Collection: Pulleys - Metric Timing - 5.000mm Pitch - AT5 - 25mm Wide

Pulleys -> Metric Timing -> 5.000mm Pitch -> AT5 -> 25mm Wide

There are 19 products in the sub-categories of Pulleys - Metric Timing - 5.000mm Pitch - AT5 - 25mm Wide. Browse the Pulleys - Metric Timing - 5.000mm Pitch - AT5 - 25mm Wide products table.

Category Details

A selection of 25mm Wide AT5 5.000mm Pitch Metric Timing Pulleys. Timing pulleys to suit AT5 Series belts

Timing pulleys combined with timing belts, provide power transmission without slippage.
Timing pulleys are toothed pulleys used with timing belts to synchronize the movement of different mechanical components, ensuring precise timing and coordination.
Some uses for timing pulleys include 3D printers, CNC machines, robotics and automation components, textile machinery, office equipment such as scanners and copiers, and medical devices requiring precise movement control.
Aluminium Alloy
Steel Flanges
Hub is unthreaded, you will need to drill and tap with your required locking screw size

Miniature Bearings Australia - MBA Minibearings

Additional resources:

A more concise listing may be found in the Pulleys - Metric Timing - 5.000mm Pitch - AT5 - 25mm Wide category on the Small Parts & Bearings online store.

Number of Teeth	Max Belt Width	Bore (d)	Bore Type	Locking Type
Metric Timing Pulleys - 12 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley
Number of Teeth 12	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) No Bore 0 mm	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 19.09 mm Flange Diameter (FD): 23.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 11.0
Part Number: P-050A-012-250FF-AL-N-000 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $65.05 AUD Regular price Sale price $65.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Number of Teeth	Max Belt Width	Bore (d)	Bore Type	Indicative Image
Metric Timing Pulleys - 12 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley
Number of Teeth 12	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) No Bore 0 mm	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 19.09 mm Flange Diameter (FD): 23.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 11.0
Part Number: P-050A-012-250FF-AL-N-000 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $65.05 AUD Regular price Sale price $65.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-012-250FF-AL-N-000 (Each) --- Metric Timing Pulleys - 12 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley P-050A-012-250FF-AL-N-000 (Each) --- Metric Timing Pulleys - 12 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley Regular price $65.05 AUD Regular price Sale price $65.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now
Metric Timing Pulleys - 14 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley
Number of Teeth 14	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) No Bore 0 mm	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 22.27 mm Flange Diameter (FD): 25.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 13.0
Part Number: P-050A-014-250FF-AL-N-000 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $56.05 AUD Regular price ~~$67.25 AUD~~ Sale price $56.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 14 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley
Number of Teeth 14	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) No Bore 0 mm	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 22.27 mm Flange Diameter (FD): 25.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 13.0
Part Number: P-050A-014-250FF-AL-N-000 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $56.05 AUD Regular price ~~$67.25 AUD~~ Sale price $56.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-014-250FF-AL-N-000 (Each) --- Metric Timing Pulleys - 14 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley Sale P-050A-014-250FF-AL-N-000 (Each) --- Metric Timing Pulleys - 14 tooth - 25 - No Bore 0 5mm Pitch - Aluminium Pulley Regular price $56.05 AUD Regular price ~~$67.25 AUD~~ Sale price $56.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 15 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 15	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 23.86 mm Flange Diameter (FD): 28.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 16.0
Part Number: P-050A-015-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $57.32 AUD Regular price ~~$68.78 AUD~~ Sale price $57.32 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 15 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 15	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 23.86 mm Flange Diameter (FD): 28.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 16.0
Part Number: P-050A-015-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $57.32 AUD Regular price ~~$68.78 AUD~~ Sale price $57.32 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-015-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 15 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-015-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 15 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $57.32 AUD Regular price ~~$68.78 AUD~~ Sale price $57.32 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 16 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 16	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 25.45 mm Flange Diameter (FD): 32.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 18.0
Part Number: P-050A-016-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $57.50 AUD Regular price ~~$69.00 AUD~~ Sale price $57.50 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 16 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 16	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 25.45 mm Flange Diameter (FD): 32.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 18.0
Part Number: P-050A-016-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $57.50 AUD Regular price ~~$69.00 AUD~~ Sale price $57.50 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-016-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 16 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-016-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 16 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $57.50 AUD Regular price ~~$69.00 AUD~~ Sale price $57.50 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 18 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 18	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 32.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 20.0
Part Number: P-050A-018-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $58.41 AUD Regular price ~~$70.09 AUD~~ Sale price $58.41 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 18 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 18	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 28.64 mm Flange Diameter (FD): 32.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 20.0
Part Number: P-050A-018-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $58.41 AUD Regular price ~~$70.09 AUD~~ Sale price $58.41 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-018-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 18 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-018-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 18 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $58.41 AUD Regular price ~~$70.09 AUD~~ Sale price $58.41 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 20 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 20	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 31.82 mm Flange Diameter (FD): 36.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 23.0
Part Number: P-050A-020-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $64.68 AUD Regular price ~~$77.62 AUD~~ Sale price $64.68 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 20 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 20	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 31.82 mm Flange Diameter (FD): 36.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 23.0
Part Number: P-050A-020-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $64.68 AUD Regular price ~~$77.62 AUD~~ Sale price $64.68 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-020-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 20 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-020-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 20 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $64.68 AUD Regular price ~~$77.62 AUD~~ Sale price $64.68 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 22 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 22	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 35.00 mm Flange Diameter (FD): 38.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 24.0
Part Number: P-050A-022-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $65.59 AUD Regular price ~~$78.71 AUD~~ Sale price $65.59 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 22 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 22	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 35.00 mm Flange Diameter (FD): 38.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 24.0
Part Number: P-050A-022-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $65.59 AUD Regular price ~~$78.71 AUD~~ Sale price $65.59 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-022-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 22 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-022-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 22 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $65.59 AUD Regular price ~~$78.71 AUD~~ Sale price $65.59 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 24 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 24	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 42.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 26.0
Part Number: P-050A-024-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $66.05 AUD Regular price ~~$79.25 AUD~~ Sale price $66.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 24 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 24	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 38.18 mm Flange Diameter (FD): 42.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 26.0
Part Number: P-050A-024-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $66.05 AUD Regular price ~~$79.25 AUD~~ Sale price $66.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-024-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 24 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-024-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 24 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $66.05 AUD Regular price ~~$79.25 AUD~~ Sale price $66.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 25 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 25	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 39.77 mm Flange Diameter (FD): 44.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 26.0
Part Number: P-050A-025-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $67.77 AUD Regular price ~~$81.33 AUD~~ Sale price $67.77 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 25 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 25	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 39.77 mm Flange Diameter (FD): 44.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 26.0
Part Number: P-050A-025-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $67.77 AUD Regular price ~~$81.33 AUD~~ Sale price $67.77 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-025-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 25 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-025-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 25 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $67.77 AUD Regular price ~~$81.33 AUD~~ Sale price $67.77 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 26 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 26	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 41.36 mm Flange Diameter (FD): 44.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 26.0
Part Number: P-050A-026-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $68.59 AUD Regular price ~~$82.31 AUD~~ Sale price $68.59 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 26 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 26	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 6.000 mm (Equiv. 0.236 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 41.36 mm Flange Diameter (FD): 44.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 26.0
Part Number: P-050A-026-250FF-AL-N-060 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $68.59 AUD Regular price ~~$82.31 AUD~~ Sale price $68.59 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-026-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 26 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Sale P-050A-026-250FF-AL-N-060 (Each) --- Metric Timing Pulleys - 26 tooth - 25x6 mm 5mm Pitch - Aluminium Pulley Regular price $68.59 AUD Regular price ~~$82.31 AUD~~ Sale price $68.59 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 27 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 27	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 42.95 mm Flange Diameter (FD): 46.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 38.0
Part Number: P-050A-027-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $69.50 AUD Regular price ~~$83.40 AUD~~ Sale price $69.50 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 27 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 27	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 42.95 mm Flange Diameter (FD): 46.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 38.0
Part Number: P-050A-027-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $69.50 AUD Regular price ~~$83.40 AUD~~ Sale price $69.50 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-027-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 27 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-027-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 27 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $69.50 AUD Regular price ~~$83.40 AUD~~ Sale price $69.50 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 30 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 30	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 47.73 mm Flange Diameter (FD): 51.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 34.0
Part Number: P-050A-030-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $72.05 AUD Regular price ~~$86.45 AUD~~ Sale price $72.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 30 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 30	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 47.73 mm Flange Diameter (FD): 51.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 34.0
Part Number: P-050A-030-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $72.05 AUD Regular price ~~$86.45 AUD~~ Sale price $72.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-030-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 30 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-030-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 30 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $72.05 AUD Regular price ~~$86.45 AUD~~ Sale price $72.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 32 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 32	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 50.91 mm Flange Diameter (FD): 54.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 38.0
Part Number: P-050A-032-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $85.95 AUD Regular price ~~$103.15 AUD~~ Sale price $85.95 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 32 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 32	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 50.91 mm Flange Diameter (FD): 54.0 mm Overall Length: 36.0 mm Hub Diameter (HD): 38.0
Part Number: P-050A-032-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $85.95 AUD Regular price ~~$103.15 AUD~~ Sale price $85.95 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-032-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 32 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-032-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 32 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $85.95 AUD Regular price ~~$103.15 AUD~~ Sale price $85.95 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 36 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 36	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 60.3 mm Overall Length: 36.0 mm Hub Diameter (HD): 38.0
Part Number: P-050A-036-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $89.05 AUD Regular price ~~$106.85 AUD~~ Sale price $89.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 36 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 36	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 57.27 mm Flange Diameter (FD): 60.3 mm Overall Length: 36.0 mm Hub Diameter (HD): 38.0
Part Number: P-050A-036-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $89.05 AUD Regular price ~~$106.85 AUD~~ Sale price $89.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-036-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 36 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-036-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 36 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $89.05 AUD Regular price ~~$106.85 AUD~~ Sale price $89.05 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 40 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 40	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 2 Pitch Dia. (PD): 63.63 mm Flange Diameter (FD): 66.7 mm Overall Length: 36.0 mm Hub Diameter (HD): 40.0
Part Number: P-050A-040-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $99.86 AUD Regular price ~~$119.84 AUD~~ Sale price $99.86 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 40 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 40	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 2 Pitch Dia. (PD): 63.63 mm Flange Diameter (FD): 66.7 mm Overall Length: 36.0 mm Hub Diameter (HD): 40.0
Part Number: P-050A-040-250FF-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $99.86 AUD Regular price ~~$119.84 AUD~~ Sale price $99.86 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-040-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 40 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-040-250FF-AL-N-080 (Each) --- Metric Timing Pulleys - 40 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $99.86 AUD Regular price ~~$119.84 AUD~~ Sale price $99.86 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 44 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 44	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 3 Pitch Dia. (PD): 70.00 mm Overall Length: 38.0 mm Hub Diameter (HD): 50.0
Part Number: P-050A-044-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $111.14 AUD Regular price ~~$133.36 AUD~~ Sale price $111.14 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 44 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 44	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 3 Pitch Dia. (PD): 70.00 mm Overall Length: 38.0 mm Hub Diameter (HD): 50.0
Part Number: P-050A-044-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $111.14 AUD Regular price ~~$133.36 AUD~~ Sale price $111.14 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-044-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 44 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-044-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 44 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $111.14 AUD Regular price ~~$133.36 AUD~~ Sale price $111.14 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 48 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 48	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 3 Pitch Dia. (PD): 76.36 mm Overall Length: 38.0 mm Hub Diameter (HD): 50.0
Part Number: P-050A-048-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $120.68 AUD Regular price ~~$144.82 AUD~~ Sale price $120.68 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 48 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 48	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 3 Pitch Dia. (PD): 76.36 mm Overall Length: 38.0 mm Hub Diameter (HD): 50.0
Part Number: P-050A-048-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $120.68 AUD Regular price ~~$144.82 AUD~~ Sale price $120.68 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-048-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 48 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-048-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 48 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $120.68 AUD Regular price ~~$144.82 AUD~~ Sale price $120.68 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 60 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 60	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 3 Pitch Dia. (PD): 95.45 mm Overall Length: 38.0 mm Hub Diameter (HD): 65.0
Part Number: P-050A-060-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $135.86 AUD Regular price ~~$163.04 AUD~~ Sale price $135.86 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 60 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 60	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 3 Pitch Dia. (PD): 95.45 mm Overall Length: 38.0 mm Hub Diameter (HD): 65.0
Part Number: P-050A-060-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $135.86 AUD Regular price ~~$163.04 AUD~~ Sale price $135.86 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-060-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 60 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-060-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 60 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $135.86 AUD Regular price ~~$163.04 AUD~~ Sale price $135.86 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale
Metric Timing Pulleys - 72 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 72	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain	Locking Type None
Material: Aluminium Type: 3 Pitch Dia. (PD): 114.54 mm Overall Length: 38.0 mm Hub Diameter (HD): 80.0
Part Number: P-050A-072-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $194.41 AUD Regular price ~~$233.29 AUD~~ Sale price $194.41 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
Metric Timing Pulleys - 72 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley
Number of Teeth 72	Max Belt Width 25.00 mm (Equiv. 0.984 in.)	Bore (d) 8.000 mm (Equiv. 0.315 in.)	Bore Type Plain
Material: Aluminium Locking Type: None Type: 3 Pitch Dia. (PD): 114.54 mm Overall Length: 38.0 mm Hub Diameter (HD): 80.0
Part Number: P-050A-072-250P-AL-N-080 (Each) Out of Stock \| Backorder Now \| Orders can be expected around Wed, Mar 04, 2026 Regular price $194.41 AUD Regular price ~~$233.29 AUD~~ Sale price $194.41 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Quantity Required Backorder: Out of Stock.
P-050A-072-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 72 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Sale P-050A-072-250P-AL-N-080 (Each) --- Metric Timing Pulleys - 72 tooth - 25x8 mm 5mm Pitch - Aluminium Pulley Regular price $194.41 AUD Regular price ~~$233.29 AUD~~ Sale price $194.41 AUD Unit price per Each Excludes GST and overseas Taxes & Duties Out of stock! Backorder Now Sale

Country/region

Miniature Bearings Australia

Collection: Pulleys - Metric Timing - 5.000mm Pitch - AT5 - 25mm Wide

Category Details

Filter

Filter

Subscribe to our emails
