Collection: Bushes - Unflanged - Plastic - Iglidur H

Bushes -> Unflanged -> Plastic -> Iglidur H

There are 31 products in the sub-categories of Bushes - Unflanged - Plastic - Iglidur H. Scroll down or follow the link to Bushes - Unflanged - Plastic - Iglidur H in the products table to see all these items combined into a handy table with filters.

Category Details

A selection of Iglidur H Plastic Unflanged Bushes. Underwater performance. High Temp. Chemical Resistance.

An expanded range may be available on special order. Please enquire.
Specific Gravity 1.64 g/cm3.
Operating Temp 240 C short term / 200 C long term.
Tensile Strength at 20 Deg C = 175 Mpa.
Hardness 87 Shore D (DIN53505).
Bushing bore tolerance shown is after a H7 press fit.

Miniature Bearings Australia - MBA Minibearings

Additional resources:

A more concise listing may be found in the Bushes - Unflanged - Plastic - Iglidur H category on the Small Parts & Bearings online store.

Nominal Inside Diameter (d)	Nominal Outside Diameter (D)	Length (s)	Indicative Image
Nominal Inside Diameter (d) 3.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.118 in.)	Nominal Outside Diameter (D) 4.500 mm (Equiv. 0.177 in.)	Length (s) 3.000 mm _{+ 0.000 / - 0.140} (Equiv. 0.118 in.)
Material: Iglidur H
Part Number: BP0030-0045-0030-PH (10 Pcs) Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $106.05 AUD Regular price Sale price $106.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d)	Nominal Outside Diameter (D)	Length (s)	Indicative Image
Nominal Inside Diameter (d) 3.000 mm _{+ 0.006 / + 0.046} (Equiv. 0.118 in.)	Nominal Outside Diameter (D) 4.500 mm (Equiv. 0.177 in.)	Length (s) 3.000 mm _{+ 0.000 / - 0.140} (Equiv. 0.118 in.)
Material: Iglidur H
Part Number: BP0030-0045-0030-PH (10 Pcs) Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $106.05 AUD Regular price Sale price $106.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0030-0045-0030-PH (10 Pcs) --- Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur H Bush BP0030-0045-0030-PH (10 Pcs) --- Unflanged Bushes - 3x4.5x3 mm Plastic - Iglidur H Bush Regular price $106.05 AUD Regular price Sale price $106.05 AUD Unit price per Out of stock! Backorder Now
Nominal Inside Diameter (d) 4.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.157 in.)	Nominal Outside Diameter (D) 5.500 mm (Equiv. 0.217 in.)	Length (s) 4.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.157 in.)
Material: Iglidur H
Part Number: BP0040-0055-0040-PH (10 Pcs) Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 4.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.157 in.)	Nominal Outside Diameter (D) 5.500 mm (Equiv. 0.217 in.)	Length (s) 4.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.157 in.)
Material: Iglidur H
Part Number: BP0040-0055-0040-PH (10 Pcs) Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0040-0055-0040-PH (10 Pcs) --- Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur H Bush Sale BP0040-0055-0040-PH (10 Pcs) --- Unflanged Bushes - 4x5.5x4 mm Plastic - Iglidur H Bush Regular price $91.50 AUD Regular price ~~$109.80 AUD~~ Sale price $91.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 5.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.197 in.)
Material: Iglidur H
Part Number: BP0050-0070-0050-PH (10 Pcs) Unflanged Bushes - 5x7x5 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $92.86 AUD Regular price ~~$111.44 AUD~~ Sale price $92.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 5.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.197 in.)
Material: Iglidur H
Part Number: BP0050-0070-0050-PH (10 Pcs) Unflanged Bushes - 5x7x5 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $92.86 AUD Regular price ~~$111.44 AUD~~ Sale price $92.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0050-0070-0050-PH (10 Pcs) --- Unflanged Bushes - 5x7x5 mm Plastic - Iglidur H Bush Sale BP0050-0070-0050-PH (10 Pcs) --- Unflanged Bushes - 5x7x5 mm Plastic - Iglidur H Bush Regular price $92.86 AUD Regular price ~~$111.44 AUD~~ Sale price $92.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 6.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.236 in.)
Material: Iglidur H
Part Number: BP0060-0080-0060-PH (10 Pcs) Unflanged Bushes - 6x8x6 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $92.86 AUD Regular price ~~$111.44 AUD~~ Sale price $92.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 6.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.236 in.)
Material: Iglidur H
Part Number: BP0060-0080-0060-PH (10 Pcs) Unflanged Bushes - 6x8x6 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $92.86 AUD Regular price ~~$111.44 AUD~~ Sale price $92.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0060-0080-0060-PH (10 Pcs) --- Unflanged Bushes - 6x8x6 mm Plastic - Iglidur H Bush Sale BP0060-0080-0060-PH (10 Pcs) --- Unflanged Bushes - 6x8x6 mm Plastic - Iglidur H Bush Regular price $92.86 AUD Regular price ~~$111.44 AUD~~ Sale price $92.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 8.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.315 in.)	Nominal Outside Diameter (D) 10.000 mm (Equiv. 0.394 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)
Material: Iglidur H
Part Number: BP0080-0100-0080-PH (10 Pcs) Unflanged Bushes - 8x10x8 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $94.14 AUD Regular price ~~$112.96 AUD~~ Sale price $94.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 8.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.315 in.)	Nominal Outside Diameter (D) 10.000 mm (Equiv. 0.394 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)
Material: Iglidur H
Part Number: BP0080-0100-0080-PH (10 Pcs) Unflanged Bushes - 8x10x8 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $94.14 AUD Regular price ~~$112.96 AUD~~ Sale price $94.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0080-0100-0080-PH (10 Pcs) --- Unflanged Bushes - 8x10x8 mm Plastic - Iglidur H Bush Sale BP0080-0100-0080-PH (10 Pcs) --- Unflanged Bushes - 8x10x8 mm Plastic - Iglidur H Bush Regular price $94.14 AUD Regular price ~~$112.96 AUD~~ Sale price $94.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 8.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.315 in.)	Nominal Outside Diameter (D) 10.000 mm (Equiv. 0.394 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur H
Part Number: BP0080-0100-0100-PH (10 Pcs) Unflanged Bushes - 8x10x10 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $95.50 AUD Regular price ~~$114.60 AUD~~ Sale price $95.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 8.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.315 in.)	Nominal Outside Diameter (D) 10.000 mm (Equiv. 0.394 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur H
Part Number: BP0080-0100-0100-PH (10 Pcs) Unflanged Bushes - 8x10x10 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $95.50 AUD Regular price ~~$114.60 AUD~~ Sale price $95.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0080-0100-0100-PH (10 Pcs) --- Unflanged Bushes - 8x10x10 mm Plastic - Iglidur H Bush Sale BP0080-0100-0100-PH (10 Pcs) --- Unflanged Bushes - 8x10x10 mm Plastic - Iglidur H Bush Regular price $95.50 AUD Regular price ~~$114.60 AUD~~ Sale price $95.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 10.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.394 in.)	Nominal Outside Diameter (D) 12.000 mm (Equiv. 0.472 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur H
Part Number: BP0100-0120-0100-PH (10 Pcs) Unflanged Bushes - 10x12x10 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $98.23 AUD Regular price ~~$117.87 AUD~~ Sale price $98.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 10.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.394 in.)	Nominal Outside Diameter (D) 12.000 mm (Equiv. 0.472 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur H
Part Number: BP0100-0120-0100-PH (10 Pcs) Unflanged Bushes - 10x12x10 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $98.23 AUD Regular price ~~$117.87 AUD~~ Sale price $98.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0100-0120-0100-PH (10 Pcs) --- Unflanged Bushes - 10x12x10 mm Plastic - Iglidur H Bush Sale BP0100-0120-0100-PH (10 Pcs) --- Unflanged Bushes - 10x12x10 mm Plastic - Iglidur H Bush Regular price $98.23 AUD Regular price ~~$117.87 AUD~~ Sale price $98.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur H
Part Number: BP0120-0140-0100-PH (10 Pcs) Unflanged Bushes - 12x14x10 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 10.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.394 in.)
Material: Iglidur H
Part Number: BP0120-0140-0100-PH (10 Pcs) Unflanged Bushes - 12x14x10 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0120-0140-0100-PH (10 Pcs) --- Unflanged Bushes - 12x14x10 mm Plastic - Iglidur H Bush Sale BP0120-0140-0100-PH (10 Pcs) --- Unflanged Bushes - 12x14x10 mm Plastic - Iglidur H Bush Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0120-0140-0150-PH (10 Pcs) Unflanged Bushes - 12x14x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0120-0140-0150-PH (10 Pcs) Unflanged Bushes - 12x14x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0120-0140-0150-PH (10 Pcs) --- Unflanged Bushes - 12x14x15 mm Plastic - Iglidur H Bush Sale BP0120-0140-0150-PH (10 Pcs) --- Unflanged Bushes - 12x14x15 mm Plastic - Iglidur H Bush Regular price $103.68 AUD Regular price ~~$124.42 AUD~~ Sale price $103.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0120-0140-0200-PH (10 Pcs) Unflanged Bushes - 12x14x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $121.41 AUD Regular price ~~$145.69 AUD~~ Sale price $121.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0120-0140-0200-PH (10 Pcs) Unflanged Bushes - 12x14x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $121.41 AUD Regular price ~~$145.69 AUD~~ Sale price $121.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0120-0140-0200-PH (10 Pcs) --- Unflanged Bushes - 12x14x20 mm Plastic - Iglidur H Bush Sale BP0120-0140-0200-PH (10 Pcs) --- Unflanged Bushes - 12x14x20 mm Plastic - Iglidur H Bush Regular price $121.41 AUD Regular price ~~$145.69 AUD~~ Sale price $121.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 14.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.551 in.)	Nominal Outside Diameter (D) 16.000 mm (Equiv. 0.63 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0140-0160-0200-PH (10 Pcs) Unflanged Bushes - 14x16x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $121.41 AUD Regular price ~~$145.69 AUD~~ Sale price $121.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 14.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.551 in.)	Nominal Outside Diameter (D) 16.000 mm (Equiv. 0.63 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0140-0160-0200-PH (10 Pcs) Unflanged Bushes - 14x16x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $121.41 AUD Regular price ~~$145.69 AUD~~ Sale price $121.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0140-0160-0200-PH (10 Pcs) --- Unflanged Bushes - 14x16x20 mm Plastic - Iglidur H Bush Sale BP0140-0160-0200-PH (10 Pcs) --- Unflanged Bushes - 14x16x20 mm Plastic - Iglidur H Bush Regular price $121.41 AUD Regular price ~~$145.69 AUD~~ Sale price $121.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 15.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.591 in.)	Nominal Outside Diameter (D) 17.000 mm (Equiv. 0.669 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0150-0170-0150-PH (10 Pcs) Unflanged Bushes - 15x17x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $111.86 AUD Regular price ~~$134.24 AUD~~ Sale price $111.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 15.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.591 in.)	Nominal Outside Diameter (D) 17.000 mm (Equiv. 0.669 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0150-0170-0150-PH (10 Pcs) Unflanged Bushes - 15x17x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $111.86 AUD Regular price ~~$134.24 AUD~~ Sale price $111.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0150-0170-0150-PH (10 Pcs) --- Unflanged Bushes - 15x17x15 mm Plastic - Iglidur H Bush Sale BP0150-0170-0150-PH (10 Pcs) --- Unflanged Bushes - 15x17x15 mm Plastic - Iglidur H Bush Regular price $111.86 AUD Regular price ~~$134.24 AUD~~ Sale price $111.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 16.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.63 in.)	Nominal Outside Diameter (D) 18.000 mm (Equiv. 0.709 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0160-0180-0150-PH (10 Pcs) Unflanged Bushes - 16x18x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $98.23 AUD Regular price ~~$117.87 AUD~~ Sale price $98.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 16.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.63 in.)	Nominal Outside Diameter (D) 18.000 mm (Equiv. 0.709 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0160-0180-0150-PH (10 Pcs) Unflanged Bushes - 16x18x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $98.23 AUD Regular price ~~$117.87 AUD~~ Sale price $98.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0160-0180-0150-PH (10 Pcs) --- Unflanged Bushes - 16x18x15 mm Plastic - Iglidur H Bush Sale BP0160-0180-0150-PH (10 Pcs) --- Unflanged Bushes - 16x18x15 mm Plastic - Iglidur H Bush Regular price $98.23 AUD Regular price ~~$117.87 AUD~~ Sale price $98.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 16.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.63 in.)	Nominal Outside Diameter (D) 18.000 mm (Equiv. 0.709 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0160-0180-0200-PH (10 Pcs) Unflanged Bushes - 16x18x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $113.23 AUD Regular price ~~$135.87 AUD~~ Sale price $113.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 16.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.63 in.)	Nominal Outside Diameter (D) 18.000 mm (Equiv. 0.709 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0160-0180-0200-PH (10 Pcs) Unflanged Bushes - 16x18x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $113.23 AUD Regular price ~~$135.87 AUD~~ Sale price $113.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0160-0180-0200-PH (10 Pcs) --- Unflanged Bushes - 16x18x20 mm Plastic - Iglidur H Bush Sale BP0160-0180-0200-PH (10 Pcs) --- Unflanged Bushes - 16x18x20 mm Plastic - Iglidur H Bush Regular price $113.23 AUD Regular price ~~$135.87 AUD~~ Sale price $113.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 16.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.63 in.)	Nominal Outside Diameter (D) 18.000 mm (Equiv. 0.709 in.)	Length (s) 25.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.984 in.)
Material: Iglidur H
Part Number: BP0160-0180-0250-PH (10 Pcs) Unflanged Bushes - 16x18x25 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $117.32 AUD Regular price ~~$140.78 AUD~~ Sale price $117.32 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 16.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.63 in.)	Nominal Outside Diameter (D) 18.000 mm (Equiv. 0.709 in.)	Length (s) 25.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.984 in.)
Material: Iglidur H
Part Number: BP0160-0180-0250-PH (10 Pcs) Unflanged Bushes - 16x18x25 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $117.32 AUD Regular price ~~$140.78 AUD~~ Sale price $117.32 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0160-0180-0250-PH (10 Pcs) --- Unflanged Bushes - 16x18x25 mm Plastic - Iglidur H Bush Sale BP0160-0180-0250-PH (10 Pcs) --- Unflanged Bushes - 16x18x25 mm Plastic - Iglidur H Bush Regular price $117.32 AUD Regular price ~~$140.78 AUD~~ Sale price $117.32 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 18.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.709 in.)	Nominal Outside Diameter (D) 20.000 mm (Equiv. 0.787 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0180-0200-0150-PH (10 Pcs) Unflanged Bushes - 18x20x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $100.95 AUD Regular price ~~$121.15 AUD~~ Sale price $100.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 18.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.709 in.)	Nominal Outside Diameter (D) 20.000 mm (Equiv. 0.787 in.)	Length (s) 15.000 mm _{+ 0.000 / - 0.270} (Equiv. 0.591 in.)
Material: Iglidur H
Part Number: BP0180-0200-0150-PH (10 Pcs) Unflanged Bushes - 18x20x15 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $100.95 AUD Regular price ~~$121.15 AUD~~ Sale price $100.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0180-0200-0150-PH (10 Pcs) --- Unflanged Bushes - 18x20x15 mm Plastic - Iglidur H Bush Sale BP0180-0200-0150-PH (10 Pcs) --- Unflanged Bushes - 18x20x15 mm Plastic - Iglidur H Bush Regular price $100.95 AUD Regular price ~~$121.15 AUD~~ Sale price $100.95 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 18.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.709 in.)	Nominal Outside Diameter (D) 20.000 mm (Equiv. 0.787 in.)	Length (s) 25.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.984 in.)
Material: Iglidur H
Part Number: BP0180-0200-0250-PH (10 Pcs) Unflanged Bushes - 18x20x25 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $105.05 AUD Regular price ~~$126.05 AUD~~ Sale price $105.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 18.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.709 in.)	Nominal Outside Diameter (D) 20.000 mm (Equiv. 0.787 in.)	Length (s) 25.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.984 in.)
Material: Iglidur H
Part Number: BP0180-0200-0250-PH (10 Pcs) Unflanged Bushes - 18x20x25 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $105.05 AUD Regular price ~~$126.05 AUD~~ Sale price $105.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0180-0200-0250-PH (10 Pcs) --- Unflanged Bushes - 18x20x25 mm Plastic - Iglidur H Bush Sale BP0180-0200-0250-PH (10 Pcs) --- Unflanged Bushes - 18x20x25 mm Plastic - Iglidur H Bush Regular price $105.05 AUD Regular price ~~$126.05 AUD~~ Sale price $105.05 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 20.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.787 in.)	Nominal Outside Diameter (D) 23.000 mm (Equiv. 0.906 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0200-0230-0200-PH (10 Pcs) Unflanged Bushes - 20x23x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $140.41 AUD Regular price ~~$168.49 AUD~~ Sale price $140.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 20.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.787 in.)	Nominal Outside Diameter (D) 23.000 mm (Equiv. 0.906 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0200-0230-0200-PH (10 Pcs) Unflanged Bushes - 20x23x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $140.41 AUD Regular price ~~$168.49 AUD~~ Sale price $140.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0200-0230-0200-PH (10 Pcs) --- Unflanged Bushes - 20x23x20 mm Plastic - Iglidur H Bush Sale BP0200-0230-0200-PH (10 Pcs) --- Unflanged Bushes - 20x23x20 mm Plastic - Iglidur H Bush Regular price $140.41 AUD Regular price ~~$168.49 AUD~~ Sale price $140.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 22.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.866 in.)	Nominal Outside Diameter (D) 25.000 mm (Equiv. 0.984 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0220-0250-0200-PH (10 Pcs) Unflanged Bushes - 22x25x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $144.50 AUD Regular price ~~$173.40 AUD~~ Sale price $144.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 22.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.866 in.)	Nominal Outside Diameter (D) 25.000 mm (Equiv. 0.984 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0220-0250-0200-PH (10 Pcs) Unflanged Bushes - 22x25x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $144.50 AUD Regular price ~~$173.40 AUD~~ Sale price $144.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0220-0250-0200-PH (10 Pcs) --- Unflanged Bushes - 22x25x20 mm Plastic - Iglidur H Bush Sale BP0220-0250-0200-PH (10 Pcs) --- Unflanged Bushes - 22x25x20 mm Plastic - Iglidur H Bush Regular price $144.50 AUD Regular price ~~$173.40 AUD~~ Sale price $144.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 25.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.984 in.)	Nominal Outside Diameter (D) 28.000 mm (Equiv. 1.102 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0250-0280-0200-PH (10 Pcs) Unflanged Bushes - 25x28x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $160.86 AUD Regular price ~~$193.04 AUD~~ Sale price $160.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 25.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.984 in.)	Nominal Outside Diameter (D) 28.000 mm (Equiv. 1.102 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0250-0280-0200-PH (10 Pcs) Unflanged Bushes - 25x28x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $160.86 AUD Regular price ~~$193.04 AUD~~ Sale price $160.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0250-0280-0200-PH (10 Pcs) --- Unflanged Bushes - 25x28x20 mm Plastic - Iglidur H Bush Sale BP0250-0280-0200-PH (10 Pcs) --- Unflanged Bushes - 25x28x20 mm Plastic - Iglidur H Bush Regular price $160.86 AUD Regular price ~~$193.04 AUD~~ Sale price $160.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0300-0340-0200-PH (10 Pcs) Unflanged Bushes - 30x34x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $245.14 AUD Regular price ~~$294.16 AUD~~ Sale price $245.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)
Material: Iglidur H
Part Number: BP0300-0340-0200-PH (10 Pcs) Unflanged Bushes - 30x34x20 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $245.14 AUD Regular price ~~$294.16 AUD~~ Sale price $245.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0300-0340-0200-PH (10 Pcs) --- Unflanged Bushes - 30x34x20 mm Plastic - Iglidur H Bush Sale BP0300-0340-0200-PH (10 Pcs) --- Unflanged Bushes - 30x34x20 mm Plastic - Iglidur H Bush Regular price $245.14 AUD Regular price ~~$294.16 AUD~~ Sale price $245.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 30.000 mm _{+ 0.000 / - 0.330} (Equiv. 1.181 in.)
Material: Iglidur H
Part Number: BP0300-0340-0300-PH (10 Pcs) Unflanged Bushes - 30x34x30 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $245.14 AUD Regular price ~~$294.16 AUD~~ Sale price $245.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 30.000 mm _{+ 0.000 / - 0.330} (Equiv. 1.181 in.)
Material: Iglidur H
Part Number: BP0300-0340-0300-PH (10 Pcs) Unflanged Bushes - 30x34x30 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $245.14 AUD Regular price ~~$294.16 AUD~~ Sale price $245.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0300-0340-0300-PH (10 Pcs) --- Unflanged Bushes - 30x34x30 mm Plastic - Iglidur H Bush Sale BP0300-0340-0300-PH (10 Pcs) --- Unflanged Bushes - 30x34x30 mm Plastic - Iglidur H Bush Regular price $245.14 AUD Regular price ~~$294.16 AUD~~ Sale price $245.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 40.000 mm _{+ 0.000 / - 0.390} (Equiv. 1.575 in.)
Material: Iglidur H
Part Number: BP0300-0340-0400-PH (10 Pcs) Unflanged Bushes - 30x34x40 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $254.68 AUD Regular price ~~$305.62 AUD~~ Sale price $254.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 40.000 mm _{+ 0.000 / - 0.390} (Equiv. 1.575 in.)
Material: Iglidur H
Part Number: BP0300-0340-0400-PH (10 Pcs) Unflanged Bushes - 30x34x40 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $254.68 AUD Regular price ~~$305.62 AUD~~ Sale price $254.68 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0300-0340-0400-PH (10 Pcs) --- Unflanged Bushes - 30x34x40 mm Plastic - Iglidur H Bush Sale BP0300-0340-0400-PH (10 Pcs) --- Unflanged Bushes - 30x34x40 mm Plastic - Iglidur H Bush Regular price $254.68 AUD Regular price ~~$305.62 AUD~~ Sale price $254.68 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 35.000 mm _{+ 0.025 / + 0.125} (Equiv. 1.378 in.)	Nominal Outside Diameter (D) 39.000 mm (Equiv. 1.535 in.)	Length (s) 40.000 mm _{+ 0.000 / - 0.390} (Equiv. 1.575 in.)
Material: Iglidur H
Part Number: BP0350-0390-0400-PH (10 Pcs) Unflanged Bushes - 35x39x40 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $337.59 AUD Regular price ~~$405.11 AUD~~ Sale price $337.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 35.000 mm _{+ 0.025 / + 0.125} (Equiv. 1.378 in.)	Nominal Outside Diameter (D) 39.000 mm (Equiv. 1.535 in.)	Length (s) 40.000 mm _{+ 0.000 / - 0.390} (Equiv. 1.575 in.)
Material: Iglidur H
Part Number: BP0350-0390-0400-PH (10 Pcs) Unflanged Bushes - 35x39x40 mm Plastic - Iglidur H Bush Out of Stock \| Backorder Now \| Orders can be expected around Sat, Oct 11, 2025 Regular price $337.59 AUD Regular price ~~$405.11 AUD~~ Sale price $337.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BP0350-0390-0400-PH (10 Pcs) --- Unflanged Bushes - 35x39x40 mm Plastic - Iglidur H Bush Sale BP0350-0390-0400-PH (10 Pcs) --- Unflanged Bushes - 35x39x40 mm Plastic - Iglidur H Bush Regular price $337.59 AUD Regular price ~~$405.11 AUD~~ Sale price $337.59 AUD Unit price per Out of stock! Backorder Now Sale
