Collection: Retaining Rings - E-Clips - Basic - Carbon Steel

Retaining Rings -> E-Clips -> Basic -> Carbon Steel

Minimum Rec. Shaft Dia (S)	Groove Dia. (Dg)	Clip Thickness (T)	Clip OD Loose (D1)	Groove Width (W)	Indicative Image
Minimum Rec. Shaft Dia (S) 24.99 mm _{+ 3.05 / - 0.00} (Equiv. 0.984 in.)	Groove Dia. (Dg) 21.21 mm _{+ 0.076 / - 0.000} (Equiv. 0.835 in.)	Clip Thickness (T) 1.27 mm _{+/ - 0.050} (Equiv. 0.05 in.)	Clip OD Loose (D1) 38.10 mm	Groove Width (W) 1.42 mm
Material: Carbon Steel Maximum Rec. Shaft Dia (S): 28.04 Clip OD in groove (C1): 38.86 mm
Part Number: ECL-0212-0250-C (5 Pcs) E-Clips Retaining Rings - 24.99x21.21x1.27 mm Basic - Carbon Steel E-Clip Out of Stock \| Backorder Now \| Orders can be expected around Thu, Oct 02, 2025 Regular price $7.86 AUD Regular price ~~$18.02 AUD~~ Sale price $7.86 AUD Unit price per Per 5 Quantity Required Backorder: Out of Stock.
Minimum Rec. Shaft Dia (S)	Groove Dia. (Dg)	Clip Thickness (T)	Clip OD Loose (D1)	Indicative Image
Minimum Rec. Shaft Dia (S) 24.99 mm _{+ 3.05 / - 0.00} (Equiv. 0.984 in.)	Groove Dia. (Dg) 21.21 mm _{+ 0.076 / - 0.000} (Equiv. 0.835 in.)	Clip Thickness (T) 1.27 mm _{+/ - 0.050} (Equiv. 0.05 in.)	Clip OD Loose (D1) 38.10 mm
Material: Carbon Steel Groove Width (W): 1.42 mm Maximum Rec. Shaft Dia (S): 28.04 Clip OD in groove (C1): 38.86 mm
Part Number: ECL-0212-0250-C (5 Pcs) E-Clips Retaining Rings - 24.99x21.21x1.27 mm Basic - Carbon Steel E-Clip Out of Stock \| Backorder Now \| Orders can be expected around Thu, Oct 02, 2025 Regular price $7.86 AUD Regular price ~~$18.02 AUD~~ Sale price $7.86 AUD Unit price per Per 5 Quantity Required Backorder: Out of Stock.
ECL-0212-0250-C (5 Pcs) --- E-Clips Retaining Rings - 24.99x21.21x1.27 mm Basic - Carbon Steel E-Clip Sale ECL-0212-0250-C (5 Pcs) --- E-Clips Retaining Rings - 24.99x21.21x1.27 mm Basic - Carbon Steel E-Clip Regular price $7.86 AUD Regular price ~~$18.02 AUD~~ Sale price $7.86 AUD Unit price per Out of stock! Backorder Now Sale
Minimum Rec. Shaft Dia (S) 25.00 mm _{+ 13.00 / - 0.00} (Equiv. 0.984 in.)	Groove Dia. (Dg) 24.00 mm _{+ 0.00 / - 0.13} (Equiv. 0.945 in.)	Clip Thickness (T) 2.00 mm _{+/ - 0.03} (Equiv. 0.079 in.)	Clip OD Loose (D1) 43.65 mm	Groove Width (W) 2.05 mm
Material: Carbon Steel Maximum Rec. Shaft Dia (S): 38.00 Clip OD in groove (C1): 44.60 mm Loose Clip ID (A): 21.88 mm Min. Extension (n): 4.00 Standard: DIN6799
Part Number: ECL-0240-0250-C (2 Pcs) E-Clips Retaining Rings - 25x24x2 mm Basic - Carbon Steel E-Clip 30 units (60 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $6.59 AUD Regular price Sale price $6.59 AUD Unit price per Per 2 Quantity Required 30 units (60 pcs) Available Now. Backorder if more than 30.
Minimum Rec. Shaft Dia (S) 25.00 mm _{+ 13.00 / - 0.00} (Equiv. 0.984 in.)	Groove Dia. (Dg) 24.00 mm _{+ 0.00 / - 0.13} (Equiv. 0.945 in.)	Clip Thickness (T) 2.00 mm _{+/ - 0.03} (Equiv. 0.079 in.)	Clip OD Loose (D1) 43.65 mm
Material: Carbon Steel Groove Width (W): 2.05 mm Maximum Rec. Shaft Dia (S): 38.00 Clip OD in groove (C1): 44.60 mm Loose Clip ID (A): 21.88 mm Min. Extension (n): 4.00 Standard: DIN6799
Part Number: ECL-0240-0250-C (2 Pcs) E-Clips Retaining Rings - 25x24x2 mm Basic - Carbon Steel E-Clip 30 units (60 pcs) Available Now \| Further orders can be expected around Sun, Sep 21, 2025 Regular price $6.59 AUD Regular price Sale price $6.59 AUD Unit price per Per 2 Quantity Required 30 units (60 pcs) Available Now. Backorder if more than 30.
ECL-0240-0250-C (2 Pcs) --- E-Clips Retaining Rings - 25x24x2 mm Basic - Carbon Steel E-Clip ECL-0240-0250-C (2 Pcs) --- E-Clips Retaining Rings - 25x24x2 mm Basic - Carbon Steel E-Clip Regular price $6.59 AUD Regular price Sale price $6.59 AUD Unit price per 30 Available Now
Minimum Rec. Shaft Dia (S) 30.16 mm _{+ 5.08 / - 0.00} (Equiv. 1.187 in.)	Groove Dia. (Dg) 27.41 mm _{+ 0.127 / - 0.000} (Equiv. 1.079 in.)	Clip Thickness (T) 1.58 mm _{+/ - 0.075} (Equiv. 0.062 in.)	Clip OD Loose (D1) 41.30 mm	Groove Width (W) 1.73 mm
Material: Carbon Steel Maximum Rec. Shaft Dia (S): 35.24 Clip OD in groove (C1): 42.42 mm
Part Number: ECL-0274-0302-C (2 Pcs) E-Clips Retaining Rings - 30.16x27.41x1.58 mm Basic - Carbon Steel E-Clip 10 units (20 pcs) Available Now \| Further orders can be expected around Thu, Oct 02, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Per 2 Quantity Required 10 units (20 pcs) Available Now. Backorder if more than 10.
Minimum Rec. Shaft Dia (S) 30.16 mm _{+ 5.08 / - 0.00} (Equiv. 1.187 in.)	Groove Dia. (Dg) 27.41 mm _{+ 0.127 / - 0.000} (Equiv. 1.079 in.)	Clip Thickness (T) 1.58 mm _{+/ - 0.075} (Equiv. 0.062 in.)	Clip OD Loose (D1) 41.30 mm
Material: Carbon Steel Groove Width (W): 1.73 mm Maximum Rec. Shaft Dia (S): 35.24 Clip OD in groove (C1): 42.42 mm
Part Number: ECL-0274-0302-C (2 Pcs) E-Clips Retaining Rings - 30.16x27.41x1.58 mm Basic - Carbon Steel E-Clip 10 units (20 pcs) Available Now \| Further orders can be expected around Thu, Oct 02, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Per 2 Quantity Required 10 units (20 pcs) Available Now. Backorder if more than 10.
ECL-0274-0302-C (2 Pcs) --- E-Clips Retaining Rings - 30.16x27.41x1.58 mm Basic - Carbon Steel E-Clip ECL-0274-0302-C (2 Pcs) --- E-Clips Retaining Rings - 30.16x27.41x1.58 mm Basic - Carbon Steel E-Clip Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per 10 Available Now
Minimum Rec. Shaft Dia (S) 34.93 mm _{+ 5.08 / - 0.00} (Equiv. 1.375 in.)	Groove Dia. (Dg) 31.24 mm _{+ 0.127 / - 0.000} (Equiv. 1.23 in.)	Clip Thickness (T) 1.58 mm _{+/ - 0.075} (Equiv. 0.062 in.)	Clip OD Loose (D1) 47.63 mm	Groove Width (W) 1.73 mm
Material: Carbon Steel Maximum Rec. Shaft Dia (S): 40.01 Clip OD in groove (C1): 48.77 mm
Part Number: ECL-0312-0349-C E-Clips Retaining Rings - 34.93x31.24x1.58 mm Basic - Carbon Steel E-Clip 10 Available Now \| Further orders can be expected around Thu, Oct 02, 2025 Regular price $1.95 AUD Regular price ~~$5.19 AUD~~ Sale price $1.95 AUD Unit price per Each Quantity Required 10 Available Now. Backorder if more than 10.
Minimum Rec. Shaft Dia (S) 34.93 mm _{+ 5.08 / - 0.00} (Equiv. 1.375 in.)	Groove Dia. (Dg) 31.24 mm _{+ 0.127 / - 0.000} (Equiv. 1.23 in.)	Clip Thickness (T) 1.58 mm _{+/ - 0.075} (Equiv. 0.062 in.)	Clip OD Loose (D1) 47.63 mm
Material: Carbon Steel Groove Width (W): 1.73 mm Maximum Rec. Shaft Dia (S): 40.01 Clip OD in groove (C1): 48.77 mm
Part Number: ECL-0312-0349-C E-Clips Retaining Rings - 34.93x31.24x1.58 mm Basic - Carbon Steel E-Clip 10 Available Now \| Further orders can be expected around Thu, Oct 02, 2025 Regular price $1.95 AUD Regular price ~~$5.19 AUD~~ Sale price $1.95 AUD Unit price per Each Quantity Required 10 Available Now. Backorder if more than 10.
ECL-0312-0349-C --- E-Clips Retaining Rings - 34.93x31.24x1.58 mm Basic - Carbon Steel E-Clip Sale ECL-0312-0349-C --- E-Clips Retaining Rings - 34.93x31.24x1.58 mm Basic - Carbon Steel E-Clip Regular price $1.95 AUD Regular price ~~$5.19 AUD~~ Sale price $1.95 AUD Unit price per 10 Available Now Sale
