Gears - Spur - Hubbed - Module 1 - Plastic

Gears -> Spur -> Hubbed -> Module 1 -> Plastic

There is only 1 product in the sub-categories of Gears - Spur - Hubbed - Module 1 - Plastic. Browse the Gears - Spur - Hubbed - Module 1 - Plastic products table.

Category Details

A selection of Plastic Module 1 Hubbed Spur Gears. PCD in mm = No. of Teeth. 20 Degree Pressure Angle

  • There are more items available in this range than currently listed. Please enquire if you have special requirements. Expanded range includes hardened gears, stainless steel, antibacklash, and special bore sizes.
  • Be sure to match the pitch type and tooth angle when selecting spur gears.
  • An expanded range may be available on special order. Please enquire.
  • The diameter increases by 1mm per tooth
  • Module 1. Approximately 3.14mm between the teeth.

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Gears - Spur - Hubbed - Module 1 - Plastic category on the Small Parts & Bearings online store.
Number of Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Face Width (FW) Type Indicative
Spur Gears - 120 tooth - 120x12 mm Hubbed - Acetal - No Insert Gear
Number of Teeth
120
Pitch Circle Diameter (PD)
120.00
mm
Bore (d)
12.000
mm
Outside Diameter (OD)
122.000
mm
Face Width (FW)
9.000
mm
Type
Hubbed
Spur Gears - 120 tooth - 120x12 mm Hubbed - Acetal - No Insert Gear
Material: Acetal - No Insert    Hub Diameter (D1): 24.00    Hub Projection (HL): 9.00    Locking Method: None    Quality: Commercial - Molded
Part Number: G120B-120-M1-090-120-A-PD (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity
Number of Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Indicative
Spur Gears - 120 tooth - 120x12 mm Hubbed - Acetal - No Insert Gear
Number of Teeth
120
Pitch Circle Diameter (PD)
120.00
mm
Bore (d)
12.000
mm
Outside Diameter (OD)
122.000
mm
Spur Gears - 120 tooth - 120x12 mm Hubbed - Acetal - No Insert Gear
Material: Acetal - No Insert    Face Width (FW): 9.000 mm    Type: Hubbed    Hub Diameter (D1): 24.00    Hub Projection (HL): 9.00    Locking Method: None    Quality: Commercial - Molded
Part Number: G120B-120-M1-090-120-A-PD (Each)
Contact Us | Special Order Only - Please contact us if you need a large quantity | Backorder now for delivery around Tue, Apr 03, 2029
