Housings - Flanged - Offset Cast Iron

Housings -> Flanged -> Offset Cast Iron

There are 3 products in the sub-categories of Housings - Flanged - Offset Cast Iron. Browse the Housings - Flanged - Offset Cast Iron products table.

Category Details

A selection of Offset Cast Iron Flanged Housings. Lubrication Groove.

  • An expanded range may be available on special order. Please enquire.
  • Bearings sold separately.
  • Larger sizes available on request.
  • Use with steel bearing inserts for cast iron housings.

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Housings - Flanged - Offset Cast Iron category on the Small Parts & Bearings online store.
Height (H) Length (L) Width - Assembled (W) Bolt Hole Centres (J) Base Width (A1) Bearing Width (B) Indicative
Height (H)
110.000
mm

(Equiv. 4.331 in.)
Length (L)
62.000
mm

(Equiv. 2.441 in.)
Width - Assembled (W)
33.300
mm

(Equiv. 1.311 in.)
Bolt Hole Centres (J)
32.000
mm
Base Width (A1)
13.000
mm
Bearing Width (B)
31.000
mm
Flanged Housings - 110x62x33.3 mm
Material: Cast Iron    To Suit Bearing: UC201 - UC202 - UC203 - UC204    Bolt Hole Size (s): 10.000 mm    Offset Width (Ow): 52.000 mm
Part Number: FK204
Flanged Housings - 110x62x33.3 mm Offset Cast Iron - Cast Iron Housing
Out of Stock | Backorder Now | Orders can be expected around Tue, Sep 09, 2025
$24.14 AUD
$28.96 AUD $24.14 AUD
Each
Quantity Required

Backorder: Out of Stock.
Height (H) Length (L) Width - Assembled (W) Bolt Hole Centres (J) Indicative
Height (H)
110.000
mm

(Equiv. 4.331 in.)
Length (L)
62.000
mm

(Equiv. 2.441 in.)
Width - Assembled (W)
33.300
mm

(Equiv. 1.311 in.)
Bolt Hole Centres (J)
32.000
mm
Flanged Housings - 110x62x33.3 mm
Material: Cast Iron    Base Width (A1): 13.000 mm    Bearing Width (B): 31.000 mm    To Suit Bearing: UC201 - UC202 - UC203 - UC204    Bolt Hole Size (s): 10.000 mm    Offset Width (Ow): 52.000 mm
Part Number: FK204
Flanged Housings - 110x62x33.3 mm Offset Cast Iron - Cast Iron Housing
Out of Stock | Backorder Now | Orders can be expected around Tue, Sep 09, 2025
$24.14 AUD
$28.96 AUD $24.14 AUD
Each
Quantity Required

Backorder: Out of Stock.
Height (H)
116.000
mm

(Equiv. 4.567 in.)
Length (L)
68.000
mm

(Equiv. 2.677 in.)
Width - Assembled (W)
35.700
mm

(Equiv. 1.406 in.)
Bolt Hole Centres (J)
34.000
mm
Base Width (A1)
13.000
mm
Bearing Width (B)
34.000
mm
Flanged Housings - 116x68x35.7 mm
Material: Cast Iron    To Suit Bearing: UC205    Bolt Hole Size (s): 10.000 mm    Offset Width (Ow): 56.000 mm
Part Number: FK205
Flanged Housings - 116x68x35.7 mm Offset Cast Iron - Cast Iron Housing
Out of Stock | Backorder Now | Orders can be expected around Tue, Sep 09, 2025
$23.05 AUD
$27.65 AUD $23.05 AUD
Each
Quantity Required

Backorder: Out of Stock.
Height (H)
116.000
mm

(Equiv. 4.567 in.)
Length (L)
68.000
mm

(Equiv. 2.677 in.)
Width - Assembled (W)
35.700
mm

(Equiv. 1.406 in.)
Bolt Hole Centres (J)
34.000
mm
Flanged Housings - 116x68x35.7 mm
Material: Cast Iron    Base Width (A1): 13.000 mm    Bearing Width (B): 34.000 mm    To Suit Bearing: UC205    Bolt Hole Size (s): 10.000 mm    Offset Width (Ow): 56.000 mm
Part Number: FK205
Flanged Housings - 116x68x35.7 mm Offset Cast Iron - Cast Iron Housing
Out of Stock | Backorder Now | Orders can be expected around Tue, Sep 09, 2025
$23.05 AUD
$27.65 AUD $23.05 AUD
Each
Quantity Required

Backorder: Out of Stock.
Height (H)
130.000
mm

(Equiv. 5.118 in.)
Length (L)
78.000
mm

(Equiv. 3.071 in.)
Width - Assembled (W)
40.200
mm

(Equiv. 1.583 in.)
Bolt Hole Centres (J)
40.000
mm
Base Width (A1)
13.000
mm
Bearing Width (B)
38.100
mm
Flanged Housings - 130x78x40.2 mm
Material: Cast Iron    To Suit Bearing: UC206    Bolt Hole Size (s): 10.000 mm    Offset Width (Ow): 65.000 mm
Part Number: FK206
Flanged Housings - 130x78x40.2 mm Offset Cast Iron - Cast Iron Housing
Out of Stock | Backorder Now | Orders can be expected around Tue, Sep 09, 2025
$29.50 AUD
$35.40 AUD $29.50 AUD
Each
Quantity Required

Backorder: Out of Stock.
Height (H)
130.000
mm

(Equiv. 5.118 in.)
Length (L)
78.000
mm

(Equiv. 3.071 in.)
Width - Assembled (W)
40.200
mm

(Equiv. 1.583 in.)
Bolt Hole Centres (J)
40.000
mm
Flanged Housings - 130x78x40.2 mm
Material: Cast Iron    Base Width (A1): 13.000 mm    Bearing Width (B): 38.100 mm    To Suit Bearing: UC206    Bolt Hole Size (s): 10.000 mm    Offset Width (Ow): 65.000 mm
Part Number: FK206
Flanged Housings - 130x78x40.2 mm Offset Cast Iron - Cast Iron Housing
Out of Stock | Backorder Now | Orders can be expected around Tue, Sep 09, 2025
$29.50 AUD
$35.40 AUD $29.50 AUD
Each
Quantity Required

Backorder: Out of Stock.
