A selection of Clamp Type Short Series Helical Couplings. Zero backlash, one piece construction

  • An expanded range may be available on special order. Please enquire.
  • Maximises torsional stiffness without inducing high bearing loads
  • Over 50,000,000 test cycles at rated load and 80 percent offset without failure
  • Maintenance Free. Recommended temperature range minus 80 oC to plus 80 Deg C

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Couplings - Helical - Short Series - Clamp Type category on the Small Parts & Bearings online store.
Bore (B1) Bore (B2) OD (D) / Clearance Dia (OH) Length (L) Working Torque Maximum Speed Indicative
Helical Couplings - 1.950 / 1.950 mm Pilot Bore - Max 3mm - 13 / 14.5 Short Series - Aluminium 7075-T6 Coupling
Bore (B1)
1.950 / 1.950
mm
+ 0.020 / - 0.000
(Equiv. 0.077 in.)
Bore (B2)
Pilot Bore - Max 3mm

+ 0.020 / - 0.000
OD (D) / Clearance Dia (OH)
13 / 14.5
mm
+/- 0.13
(Equiv. 0.512 in.)
Length (L)
16.8
mm
+/- 0.13
Working Torque
0.55
N.m
Maximum Speed
12000
RPM
Helical Couplings - 1.950 / 1.950 mm Pilot Bore - Max 3mm - 13 / 14.5 - Aluminium 7075-T6
Material: Aluminium 7075-T6    Hub Length (E): 5.00 mm    Torsional Stiffness: 45.0 Nm/rad    Parallel Misalignment: 0.08 mm    Angular Misalignment: 2.5 Deg    Axial Misalignment: +/-0.30 mm    Max Inertia: 1.00 g/cm Sq
Deleted Item. Available while stocks last.
Part Number: CP-020-020-13-017-H-RFC-AL (Each)
1 Available Now | Item Discontinued - Up to 1 may be ordered online. No backorders. Please contact us if you need a larger quantity
$40.00 AUD
$76.00 AUD $40.00 AUD
Each
Excludes GST and overseas Taxes & Duties
Quantity Required

1 Available Now. These are priced to quit. Please contact us for a quote if you require more.
