A selection of Rail Systems Type 2 Rails Linear. Match with carriage by size column 1. Thomson 500 Series provide long life, exceptional rigidity, high dynamic and static load capabilities in all directions.

  • Linear rails to suit type 2 carriages.
  • Straight rails through advanced grinding technologies. Simple installation and greater accuracy with joint-free rails up to 6 meters
  • Accommodates high moment loads and maintains high running accuracy. Improved machine accuracies and rigidity resulting in reduced vibration and extended machine and tool life.
  • Rails are subjected to multiple straightening processes during and after grinding of the ball paths to ensure straight and accurate rails.
