| Diameter (D) | Length (L) | Approx. Overall Length | Type |
Indicative Image |
|---|---|---|---|---|
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
30.00
mm +/- 0.500 (Equiv. 1.181 in.) |
Approx. Overall Length
30.00
mm +/- 0.500 (Equiv. 1.181 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-030-303-2
Dowel Pins - 12x30 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
| Diameter (D) | Length (L) | Approx. Overall Length |
Indicative Image |
|
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
30.00
mm +/- 0.500 (Equiv. 1.181 in.) |
Approx. Overall Length
30.00
mm +/- 0.500 (Equiv. 1.181 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-030-303-2
Dowel Pins - 12x30 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
32.00
mm +/- 0.500 (Equiv. 1.26 in.) |
Approx. Overall Length
32.00
mm +/- 0.500 (Equiv. 1.26 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-032-303-2
Dowel Pins - 12x32 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
32.00
mm +/- 0.500 (Equiv. 1.26 in.) |
Approx. Overall Length
32.00
mm +/- 0.500 (Equiv. 1.26 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-032-303-2
Dowel Pins - 12x32 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
36.00
mm +/- 0.500 (Equiv. 1.417 in.) |
Approx. Overall Length
36.00
mm +/- 0.500 (Equiv. 1.417 in.) |
Type
2 (Chamfer Both Ends)
|
|
|
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80
Chamfer: 2.5 x 15 Deg
Standard: Based on ISO 2338
Deleted Item. Available while stocks last. |
||||
|
Part Number: DP120-036-303-2 (5 Pcs)
Dowel Pins - 12x36 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
36.00
mm +/- 0.500 (Equiv. 1.417 in.) |
Approx. Overall Length
36.00
mm +/- 0.500 (Equiv. 1.417 in.) |
|
|
|
Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80
Type: 2 (Chamfer Both Ends)
Chamfer: 2.5 x 15 Deg
Standard: Based on ISO 2338
Deleted Item. Available while stocks last. |
||||
|
Part Number: DP120-036-303-2 (5 Pcs)
Dowel Pins - 12x36 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
40.00
mm +/- 0.500 (Equiv. 1.575 in.) |
Approx. Overall Length
40.00
mm +/- 0.500 (Equiv. 1.575 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-040-303-2
Dowel Pins - 12x40 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
40.00
mm +/- 0.500 (Equiv. 1.575 in.) |
Approx. Overall Length
40.00
mm +/- 0.500 (Equiv. 1.575 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-040-303-2
Dowel Pins - 12x40 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
45.00
mm +/- 0.500 (Equiv. 1.772 in.) |
Approx. Overall Length
45.00
mm +/- 0.500 (Equiv. 1.772 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-045-303-2
Dowel Pins - 12x45 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
45.00
mm +/- 0.500 (Equiv. 1.772 in.) |
Approx. Overall Length
45.00
mm +/- 0.500 (Equiv. 1.772 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-045-303-2
Dowel Pins - 12x45 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
50.00
mm +/- 0.600 (Equiv. 1.969 in.) |
Approx. Overall Length
50.00
mm +/- 0.600 (Equiv. 1.969 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-050-303-2
Dowel Pins - 12x50 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
50.00
mm +/- 0.600 (Equiv. 1.969 in.) |
Approx. Overall Length
50.00
mm +/- 0.600 (Equiv. 1.969 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-050-303-2
Dowel Pins - 12x50 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
55.00
mm +/- 0.600 (Equiv. 2.165 in.) |
Approx. Overall Length
55.00
mm +/- 0.600 (Equiv. 2.165 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-055-303-2
Dowel Pins - 12x55 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
55.00
mm +/- 0.600 (Equiv. 2.165 in.) |
Approx. Overall Length
55.00
mm +/- 0.600 (Equiv. 2.165 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-055-303-2
Dowel Pins - 12x55 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
60.00
mm +/- 0.600 (Equiv. 2.362 in.) |
Approx. Overall Length
60.00
mm +/- 0.600 (Equiv. 2.362 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-060-303-2
Dowel Pins - 12x60 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
60.00
mm +/- 0.600 (Equiv. 2.362 in.) |
Approx. Overall Length
60.00
mm +/- 0.600 (Equiv. 2.362 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-060-303-2
Dowel Pins - 12x60 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
70.00
mm +/- 0.600 (Equiv. 2.756 in.) |
Approx. Overall Length
70.00
mm +/- 0.600 (Equiv. 2.756 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-070-303-2
Dowel Pins - 12x70 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
70.00
mm +/- 0.600 (Equiv. 2.756 in.) |
Approx. Overall Length
70.00
mm +/- 0.600 (Equiv. 2.756 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-070-303-2
Dowel Pins - 12x70 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
80.00
mm +/- 0.700 (Equiv. 3.15 in.) |
Approx. Overall Length
80.00
mm +/- 0.700 (Equiv. 3.15 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-080-303-2
Dowel Pins - 12x80 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
80.00
mm +/- 0.700 (Equiv. 3.15 in.) |
Approx. Overall Length
80.00
mm +/- 0.700 (Equiv. 3.15 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-080-303-2
Dowel Pins - 12x80 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
90.00
mm +/- 0.700 (Equiv. 3.543 in.) |
Approx. Overall Length
90.00
mm +/- 0.700 (Equiv. 3.543 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-090-303-2
Dowel Pins - 12x90 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
90.00
mm +/- 0.700 (Equiv. 3.543 in.) |
Approx. Overall Length
90.00
mm +/- 0.700 (Equiv. 3.543 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-090-303-2
Dowel Pins - 12x90 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018
(Equiv. 0.472 in.) |
Length (L)
100.00
mm +/- 0.700 (Equiv. 3.937 in.) |
Approx. Overall Length
100.00
mm +/- 0.700 (Equiv. 3.937 in.) |
Type
2 (Chamfer Both Ends)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-100-303-2
Dowel Pins - 12x100 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
12.000
mm + 0.007 / + 0.018 (Equiv. 0.472 in.) |
Length (L)
100.00
mm +/- 0.700 (Equiv. 3.937 in.) |
Approx. Overall Length
100.00
mm +/- 0.700 (Equiv. 3.937 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 2 (Chamfer Both Ends) Chamfer: 2.5 x 15 Deg Standard: Based on ISO 2338 | ||||
|
Part Number: DP120-100-303-2
Dowel Pins - 12x100 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
|
Diameter (D)
1.588
mm + 0.002 / + 0.008
(Equiv. 0.063 in.) |
Length (L)
5.56
mm +/- 0.254 (Equiv. 0.219 in.) |
Approx. Overall Length
5.56
mm +/- 0.254 (Equiv. 0.219 in.) |
Type
1 (Chamfer One End)
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Chamfer: 0.30 x 15 Deg Standard: Based on DIN 6325 | ||||
|
Part Number: DP016-006-303-1A (500 Pcs)
Dowel Pins - 1.588x5.56 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity |
||||
|
Diameter (D)
1.588
mm + 0.002 / + 0.008 (Equiv. 0.063 in.) |
Length (L)
5.56
mm +/- 0.254 (Equiv. 0.219 in.) |
Approx. Overall Length
5.56
mm +/- 0.254 (Equiv. 0.219 in.) |
|
|
| Material: Stainless Steel 303/304 (Similar to A2, 18-8) HRB80 Type: 1 (Chamfer One End) Chamfer: 0.30 x 15 Deg Standard: Based on DIN 6325 | ||||
|
Part Number: DP016-006-303-1A (500 Pcs)
Dowel Pins - 1.588x5.56 Standard - Stainless Steel 303/304 Similar to A2, 18-8 HRB80 Pin Contact Us | Special Order Only - Please contact us if you need a large quantity | Orders can be expected around Tue, Aug 08, 2028 |
||||
