Diameter (CxE): 22x19.5 mm Figure: Figure 2.
Part Number: AC-2550-2 Hydraulic Shock Absorbers - 50 mm M25x1.5 240 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 60.0 mm (Equiv. 2.362 in.)	Thread (C) M36x1.5	Length (A) 248.0 mm (Equiv. 9.764 in.)	Shaft Size (D) 10.0 mm	Max. Effective Mass 1500 Kg	Max. Nm Per Cycle 250
Max. Nm Per Hour: 120000 Max Impact Speed: 2.5 m/s Weight: 1030 g Body Length (B): 134 mm Tip Length x Diameter (CxE): 35x26 mm Figure: Figure 4.
Part Number: AC-3660-2 Hydraulic Shock Absorbers - 60 mm M36x1.5 248 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 60.0 mm (Equiv. 2.362 in.)	Thread (C) M36x1.5	Length (A) 248.0 mm (Equiv. 9.764 in.)	Shaft Size (D) 10.0 mm
Max. Effective Mass: 1500 Kg Max. Nm Per Cycle: 250 Max. Nm Per Hour: 120000 Max Impact Speed: 2.5 m/s Weight: 1030 g Body Length (B): 134 mm Tip Length x Diameter (CxE): 35x26 mm Figure: Figure 4.
Part Number: AC-3660-2 Hydraulic Shock Absorbers - 60 mm M36x1.5 248 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 60.0 mm (Equiv. 2.362 in.)	Thread (C) M36x1.5	Length (A) 248.0 mm (Equiv. 9.764 in.)	Shaft Size (D) 10.0 mm	Max. Effective Mass 2400 Kg	Max. Nm Per Cycle 250
Max. Nm Per Hour: 120000 Max Impact Speed: 1.0 m/s Weight: 1030 g Body Length (B): 134 mm Tip Length x Diameter (CxE): 35x26 mm Figure: Figure 4.
Part Number: AC-3660-3 Hydraulic Shock Absorbers - 60 mm M36x1.5 248 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
Stroke 60.0 mm (Equiv. 2.362 in.)	Thread (C) M36x1.5	Length (A) 248.0 mm (Equiv. 9.764 in.)	Shaft Size (D) 10.0 mm
Max. Effective Mass: 2400 Kg Max. Nm Per Cycle: 250 Max. Nm Per Hour: 120000 Max Impact Speed: 1.0 m/s Weight: 1030 g Body Length (B): 134 mm Tip Length x Diameter (CxE): 35x26 mm Figure: Figure 4.
Part Number: AC-3660-3 Hydraulic Shock Absorbers - 60 mm M36x1.5 248 mm Non-Adjustable Contact Us \| Item Discontinued - Please contact us if you need a large quantity Quantity Required Contact Us. These are priced to quit. Please contact us for a quote if you require more.
