Collection: Bushes - Unflanged - Plastic - Iglidur X

Bushes -> Unflanged -> Plastic -> Iglidur X

There are 126 products in the sub-categories of Bushes - Unflanged - Plastic - Iglidur X. Scroll down or follow the link to Bushes - Unflanged - Plastic - Iglidur X in the products table to see all these items combined into a handy table with filters.

Category Details

A selection of Iglidur X Plastic Unflanged Bushes. Very high temperature. Extreme chemical resistance. High compressive strength. Low water absorption.

An expanded range may be available on special order. Please enquire.
Specific Gravity 1.44 g/cm3.
Operating Temp 315 C short term / 250 C long term.
Tensile Strength at 20 Deg C = 170 Mpa.
Hardness 85 Shore D (DIN53505).
Bushing bore tolerance shown is after a H7 press fit.

Miniature Bearings Australia - MBA Minibearings

Additional resources:

A more concise listing may be found in the Bushes - Unflanged - Plastic - Iglidur X category on the Small Parts & Bearings online store.

Nominal Inside Diameter (d)	Nominal Outside Diameter (D)	Length (s)	Indicative Image
Nominal Inside Diameter (d) 2.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.079 in.)	Nominal Outside Diameter (D) 3.500 mm (Equiv. 0.138 in.)	Length (s) 3.000 mm _{+ 0.000 / - 0.140} (Equiv. 0.118 in.)
Material: Iglidur X
Part Number: BP0020-0035-0030-PX (10 Pcs) Unflanged Bushes - 2x3.5x3 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $128.14 AUD Regular price ~~$153.76 AUD~~ Sale price $128.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d)	Nominal Outside Diameter (D)	Length (s)	Indicative Image
Nominal Inside Diameter (d) 2.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.079 in.)	Nominal Outside Diameter (D) 3.500 mm (Equiv. 0.138 in.)	Length (s) 3.000 mm _{+ 0.000 / - 0.140} (Equiv. 0.118 in.)
Material: Iglidur X
Part Number: BP0020-0035-0030-PX (10 Pcs) Unflanged Bushes - 2x3.5x3 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $128.14 AUD Regular price ~~$153.76 AUD~~ Sale price $128.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0020-0035-0030-PX (10 Pcs) --- Unflanged Bushes - 2x3.5x3 mm Plastic - Iglidur X Bush Sale BP0020-0035-0030-PX (10 Pcs) --- Unflanged Bushes - 2x3.5x3 mm Plastic - Iglidur X Bush Regular price $128.14 AUD Regular price ~~$153.76 AUD~~ Sale price $128.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 3.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.118 in.)	Nominal Outside Diameter (D) 4.500 mm (Equiv. 0.177 in.)	Length (s) 3.000 mm _{+ 0.000 / - 0.140} (Equiv. 0.118 in.)
Material: Iglidur X
Part Number: BP0030-0045-0030-PX (10 Pcs) Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 3.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.118 in.)	Nominal Outside Diameter (D) 4.500 mm (Equiv. 0.177 in.)	Length (s) 3.000 mm _{+ 0.000 / - 0.140} (Equiv. 0.118 in.)
Material: Iglidur X
Part Number: BP0030-0045-0030-PX (10 Pcs) Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0030-0045-0030-PX (10 Pcs) --- Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur X Bush Sale BP0030-0045-0030-PX (10 Pcs) --- Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur X Bush Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 3.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.118 in.)	Nominal Outside Diameter (D) 4.500 mm (Equiv. 0.177 in.)	Length (s) 6.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.236 in.)
Material: Iglidur X
Part Number: BP0030-0045-0060-PX (10 Pcs) Unflanged Bushes - 3x4.5x6 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $130.86 AUD Regular price ~~$157.04 AUD~~ Sale price $130.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 3.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.118 in.)	Nominal Outside Diameter (D) 4.500 mm (Equiv. 0.177 in.)	Length (s) 6.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.236 in.)
Material: Iglidur X
Part Number: BP0030-0045-0060-PX (10 Pcs) Unflanged Bushes - 3x4.5x6 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $130.86 AUD Regular price ~~$157.04 AUD~~ Sale price $130.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0030-0045-0060-PX (10 Pcs) --- Unflanged Bushes - 3x4.5x6 mm Plastic - Iglidur X Bush Sale BP0030-0045-0060-PX (10 Pcs) --- Unflanged Bushes - 3x4.5x6 mm Plastic - Iglidur X Bush Regular price $130.86 AUD Regular price ~~$157.04 AUD~~ Sale price $130.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 3.175 mm _{+ 0.010 / + 0.058} (Equiv. 0.125 in.)	Nominal Outside Diameter (D) 4.763 mm (Equiv. 0.188 in.)	Length (s) 4.763 mm _{+ 0.000 / - 0.180} (Equiv. 0.188 in.)
Material: Iglidur X
Part Number: BP0032-0048-0048-PX (10 Pcs) Unflanged Bushes - 3.175x4.763x4.763 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $77.77 AUD Regular price ~~$93.33 AUD~~ Sale price $77.77 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 3.175 mm _{+ 0.010 / + 0.058} (Equiv. 0.125 in.)	Nominal Outside Diameter (D) 4.763 mm (Equiv. 0.188 in.)	Length (s) 4.763 mm _{+ 0.000 / - 0.180} (Equiv. 0.188 in.)
Material: Iglidur X
Part Number: BP0032-0048-0048-PX (10 Pcs) Unflanged Bushes - 3.175x4.763x4.763 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $77.77 AUD Regular price ~~$93.33 AUD~~ Sale price $77.77 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0032-0048-0048-PX (10 Pcs) --- Unflanged Bushes - 3.175x4.763x4.763 mm Plastic - Iglidur X Bush Sale BP0032-0048-0048-PX (10 Pcs) --- Unflanged Bushes - 3.175x4.763x4.763 mm Plastic - Iglidur X Bush Regular price $77.77 AUD Regular price ~~$93.33 AUD~~ Sale price $77.77 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 3.175 mm _{+ 0.010 / + 0.058} (Equiv. 0.125 in.)	Nominal Outside Diameter (D) 4.763 mm (Equiv. 0.188 in.)	Length (s) 7.938 mm _{+ 0.000 / - 0.220} (Equiv. 0.313 in.)
Material: Iglidur X
Part Number: BP0032-0048-0079-PX (10 Pcs) Unflanged Bushes - 3.175x4.763x7.938 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $77.77 AUD Regular price ~~$93.33 AUD~~ Sale price $77.77 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 3.175 mm _{+ 0.010 / + 0.058} (Equiv. 0.125 in.)	Nominal Outside Diameter (D) 4.763 mm (Equiv. 0.188 in.)	Length (s) 7.938 mm _{+ 0.000 / - 0.220} (Equiv. 0.313 in.)
Material: Iglidur X
Part Number: BP0032-0048-0079-PX (10 Pcs) Unflanged Bushes - 3.175x4.763x7.938 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $77.77 AUD Regular price ~~$93.33 AUD~~ Sale price $77.77 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0032-0048-0079-PX (10 Pcs) --- Unflanged Bushes - 3.175x4.763x7.938 mm Plastic - Iglidur X Bush Sale BP0032-0048-0079-PX (10 Pcs) --- Unflanged Bushes - 3.175x4.763x7.938 mm Plastic - Iglidur X Bush Regular price $77.77 AUD Regular price ~~$93.33 AUD~~ Sale price $77.77 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 3.175 mm _{+ 0.010 / + 0.058} (Equiv. 0.125 in.)	Nominal Outside Diameter (D) 4.763 mm (Equiv. 0.188 in.)	Length (s) 9.525 mm _{+ 0.000 / - 0.220} (Equiv. 0.375 in.)
Material: Iglidur X
Part Number: BP0032-0048-0095-PX (10 Pcs) Unflanged Bushes - 3.175x4.763x9.525 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $80.50 AUD Regular price ~~$96.60 AUD~~ Sale price $80.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 3.175 mm _{+ 0.010 / + 0.058} (Equiv. 0.125 in.)	Nominal Outside Diameter (D) 4.763 mm (Equiv. 0.188 in.)	Length (s) 9.525 mm _{+ 0.000 / - 0.220} (Equiv. 0.375 in.)
Material: Iglidur X
Part Number: BP0032-0048-0095-PX (10 Pcs) Unflanged Bushes - 3.175x4.763x9.525 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $80.50 AUD Regular price ~~$96.60 AUD~~ Sale price $80.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0032-0048-0095-PX (10 Pcs) --- Unflanged Bushes - 3.175x4.763x9.525 mm Plastic - Iglidur X Bush Sale BP0032-0048-0095-PX (10 Pcs) --- Unflanged Bushes - 3.175x4.763x9.525 mm Plastic - Iglidur X Bush Regular price $80.50 AUD Regular price ~~$96.60 AUD~~ Sale price $80.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 4.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.157 in.)	Nominal Outside Diameter (D) 5.500 mm (Equiv. 0.217 in.)	Length (s) 4.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.157 in.)
Material: Iglidur X
Part Number: BP0040-0055-0040-PX (10 Pcs) Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 4.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.157 in.)	Nominal Outside Diameter (D) 5.500 mm (Equiv. 0.217 in.)	Length (s) 4.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.157 in.)
Material: Iglidur X
Part Number: BP0040-0055-0040-PX (10 Pcs) Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0040-0055-0040-PX (10 Pcs) --- Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur X Bush Sale BP0040-0055-0040-PX (10 Pcs) --- Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur X Bush Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 4.763 mm _{+ 0.000 / - 0.180} (Equiv. 0.188 in.)
Material: Iglidur X
Part Number: BP0048-0064-0048-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x4.763 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 4.763 mm _{+ 0.000 / - 0.180} (Equiv. 0.188 in.)
Material: Iglidur X
Part Number: BP0048-0064-0048-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x4.763 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0048-0064-0048-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x4.763 mm Plastic - Iglidur X Bush Sale BP0048-0064-0048-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x4.763 mm Plastic - Iglidur X Bush Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 6.350 mm _{+ 0.000 / - 0.220} (Equiv. 0.25 in.)
Material: Iglidur X
Part Number: BP0048-0064-0064-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x6.35 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 6.350 mm _{+ 0.000 / - 0.220} (Equiv. 0.25 in.)
Material: Iglidur X
Part Number: BP0048-0064-0064-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x6.35 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0048-0064-0064-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x6.35 mm Plastic - Iglidur X Bush Sale BP0048-0064-0064-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x6.35 mm Plastic - Iglidur X Bush Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 9.525 mm _{+ 0.000 / - 0.220} (Equiv. 0.375 in.)
Material: Iglidur X
Part Number: BP0048-0064-0095-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x9.525 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $88.77 AUD Regular price ~~$106.53 AUD~~ Sale price $88.77 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 9.525 mm _{+ 0.000 / - 0.220} (Equiv. 0.375 in.)
Material: Iglidur X
Part Number: BP0048-0064-0095-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x9.525 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $88.77 AUD Regular price ~~$106.53 AUD~~ Sale price $88.77 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0048-0064-0095-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x9.525 mm Plastic - Iglidur X Bush Sale BP0048-0064-0095-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x9.525 mm Plastic - Iglidur X Bush Regular price $88.77 AUD Regular price ~~$106.53 AUD~~ Sale price $88.77 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.270} (Equiv. 0.5 in.)
Material: Iglidur X
Part Number: BP0048-0064-0127-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x12.7 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 4.763 mm _{+ 0.010 / + 0.058} (Equiv. 0.188 in.)	Nominal Outside Diameter (D) 6.350 mm (Equiv. 0.25 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.270} (Equiv. 0.5 in.)
Material: Iglidur X
Part Number: BP0048-0064-0127-PX (10 Pcs) Unflanged Bushes - 4.763x6.35x12.7 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0048-0064-0127-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x12.7 mm Plastic - Iglidur X Bush Sale BP0048-0064-0127-PX (10 Pcs) --- Unflanged Bushes - 4.763x6.35x12.7 mm Plastic - Iglidur X Bush Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 3.500 mm _{+ 0.000 / - 0.180} (Equiv. 0.138 in.)
Material: Iglidur X
Part Number: BP0050-0070-0035-PX (10 Pcs) Unflanged Bushes - 5x7x3.5 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 3.500 mm _{+ 0.000 / - 0.180} (Equiv. 0.138 in.)
Material: Iglidur X
Part Number: BP0050-0070-0035-PX (10 Pcs) Unflanged Bushes - 5x7x3.5 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0050-0070-0035-PX (10 Pcs) --- Unflanged Bushes - 5x7x3.5 mm Plastic - Iglidur X Bush Sale BP0050-0070-0035-PX (10 Pcs) --- Unflanged Bushes - 5x7x3.5 mm Plastic - Iglidur X Bush Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 5.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.197 in.)
Material: Iglidur X
Part Number: BP0050-0070-0050-PX (10 Pcs) Unflanged Bushes - 5x7x5 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $133.59 AUD Regular price ~~$160.31 AUD~~ Sale price $133.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 5.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.197 in.)
Material: Iglidur X
Part Number: BP0050-0070-0050-PX (10 Pcs) Unflanged Bushes - 5x7x5 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $133.59 AUD Regular price ~~$160.31 AUD~~ Sale price $133.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0050-0070-0050-PX (10 Pcs) --- Unflanged Bushes - 5x7x5 mm Plastic - Iglidur X Bush Sale BP0050-0070-0050-PX (10 Pcs) --- Unflanged Bushes - 5x7x5 mm Plastic - Iglidur X Bush Regular price $133.59 AUD Regular price ~~$160.31 AUD~~ Sale price $133.59 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)
Material: Iglidur X
Part Number: BP0050-0070-0080-PX (10 Pcs) Unflanged Bushes - 5x7x8 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $133.59 AUD Regular price ~~$160.31 AUD~~ Sale price $133.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)
Material: Iglidur X
Part Number: BP0050-0070-0080-PX (10 Pcs) Unflanged Bushes - 5x7x8 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $133.59 AUD Regular price ~~$160.31 AUD~~ Sale price $133.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0050-0070-0080-PX (10 Pcs) --- Unflanged Bushes - 5x7x8 mm Plastic - Iglidur X Bush Sale BP0050-0070-0080-PX (10 Pcs) --- Unflanged Bushes - 5x7x8 mm Plastic - Iglidur X Bush Regular price $133.59 AUD Regular price ~~$160.31 AUD~~ Sale price $133.59 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 6.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.236 in.)
Material: Iglidur X
Part Number: BP0060-0080-0060-PX (10 Pcs) Unflanged Bushes - 6x8x6 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $134.95 AUD Regular price ~~$161.95 AUD~~ Sale price $134.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 6.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.236 in.)
Material: Iglidur X
Part Number: BP0060-0080-0060-PX (10 Pcs) Unflanged Bushes - 6x8x6 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $134.95 AUD Regular price ~~$161.95 AUD~~ Sale price $134.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0060-0080-0060-PX (10 Pcs) --- Unflanged Bushes - 6x8x6 mm Plastic - Iglidur X Bush Sale BP0060-0080-0060-PX (10 Pcs) --- Unflanged Bushes - 6x8x6 mm Plastic - Iglidur X Bush Regular price $134.95 AUD Regular price ~~$161.95 AUD~~ Sale price $134.95 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)
Material: Iglidur X
Part Number: BP0060-0080-0080-PX (10 Pcs) Unflanged Bushes - 6x8x8 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $136.32 AUD Regular price ~~$163.58 AUD~~ Sale price $136.32 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)
Material: Iglidur X
Part Number: BP0060-0080-0080-PX (10 Pcs) Unflanged Bushes - 6x8x8 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $136.32 AUD Regular price ~~$163.58 AUD~~ Sale price $136.32 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0060-0080-0080-PX (10 Pcs) --- Unflanged Bushes - 6x8x8 mm Plastic - Iglidur X Bush Sale BP0060-0080-0080-PX (10 Pcs) --- Unflanged Bushes - 6x8x8 mm Plastic - Iglidur X Bush Regular price $136.32 AUD Regular price ~~$163.58 AUD~~ Sale price $136.32 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur X
Part Number: BP0060-0080-0100-PX (10 Pcs) Unflanged Bushes - 6x8x10 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur X
Part Number: BP0060-0080-0100-PX (10 Pcs) Unflanged Bushes - 6x8x10 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0060-0080-0100-PX (10 Pcs) --- Unflanged Bushes - 6x8x10 mm Plastic - Iglidur X Bush Sale BP0060-0080-0100-PX (10 Pcs) --- Unflanged Bushes - 6x8x10 mm Plastic - Iglidur X Bush Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 13.800 mm _{+ 0.000 / - 0.270} (Equiv. 0.543 in.)
Material: Iglidur X
Part Number: BP0060-0080-0138-PX (10 Pcs) Unflanged Bushes - 6x8x13.8 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 13.800 mm _{+ 0.000 / - 0.270} (Equiv. 0.543 in.)
Material: Iglidur X
Part Number: BP0060-0080-0138-PX (10 Pcs) Unflanged Bushes - 6x8x13.8 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0060-0080-0138-PX (10 Pcs) --- Unflanged Bushes - 6x8x13.8 mm Plastic - Iglidur X Bush Sale BP0060-0080-0138-PX (10 Pcs) --- Unflanged Bushes - 6x8x13.8 mm Plastic - Iglidur X Bush Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.350 mm _{+ 0.013 / + 0.071} (Equiv. 0.25 in.)	Nominal Outside Diameter (D) 7.938 mm (Equiv. 0.313 in.)	Length (s) 6.350 mm _{+ 0.000 / - 0.220} (Equiv. 0.25 in.)
Material: Iglidur X
Part Number: BP0064-0079-0064-PX (10 Pcs) Unflanged Bushes - 6.35x7.938x6.35 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.350 mm _{+ 0.013 / + 0.071} (Equiv. 0.25 in.)	Nominal Outside Diameter (D) 7.938 mm (Equiv. 0.313 in.)	Length (s) 6.350 mm _{+ 0.000 / - 0.220} (Equiv. 0.25 in.)
Material: Iglidur X
Part Number: BP0064-0079-0064-PX (10 Pcs) Unflanged Bushes - 6.35x7.938x6.35 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0064-0079-0064-PX (10 Pcs) --- Unflanged Bushes - 6.35x7.938x6.35 mm Plastic - Iglidur X Bush Sale BP0064-0079-0064-PX (10 Pcs) --- Unflanged Bushes - 6.35x7.938x6.35 mm Plastic - Iglidur X Bush Regular price $87.41 AUD Regular price ~~$104.89 AUD~~ Sale price $87.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.350 mm _{+ 0.013 / + 0.071} (Equiv. 0.25 in.)	Nominal Outside Diameter (D) 7.938 mm (Equiv. 0.313 in.)	Length (s) 9.525 mm _{+ 0.000 / - 0.220} (Equiv. 0.375 in.)
Material: Iglidur X
Part Number: BP0064-0079-0095-PX (10 Pcs) Unflanged Bushes - 6.35x7.938x9.525 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.350 mm _{+ 0.013 / + 0.071} (Equiv. 0.25 in.)	Nominal Outside Diameter (D) 7.938 mm (Equiv. 0.313 in.)	Length (s) 9.525 mm _{+ 0.000 / - 0.220} (Equiv. 0.375 in.)
Material: Iglidur X
Part Number: BP0064-0079-0095-PX (10 Pcs) Unflanged Bushes - 6.35x7.938x9.525 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0064-0079-0095-PX (10 Pcs) --- Unflanged Bushes - 6.35x7.938x9.525 mm Plastic - Iglidur X Bush Sale BP0064-0079-0095-PX (10 Pcs) --- Unflanged Bushes - 6.35x7.938x9.525 mm Plastic - Iglidur X Bush Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.350 mm _{+ 0.013 / + 0.071} (Equiv. 0.25 in.)	Nominal Outside Diameter (D) 7.938 mm (Equiv. 0.313 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.270} (Equiv. 0.5 in.)
Material: Iglidur X
Part Number: BP0064-0079-0127-PX (10 Pcs) Unflanged Bushes - 6.35x7.938x12.7 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.350 mm _{+ 0.013 / + 0.071} (Equiv. 0.25 in.)	Nominal Outside Diameter (D) 7.938 mm (Equiv. 0.313 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.270} (Equiv. 0.5 in.)
Material: Iglidur X
Part Number: BP0064-0079-0127-PX (10 Pcs) Unflanged Bushes - 6.35x7.938x12.7 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0064-0079-0127-PX (10 Pcs) --- Unflanged Bushes - 6.35x7.938x12.7 mm Plastic - Iglidur X Bush Sale BP0064-0079-0127-PX (10 Pcs) --- Unflanged Bushes - 6.35x7.938x12.7 mm Plastic - Iglidur X Bush Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 7.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.276 in.)	Nominal Outside Diameter (D) 9.000 mm (Equiv. 0.354 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur X
Part Number: BP0070-0090-0100-PX (10 Pcs) Unflanged Bushes - 7x9x10 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 7.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.276 in.)	Nominal Outside Diameter (D) 9.000 mm (Equiv. 0.354 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur X
Part Number: BP0070-0090-0100-PX (10 Pcs) Unflanged Bushes - 7x9x10 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0070-0090-0100-PX (10 Pcs) --- Unflanged Bushes - 7x9x10 mm Plastic - Iglidur X Bush Sale BP0070-0090-0100-PX (10 Pcs) --- Unflanged Bushes - 7x9x10 mm Plastic - Iglidur X Bush Regular price $137.68 AUD Regular price ~~$165.22 AUD~~ Sale price $137.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 7.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.276 in.)	Nominal Outside Diameter (D) 9.000 mm (Equiv. 0.354 in.)	Length (s) 12.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.472 in.)
Material: Iglidur X
Part Number: BP0070-0090-0120-PX (10 Pcs) Unflanged Bushes - 7x9x12 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $140.41 AUD Regular price ~~$168.49 AUD~~ Sale price $140.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 7.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.276 in.)	Nominal Outside Diameter (D) 9.000 mm (Equiv. 0.354 in.)	Length (s) 12.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.472 in.)
Material: Iglidur X
Part Number: BP0070-0090-0120-PX (10 Pcs) Unflanged Bushes - 7x9x12 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $140.41 AUD Regular price ~~$168.49 AUD~~ Sale price $140.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0070-0090-0120-PX (10 Pcs) --- Unflanged Bushes - 7x9x12 mm Plastic - Iglidur X Bush Sale BP0070-0090-0120-PX (10 Pcs) --- Unflanged Bushes - 7x9x12 mm Plastic - Iglidur X Bush Regular price $140.41 AUD Regular price ~~$168.49 AUD~~ Sale price $140.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 7.938 mm _{+ 0.013 / + 0.071} (Equiv. 0.313 in.)	Nominal Outside Diameter (D) 9.525 mm (Equiv. 0.375 in.)	Length (s) 6.350 mm _{+ 0.000 / - 0.220} (Equiv. 0.25 in.)
Material: Iglidur X
Part Number: BP0079-0095-0064-PX (10 Pcs) Unflanged Bushes - 7.938x9.525x6.35 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $90.14 AUD Regular price ~~$108.16 AUD~~ Sale price $90.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 7.938 mm _{+ 0.013 / + 0.071} (Equiv. 0.313 in.)	Nominal Outside Diameter (D) 9.525 mm (Equiv. 0.375 in.)	Length (s) 6.350 mm _{+ 0.000 / - 0.220} (Equiv. 0.25 in.)
Material: Iglidur X
Part Number: BP0079-0095-0064-PX (10 Pcs) Unflanged Bushes - 7.938x9.525x6.35 mm Plastic - Iglidur X Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $90.14 AUD Regular price ~~$108.16 AUD~~ Sale price $90.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0079-0095-0064-PX (10 Pcs) --- Unflanged Bushes - 7.938x9.525x6.35 mm Plastic - Iglidur X Bush Sale BP0079-0095-0064-PX (10 Pcs) --- Unflanged Bushes - 7.938x9.525x6.35 mm Plastic - Iglidur X Bush Regular price $90.14 AUD Regular price ~~$108.16 AUD~~ Sale price $90.14 AUD Unit price per Out of stock! Backorder Now Sale
