Collection: Mounts - Bonded - Tee Bush Centre Bolt

Mounts (With Images)

Bonded

Tee Bush Centre Bolt
Tee Bush Two Piece

15 Products in this selection

Vibration isolation for mobile and static applications involving plate clamping
Reduces structure borne noise and absorbs shock forces
Low profile height

Additional resources:
Cylindrical Bobbin Mounts PDF Quick Guide

A more concise listing may be found on the Smallparts store at Mounts - Bonded - Tee Bush Centre Bolt. Smallparts promote the most popular MBA products.

Max Static Load	Bolt Hole Diameter (C)	Flange Diameter (A)	Flange Width (F)	Shoulder Diameter (D)	Overall Length (B)
34 kg	10.1 mm	27.7 mm	5.59 mm	20.6 mm	25.9 mm
Material: Rubber
Part Number: MB-0034-028 Bonded Mounts - 34 kg - 10.1x27.7 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $21.23 AUD Regular price Sale price $21.23 AUD Unit price per Each
Max Static Load	Bolt Hole Diameter (C)	Flange Diameter (A)	Flange Width (F)	Indicative Image
34 kg	10.1 mm	27.7 mm	5.59 mm
Material: Rubber Shoulder Diameter (D): 20.6 mm Overall Length (B): 25.9 mm
Part Number: MB-0034-028 Bonded Mounts - 34 kg - 10.1x27.7 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $21.23 AUD Regular price Sale price $21.23 AUD Unit price per Each View the product page first if you are unsure.
MB-0034-028 --- Bonded Mounts - 34 kg - 10.1x27.7 mm - Rubber MB-0034-028 --- Bonded Mounts - 34 kg - 10.1x27.7 mm - Rubber Regular price $21.23 AUD Regular price Sale price $21.23 AUD Unit price per Out of stock! Backorder Now
50 kg	10.0 mm	27.0 mm	6.0 mm	20.0 mm	22.1 mm
Material: Neoprene Rubber and Steel Durometer Hardness: 60
Part Number: TB-25-60SR Bonded Mounts - 50 kg - 10x27 mm - Neoprene Rubber and Steel 20 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $9.14 AUD Regular price ~~$10.96 AUD~~ Sale price $9.14 AUD Unit price per Each
50 kg	10.0 mm	27.0 mm	6.0 mm
Material: Neoprene Rubber and Steel Shoulder Diameter (D): 20.0 mm Overall Length (B): 22.1 mm Durometer Hardness: 60
Part Number: TB-25-60SR Bonded Mounts - 50 kg - 10x27 mm - Neoprene Rubber and Steel 20 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $9.14 AUD Regular price ~~$10.96 AUD~~ Sale price $9.14 AUD Unit price per Each View the product page first if you are unsure.
TB-25-60SR --- Bonded Mounts - 50 kg - 10x27 mm - Neoprene Rubber and Steel Sale TB-25-60SR --- Bonded Mounts - 50 kg - 10x27 mm - Neoprene Rubber and Steel Regular price $9.14 AUD Regular price ~~$10.96 AUD~~ Sale price $9.14 AUD Unit price per 20 Available Now Sale
50 kg	10.2 mm	31.8 mm	14.0 mm	24.1 mm	35.0 mm
Material: Neoprene Rubber and Steel Durometer Hardness: 55
Part Number: TB-12-55BF Bonded Mounts - 50 kg - 10.2x31.8 mm - Neoprene Rubber and Steel 62 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $8.50 AUD Regular price ~~$10.20 AUD~~ Sale price $8.50 AUD Unit price per Each
50 kg	10.2 mm	31.8 mm	14.0 mm
Material: Neoprene Rubber and Steel Shoulder Diameter (D): 24.1 mm Overall Length (B): 35.0 mm Durometer Hardness: 55
Part Number: TB-12-55BF Bonded Mounts - 50 kg - 10.2x31.8 mm - Neoprene Rubber and Steel 62 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $8.50 AUD Regular price ~~$10.20 AUD~~ Sale price $8.50 AUD Unit price per Each View the product page first if you are unsure.
TB-12-55BF --- Bonded Mounts - 50 kg - 10.2x31.8 mm - Neoprene Rubber and Steel Sale TB-12-55BF --- Bonded Mounts - 50 kg - 10.2x31.8 mm - Neoprene Rubber and Steel Regular price $8.50 AUD Regular price ~~$10.20 AUD~~ Sale price $8.50 AUD Unit price per 62 Available Now Sale
56 kg	10.1 mm	27.7 mm	5.59 mm	20.9 mm	25.9 mm
Material: Rubber
Part Number: MB-0057-028 Bonded Mounts - 56 kg - 10.1x27.7 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $26.32 AUD Regular price Sale price $26.32 AUD Unit price per Each
56 kg	10.1 mm	27.7 mm	5.59 mm
Material: Rubber Shoulder Diameter (D): 20.9 mm Overall Length (B): 25.9 mm
Part Number: MB-0057-028 Bonded Mounts - 56 kg - 10.1x27.7 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $26.32 AUD Regular price Sale price $26.32 AUD Unit price per Each View the product page first if you are unsure.
MB-0057-028 --- Bonded Mounts - 56 kg - 10.1x27.7 mm - Rubber MB-0057-028 --- Bonded Mounts - 56 kg - 10.1x27.7 mm - Rubber Regular price $26.32 AUD Regular price Sale price $26.32 AUD Unit price per Out of stock! Backorder Now
100 kg	13.0 mm	43.0 mm	10.0 mm	31.0 mm	31.5 mm
Material: Neoprene Rubber and Steel Durometer Hardness: 45
Part Number: TB-45-45HK Bonded Mounts - 100 kg - 13x43 mm - Neoprene Rubber and Steel 66 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $11.32 AUD Regular price ~~$13.58 AUD~~ Sale price $11.32 AUD Unit price per Each
100 kg	13.0 mm	43.0 mm	10.0 mm
Material: Neoprene Rubber and Steel Shoulder Diameter (D): 31.0 mm Overall Length (B): 31.5 mm Durometer Hardness: 45
Part Number: TB-45-45HK Bonded Mounts - 100 kg - 13x43 mm - Neoprene Rubber and Steel 66 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $11.32 AUD Regular price ~~$13.58 AUD~~ Sale price $11.32 AUD Unit price per Each View the product page first if you are unsure.
TB-45-45HK --- Bonded Mounts - 100 kg - 13x43 mm - Neoprene Rubber and Steel Sale TB-45-45HK --- Bonded Mounts - 100 kg - 13x43 mm - Neoprene Rubber and Steel Regular price $11.32 AUD Regular price ~~$13.58 AUD~~ Sale price $11.32 AUD Unit price per 66 Available Now Sale
113 kg	13.5 mm	44.5 mm	10.4 mm	41.5 mm	31.8 mm
Material: Rubber
Part Number: MB-0113-044 (75 Pcs) Bonded Mounts - 113 kg - 13.5x44.5 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $3,273.68 AUD Regular price Sale price $3,273.68 AUD Unit price per Per 75
113 kg	13.5 mm	44.5 mm	10.4 mm
Material: Rubber Shoulder Diameter (D): 41.5 mm Overall Length (B): 31.8 mm
Part Number: MB-0113-044 (75 Pcs) Bonded Mounts - 113 kg - 13.5x44.5 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $3,273.68 AUD Regular price Sale price $3,273.68 AUD Unit price per Per 75 View the product page first if you are unsure.
MB-0113-044 (75 Pcs) --- Bonded Mounts - 113 kg - 13.5x44.5 mm - Rubber MB-0113-044 (75 Pcs) --- Bonded Mounts - 113 kg - 13.5x44.5 mm - Rubber Regular price $3,273.68 AUD Regular price Sale price $3,273.68 AUD Unit price per Out of stock! Backorder Now
158 kg	13.5 mm	50.8 mm	13.5 mm	34.3 mm	41.2 mm
Material: Rubber
Part Number: MB-0159-051 Bonded Mounts - 158 kg - 13.5x50.8 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $26.32 AUD Regular price Sale price $26.32 AUD Unit price per Each
158 kg	13.5 mm	50.8 mm	13.5 mm
Material: Rubber Shoulder Diameter (D): 34.3 mm Overall Length (B): 41.2 mm
Part Number: MB-0159-051 Bonded Mounts - 158 kg - 13.5x50.8 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $26.32 AUD Regular price Sale price $26.32 AUD Unit price per Each View the product page first if you are unsure.
MB-0159-051 --- Bonded Mounts - 158 kg - 13.5x50.8 mm - Rubber MB-0159-051 --- Bonded Mounts - 158 kg - 13.5x50.8 mm - Rubber Regular price $26.32 AUD Regular price Sale price $26.32 AUD Unit price per Out of stock! Backorder Now
200 kg	13.0 mm	49.0 mm	13.0 mm	34.0 mm	44.1 mm
Material: Neoprene Rubber and Steel Durometer Hardness: 60
Part Number: TB-50-60SR Bonded Mounts - 200 kg - 13x49 mm - Neoprene Rubber and Steel 20 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $12.86 AUD Regular price ~~$15.44 AUD~~ Sale price $12.86 AUD Unit price per Each
200 kg	13.0 mm	49.0 mm	13.0 mm
Material: Neoprene Rubber and Steel Shoulder Diameter (D): 34.0 mm Overall Length (B): 44.1 mm Durometer Hardness: 60
Part Number: TB-50-60SR Bonded Mounts - 200 kg - 13x49 mm - Neoprene Rubber and Steel 20 Available Immediately \| Further orders can be expected around Mon, Jun 02, 2025 Regular price $12.86 AUD Regular price ~~$15.44 AUD~~ Sale price $12.86 AUD Unit price per Each View the product page first if you are unsure.
TB-50-60SR --- Bonded Mounts - 200 kg - 13x49 mm - Neoprene Rubber and Steel Sale TB-50-60SR --- Bonded Mounts - 200 kg - 13x49 mm - Neoprene Rubber and Steel Regular price $12.86 AUD Regular price ~~$15.44 AUD~~ Sale price $12.86 AUD Unit price per 20 Available Now Sale
204 kg	13.5 mm	44.5 mm	10.4 mm	31.8 mm	31.8 mm
Material: Rubber
Part Number: MB-0204-044 (75 Pcs) Bonded Mounts - 204 kg - 13.5x44.5 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $2,578.95 AUD Regular price Sale price $2,578.95 AUD Unit price per Per 75
204 kg	13.5 mm	44.5 mm	10.4 mm
Material: Rubber Shoulder Diameter (D): 31.8 mm Overall Length (B): 31.8 mm
Part Number: MB-0204-044 (75 Pcs) Bonded Mounts - 204 kg - 13.5x44.5 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $2,578.95 AUD Regular price Sale price $2,578.95 AUD Unit price per Per 75 View the product page first if you are unsure.
MB-0204-044 (75 Pcs) --- Bonded Mounts - 204 kg - 13.5x44.5 mm - Rubber MB-0204-044 (75 Pcs) --- Bonded Mounts - 204 kg - 13.5x44.5 mm - Rubber Regular price $2,578.95 AUD Regular price Sale price $2,578.95 AUD Unit price per Out of stock! Backorder Now
272 kg	13.5 mm	50.8 mm	13.5 mm	34.3 mm	41.2 mm
Material: Rubber
Part Number: MB-0272-051 Bonded Mounts - 272 kg - 13.5x50.8 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $26.59 AUD Regular price Sale price $26.59 AUD Unit price per Each
272 kg	13.5 mm	50.8 mm	13.5 mm
Material: Rubber Shoulder Diameter (D): 34.3 mm Overall Length (B): 41.2 mm
Part Number: MB-0272-051 Bonded Mounts - 272 kg - 13.5x50.8 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $26.59 AUD Regular price Sale price $26.59 AUD Unit price per Each View the product page first if you are unsure.
MB-0272-051 --- Bonded Mounts - 272 kg - 13.5x50.8 mm - Rubber MB-0272-051 --- Bonded Mounts - 272 kg - 13.5x50.8 mm - Rubber Regular price $26.59 AUD Regular price Sale price $26.59 AUD Unit price per Out of stock! Backorder Now
340 kg	16.3 mm	75.5 mm	20.6 mm	50.3 mm	64.0 mm
Material: Neoprene Rubber and Steel
Part Number: TB-75 Bonded Mounts - 340 kg - 16.3x75.5 mm - Neoprene Rubber and Steel 44 Available Immediately \| Further orders can be expected around Mon, Jun 16, 2025 Regular price $46.95 AUD Regular price Sale price $46.95 AUD Unit price per Each
340 kg	16.3 mm	75.5 mm	20.6 mm
Material: Neoprene Rubber and Steel Shoulder Diameter (D): 50.3 mm Overall Length (B): 64.0 mm
Part Number: TB-75 Bonded Mounts - 340 kg - 16.3x75.5 mm - Neoprene Rubber and Steel 44 Available Immediately \| Further orders can be expected around Mon, Jun 16, 2025 Regular price $46.95 AUD Regular price Sale price $46.95 AUD Unit price per Each View the product page first if you are unsure.
TB-75 --- Bonded Mounts - 340 kg - 16.3x75.5 mm - Neoprene Rubber and Steel TB-75 --- Bonded Mounts - 340 kg - 16.3x75.5 mm - Neoprene Rubber and Steel Regular price $46.95 AUD Regular price Sale price $46.95 AUD Unit price per 44 Available Now
407 kg	19.6 mm	95.3 mm	23.9 mm	52.3 mm	67.6 mm
Material: Rubber
Part Number: CBSU407-2019 Bonded Mounts - 407 kg - 19.6x95.3 mm - Rubber 5 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $25.00 AUD Regular price ~~$47.50 AUD~~ Sale price $25.00 AUD Unit price per Each
407 kg	19.6 mm	95.3 mm	23.9 mm
Material: Rubber Shoulder Diameter (D): 52.3 mm Overall Length (B): 67.6 mm
Part Number: CBSU407-2019 Bonded Mounts - 407 kg - 19.6x95.3 mm - Rubber 5 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $25.00 AUD Regular price ~~$47.50 AUD~~ Sale price $25.00 AUD Unit price per Each
CBSU407-2019 --- Bonded Mounts - 407 kg - 19.6x95.3 mm - Rubber Sale CBSU407-2019 --- Bonded Mounts - 407 kg - 19.6x95.3 mm - Rubber Regular price $25.00 AUD Regular price ~~$47.50 AUD~~ Sale price $25.00 AUD Unit price per 5 Available Now Sale
453 kg	16.5 mm	63.5 mm	15.75 mm	41.1 mm	50.8 mm
Material: Rubber
Part Number: MB-0454-064 Bonded Mounts - 453 kg - 16.5x63.5 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $43.05 AUD Regular price Sale price $43.05 AUD Unit price per Each
453 kg	16.5 mm	63.5 mm	15.75 mm
Material: Rubber Shoulder Diameter (D): 41.1 mm Overall Length (B): 50.8 mm
Part Number: MB-0454-064 Bonded Mounts - 453 kg - 16.5x63.5 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $43.05 AUD Regular price Sale price $43.05 AUD Unit price per Each View the product page first if you are unsure.
MB-0454-064 --- Bonded Mounts - 453 kg - 16.5x63.5 mm - Rubber MB-0454-064 --- Bonded Mounts - 453 kg - 16.5x63.5 mm - Rubber Regular price $43.05 AUD Regular price Sale price $43.05 AUD Unit price per Out of stock! Backorder Now
635 kg	16.5 mm	75.7 mm	20.6 mm	50.3 mm	56.4 mm
Material: Rubber
Part Number: MB-0635-076 (40 Pcs) Bonded Mounts - 635 kg - 16.5x75.7 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $2,147.32 AUD Regular price Sale price $2,147.32 AUD Unit price per Per 40
635 kg	16.5 mm	75.7 mm	20.6 mm
Material: Rubber Shoulder Diameter (D): 50.3 mm Overall Length (B): 56.4 mm
Part Number: MB-0635-076 (40 Pcs) Bonded Mounts - 635 kg - 16.5x75.7 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $2,147.32 AUD Regular price Sale price $2,147.32 AUD Unit price per Per 40 View the product page first if you are unsure.
MB-0635-076 (40 Pcs) --- Bonded Mounts - 635 kg - 16.5x75.7 mm - Rubber MB-0635-076 (40 Pcs) --- Bonded Mounts - 635 kg - 16.5x75.7 mm - Rubber Regular price $2,147.32 AUD Regular price Sale price $2,147.32 AUD Unit price per Out of stock! Backorder Now
635 kg	20.4 mm	95.0 mm	25.4 mm	56.6 mm	63.0 mm
Material: Rubber
Part Number: MB-0635-095 (45 Pcs) Bonded Mounts - 635 kg - 20.4x95 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $3,977.86 AUD Regular price Sale price $3,977.86 AUD Unit price per Per 45
635 kg	20.4 mm	95.0 mm	25.4 mm
Material: Rubber Shoulder Diameter (D): 56.6 mm Overall Length (B): 63.0 mm
Part Number: MB-0635-095 (45 Pcs) Bonded Mounts - 635 kg - 20.4x95 mm - Rubber Out of Stock \| Backorder Now \| Orders can be expected around Wed, Apr 30, 2025 Regular price $3,977.86 AUD Regular price Sale price $3,977.86 AUD Unit price per Per 45 View the product page first if you are unsure.
MB-0635-095 (45 Pcs) --- Bonded Mounts - 635 kg - 20.4x95 mm - Rubber MB-0635-095 (45 Pcs) --- Bonded Mounts - 635 kg - 20.4x95 mm - Rubber Regular price $3,977.86 AUD Regular price Sale price $3,977.86 AUD Unit price per Out of stock! Backorder Now
