Collection: Bushes - Flanged - Plastic - Iglidur Z

Bushes -> Flanged -> Plastic -> Iglidur Z

There are 29 products in the sub-categories of Bushes - Flanged - Plastic - Iglidur Z. Scroll down or follow the link to Bushes - Flanged - Plastic - Iglidur Z in the products table to see all these items combined into a handy table with filters.

Category Details

A selection of Iglidur Z Plastic Flanged Bushes. High temperature. High thermal resistance. Extreme load. High surface speed.

An expanded range may be available on special order. Please enquire.
Specific Gravity 1.40 g/cm3.
Operating Temp 310 C short term / 250 C long term.
Tensile Strength at 20 Deg C = 95 Mpa.
Hardness 81 Shore D (DIN53505).
Bushing bore tolerance shown is after a H7 press fit.

Miniature Bearings Australia - MBA Minibearings

Additional resources:

A more concise listing may be found in the Bushes - Flanged - Plastic - Iglidur Z category on the Small Parts & Bearings online store.

Nominal Inside Diameter (d)	Nominal Outside Diameter (D)	Length (s)	Flange OD (D1)	Flange Thickness (s1)
Nominal Inside Diameter (d) 4.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.157 in.)	Nominal Outside Diameter (D) 5.500 mm (Equiv. 0.217 in.)	Length (s) 4.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.157 in.)	Flange OD (D1) 9.50 mm	Flange Thickness (s1) 0.75 mm
Material: Iglidur Z
Part Number: BF0040-0055-0040-PZ (10 Pcs) Flanged Bushes - 4x5.5x4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $133.50 AUD Regular price Sale price $133.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d)	Nominal Outside Diameter (D)	Length (s)	Flange OD (D1)	Indicative Image
Nominal Inside Diameter (d) 4.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.157 in.)	Nominal Outside Diameter (D) 5.500 mm (Equiv. 0.217 in.)	Length (s) 4.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.157 in.)	Flange OD (D1) 9.50 mm
Material: Iglidur Z Flange Thickness (s1): 0.75 mm
Part Number: BF0040-0055-0040-PZ (10 Pcs) Flanged Bushes - 4x5.5x4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $133.50 AUD Regular price Sale price $133.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0040-0055-0040-PZ (10 Pcs) --- Flanged Bushes - 4x5.5x4 mm Plastic - Iglidur Z Bush BF0040-0055-0040-PZ (10 Pcs) --- Flanged Bushes - 4x5.5x4 mm Plastic - Iglidur Z Bush Regular price $133.50 AUD Regular price Sale price $133.50 AUD Unit price per Out of stock! Backorder Now
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 5.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.197 in.)	Flange OD (D1) 11.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0050-0070-0050-PZ (10 Pcs) Flanged Bushes - 5x7x5 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $114.59 AUD Regular price ~~$137.51 AUD~~ Sale price $114.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 5.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.197 in.)	Nominal Outside Diameter (D) 7.000 mm (Equiv. 0.276 in.)	Length (s) 5.000 mm _{+ 0.000 / - 0.180} (Equiv. 0.197 in.)	Flange OD (D1) 11.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0050-0070-0050-PZ (10 Pcs) Flanged Bushes - 5x7x5 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $114.59 AUD Regular price ~~$137.51 AUD~~ Sale price $114.59 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0050-0070-0050-PZ (10 Pcs) --- Flanged Bushes - 5x7x5 mm Plastic - Iglidur Z Bush Sale BF0050-0070-0050-PZ (10 Pcs) --- Flanged Bushes - 5x7x5 mm Plastic - Iglidur Z Bush Regular price $114.59 AUD Regular price ~~$137.51 AUD~~ Sale price $114.59 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)	Flange OD (D1) 12.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0060-0080-0080-PZ (10 Pcs) Flanged Bushes - 6x8x8 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 6.000 mm _{+ 0.010 / + 0.058} (Equiv. 0.236 in.)	Nominal Outside Diameter (D) 8.000 mm (Equiv. 0.315 in.)	Length (s) 8.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.315 in.)	Flange OD (D1) 12.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0060-0080-0080-PZ (10 Pcs) Flanged Bushes - 6x8x8 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0060-0080-0080-PZ (10 Pcs) --- Flanged Bushes - 6x8x8 mm Plastic - Iglidur Z Bush Sale BF0060-0080-0080-PZ (10 Pcs) --- Flanged Bushes - 6x8x8 mm Plastic - Iglidur Z Bush Regular price $129.50 AUD Regular price ~~$155.40 AUD~~ Sale price $129.50 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 8.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.315 in.)	Nominal Outside Diameter (D) 10.000 mm (Equiv. 0.394 in.)	Length (s) 9.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.354 in.)	Flange OD (D1) 15.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0080-0100-0090-PZ (10 Pcs) Flanged Bushes - 8x10x9 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $132.23 AUD Regular price ~~$158.67 AUD~~ Sale price $132.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 8.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.315 in.)	Nominal Outside Diameter (D) 10.000 mm (Equiv. 0.394 in.)	Length (s) 9.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.354 in.)	Flange OD (D1) 15.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0080-0100-0090-PZ (10 Pcs) Flanged Bushes - 8x10x9 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $132.23 AUD Regular price ~~$158.67 AUD~~ Sale price $132.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0080-0100-0090-PZ (10 Pcs) --- Flanged Bushes - 8x10x9 mm Plastic - Iglidur Z Bush Sale BF0080-0100-0090-PZ (10 Pcs) --- Flanged Bushes - 8x10x9 mm Plastic - Iglidur Z Bush Regular price $132.23 AUD Regular price ~~$158.67 AUD~~ Sale price $132.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 9.525 mm _{+ 0.013 / + 0.071} (Equiv. 0.375 in.)	Nominal Outside Diameter (D) 11.906 mm (Equiv. 0.469 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.290} (Equiv. 0.5 in.)	Flange OD (D1) 17.45 mm	Flange Thickness (s1) 1.17 mm
Material: Iglidur Z
Part Number: BF0095-0119-0127-PZ (10 Pcs) Flanged Bushes - 9.525x11.906x12.7 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $143.14 AUD Regular price ~~$171.76 AUD~~ Sale price $143.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 9.525 mm _{+ 0.013 / + 0.071} (Equiv. 0.375 in.)	Nominal Outside Diameter (D) 11.906 mm (Equiv. 0.469 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.290} (Equiv. 0.5 in.)	Flange OD (D1) 17.45 mm
Material: Iglidur Z Flange Thickness (s1): 1.17 mm
Part Number: BF0095-0119-0127-PZ (10 Pcs) Flanged Bushes - 9.525x11.906x12.7 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $143.14 AUD Regular price ~~$171.76 AUD~~ Sale price $143.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0095-0119-0127-PZ (10 Pcs) --- Flanged Bushes - 9.525x11.906x12.7 mm Plastic - Iglidur Z Bush Sale BF0095-0119-0127-PZ (10 Pcs) --- Flanged Bushes - 9.525x11.906x12.7 mm Plastic - Iglidur Z Bush Regular price $143.14 AUD Regular price ~~$171.76 AUD~~ Sale price $143.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 10.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.394 in.)	Nominal Outside Diameter (D) 12.000 mm (Equiv. 0.472 in.)	Length (s) 9.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.354 in.)	Flange OD (D1) 18.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0100-0120-0090-PZ (10 Pcs) Flanged Bushes - 10x12x9 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $134.95 AUD Regular price ~~$161.95 AUD~~ Sale price $134.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 10.000 mm _{+ 0.013 / + 0.071} (Equiv. 0.394 in.)	Nominal Outside Diameter (D) 12.000 mm (Equiv. 0.472 in.)	Length (s) 9.000 mm _{+ 0.000 / - 0.220} (Equiv. 0.354 in.)	Flange OD (D1) 18.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0100-0120-0090-PZ (10 Pcs) Flanged Bushes - 10x12x9 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $134.95 AUD Regular price ~~$161.95 AUD~~ Sale price $134.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0100-0120-0090-PZ (10 Pcs) --- Flanged Bushes - 10x12x9 mm Plastic - Iglidur Z Bush Sale BF0100-0120-0090-PZ (10 Pcs) --- Flanged Bushes - 10x12x9 mm Plastic - Iglidur Z Bush Regular price $134.95 AUD Regular price ~~$161.95 AUD~~ Sale price $134.95 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 12.000 mm _{+ 0.000 / - 0.290} (Equiv. 0.472 in.)	Flange OD (D1) 20.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0120-0140-0120-PZ (10 Pcs) Flanged Bushes - 12x14x12 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $145.86 AUD Regular price ~~$175.04 AUD~~ Sale price $145.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 12.000 mm _{+ 0.000 / - 0.290} (Equiv. 0.472 in.)	Flange OD (D1) 20.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0120-0140-0120-PZ (10 Pcs) Flanged Bushes - 12x14x12 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $145.86 AUD Regular price ~~$175.04 AUD~~ Sale price $145.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0120-0140-0120-PZ (10 Pcs) --- Flanged Bushes - 12x14x12 mm Plastic - Iglidur Z Bush Sale BF0120-0140-0120-PZ (10 Pcs) --- Flanged Bushes - 12x14x12 mm Plastic - Iglidur Z Bush Regular price $145.86 AUD Regular price ~~$175.04 AUD~~ Sale price $145.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)	Flange OD (D1) 20.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0120-0140-0200-PZ (10 Pcs) Flanged Bushes - 12x14x20 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $162.14 AUD Regular price ~~$194.56 AUD~~ Sale price $162.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 12.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.472 in.)	Nominal Outside Diameter (D) 14.000 mm (Equiv. 0.551 in.)	Length (s) 20.000 mm _{+ 0.000 / - 0.330} (Equiv. 0.787 in.)	Flange OD (D1) 20.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0120-0140-0200-PZ (10 Pcs) Flanged Bushes - 12x14x20 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $162.14 AUD Regular price ~~$194.56 AUD~~ Sale price $162.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0120-0140-0200-PZ (10 Pcs) --- Flanged Bushes - 12x14x20 mm Plastic - Iglidur Z Bush Sale BF0120-0140-0200-PZ (10 Pcs) --- Flanged Bushes - 12x14x20 mm Plastic - Iglidur Z Bush Regular price $162.14 AUD Regular price ~~$194.56 AUD~~ Sale price $162.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 12.700 mm _{+ 0.016 / + 0.086} (Equiv. 0.5 in.)	Nominal Outside Diameter (D) 15.081 mm (Equiv. 0.594 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.290} (Equiv. 0.5 in.)	Flange OD (D1) 22.23 mm	Flange Thickness (s1) 1.17 mm
Material: Iglidur Z
Part Number: BF0127-0151-0127-PZ (10 Pcs) Flanged Bushes - 12.7x15.081x12.7 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $155.41 AUD Regular price ~~$186.49 AUD~~ Sale price $155.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 12.700 mm _{+ 0.016 / + 0.086} (Equiv. 0.5 in.)	Nominal Outside Diameter (D) 15.081 mm (Equiv. 0.594 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.290} (Equiv. 0.5 in.)	Flange OD (D1) 22.23 mm
Material: Iglidur Z Flange Thickness (s1): 1.17 mm
Part Number: BF0127-0151-0127-PZ (10 Pcs) Flanged Bushes - 12.7x15.081x12.7 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $155.41 AUD Regular price ~~$186.49 AUD~~ Sale price $155.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0127-0151-0127-PZ (10 Pcs) --- Flanged Bushes - 12.7x15.081x12.7 mm Plastic - Iglidur Z Bush Sale BF0127-0151-0127-PZ (10 Pcs) --- Flanged Bushes - 12.7x15.081x12.7 mm Plastic - Iglidur Z Bush Regular price $155.41 AUD Regular price ~~$186.49 AUD~~ Sale price $155.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 15.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.591 in.)	Nominal Outside Diameter (D) 17.000 mm (Equiv. 0.669 in.)	Length (s) 11.000 mm _{+ 0.000 / - 0.290} (Equiv. 0.433 in.)	Flange OD (D1) 23.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0150-0170-0110-PZ (10 Pcs) Flanged Bushes - 15x17x11 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $147.23 AUD Regular price ~~$176.67 AUD~~ Sale price $147.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 15.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.591 in.)	Nominal Outside Diameter (D) 17.000 mm (Equiv. 0.669 in.)	Length (s) 11.000 mm _{+ 0.000 / - 0.290} (Equiv. 0.433 in.)	Flange OD (D1) 23.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0150-0170-0110-PZ (10 Pcs) Flanged Bushes - 15x17x11 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $147.23 AUD Regular price ~~$176.67 AUD~~ Sale price $147.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0150-0170-0110-PZ (10 Pcs) --- Flanged Bushes - 15x17x11 mm Plastic - Iglidur Z Bush Sale BF0150-0170-0110-PZ (10 Pcs) --- Flanged Bushes - 15x17x11 mm Plastic - Iglidur Z Bush Regular price $147.23 AUD Regular price ~~$176.67 AUD~~ Sale price $147.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 15.875 mm _{+ 0.016 / + 0.086} (Equiv. 0.625 in.)	Nominal Outside Diameter (D) 19.050 mm (Equiv. 0.75 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.290} (Equiv. 0.5 in.)	Flange OD (D1) 23.80 mm	Flange Thickness (s1) 1.17 mm
Material: Iglidur Z
Part Number: BF0159-0191-0127-PZ (10 Pcs) Flanged Bushes - 15.875x19.05x12.7 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $226.14 AUD Regular price ~~$271.36 AUD~~ Sale price $226.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 15.875 mm _{+ 0.016 / + 0.086} (Equiv. 0.625 in.)	Nominal Outside Diameter (D) 19.050 mm (Equiv. 0.75 in.)	Length (s) 12.700 mm _{+ 0.000 / - 0.290} (Equiv. 0.5 in.)	Flange OD (D1) 23.80 mm
Material: Iglidur Z Flange Thickness (s1): 1.17 mm
Part Number: BF0159-0191-0127-PZ (10 Pcs) Flanged Bushes - 15.875x19.05x12.7 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $226.14 AUD Regular price ~~$271.36 AUD~~ Sale price $226.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0159-0191-0127-PZ (10 Pcs) --- Flanged Bushes - 15.875x19.05x12.7 mm Plastic - Iglidur Z Bush Sale BF0159-0191-0127-PZ (10 Pcs) --- Flanged Bushes - 15.875x19.05x12.7 mm Plastic - Iglidur Z Bush Regular price $226.14 AUD Regular price ~~$271.36 AUD~~ Sale price $226.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 18.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.709 in.)	Nominal Outside Diameter (D) 20.000 mm (Equiv. 0.787 in.)	Length (s) 17.000 mm _{+ 0.000 / - 0.290} (Equiv. 0.669 in.)	Flange OD (D1) 26.00 mm	Flange Thickness (s1) 1.00 mm
Material: Iglidur Z
Part Number: BF0180-0200-0170-PZ (10 Pcs) Flanged Bushes - 18x20x17 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $177.14 AUD Regular price ~~$212.56 AUD~~ Sale price $177.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 18.000 mm _{+ 0.016 / + 0.086} (Equiv. 0.709 in.)	Nominal Outside Diameter (D) 20.000 mm (Equiv. 0.787 in.)	Length (s) 17.000 mm _{+ 0.000 / - 0.290} (Equiv. 0.669 in.)	Flange OD (D1) 26.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.00 mm
Part Number: BF0180-0200-0170-PZ (10 Pcs) Flanged Bushes - 18x20x17 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $177.14 AUD Regular price ~~$212.56 AUD~~ Sale price $177.14 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0180-0200-0170-PZ (10 Pcs) --- Flanged Bushes - 18x20x17 mm Plastic - Iglidur Z Bush Sale BF0180-0200-0170-PZ (10 Pcs) --- Flanged Bushes - 18x20x17 mm Plastic - Iglidur Z Bush Regular price $177.14 AUD Regular price ~~$212.56 AUD~~ Sale price $177.14 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 19.050 mm _{+ 0.020 / + 0.104} (Equiv. 0.75 in.)	Nominal Outside Diameter (D) 22.225 mm (Equiv. 0.875 in.)	Length (s) 19.050 mm _{+ 0.000 / - 0.330} (Equiv. 0.75 in.)	Flange OD (D1) 28.58 mm	Flange Thickness (s1) 1.58 mm
Material: Iglidur Z
Part Number: BF0191-0222-0191-PZ (10 Pcs) Flanged Bushes - 19.05x22.225x19.05 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $236.95 AUD Regular price ~~$284.35 AUD~~ Sale price $236.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 19.050 mm _{+ 0.020 / + 0.104} (Equiv. 0.75 in.)	Nominal Outside Diameter (D) 22.225 mm (Equiv. 0.875 in.)	Length (s) 19.050 mm _{+ 0.000 / - 0.330} (Equiv. 0.75 in.)	Flange OD (D1) 28.58 mm
Material: Iglidur Z Flange Thickness (s1): 1.58 mm
Part Number: BF0191-0222-0191-PZ (10 Pcs) Flanged Bushes - 19.05x22.225x19.05 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $236.95 AUD Regular price ~~$284.35 AUD~~ Sale price $236.95 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0191-0222-0191-PZ (10 Pcs) --- Flanged Bushes - 19.05x22.225x19.05 mm Plastic - Iglidur Z Bush Sale BF0191-0222-0191-PZ (10 Pcs) --- Flanged Bushes - 19.05x22.225x19.05 mm Plastic - Iglidur Z Bush Regular price $236.95 AUD Regular price ~~$284.35 AUD~~ Sale price $236.95 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 19.050 mm _{+ 0.020 / + 0.104} (Equiv. 0.75 in.)	Nominal Outside Diameter (D) 22.225 mm (Equiv. 0.875 in.)	Length (s) 25.400 mm _{+ 0.000 / - 0.330} (Equiv. 1 in.)	Flange OD (D1) 28.58 mm	Flange Thickness (s1) 1.58 mm
Material: Iglidur Z
Part Number: BF0191-0222-0254-PZ (10 Pcs) Flanged Bushes - 19.05x22.225x25.4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $272.32 AUD Regular price ~~$326.78 AUD~~ Sale price $272.32 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 19.050 mm _{+ 0.020 / + 0.104} (Equiv. 0.75 in.)	Nominal Outside Diameter (D) 22.225 mm (Equiv. 0.875 in.)	Length (s) 25.400 mm _{+ 0.000 / - 0.330} (Equiv. 1 in.)	Flange OD (D1) 28.58 mm
Material: Iglidur Z Flange Thickness (s1): 1.58 mm
Part Number: BF0191-0222-0254-PZ (10 Pcs) Flanged Bushes - 19.05x22.225x25.4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $272.32 AUD Regular price ~~$326.78 AUD~~ Sale price $272.32 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0191-0222-0254-PZ (10 Pcs) --- Flanged Bushes - 19.05x22.225x25.4 mm Plastic - Iglidur Z Bush Sale BF0191-0222-0254-PZ (10 Pcs) --- Flanged Bushes - 19.05x22.225x25.4 mm Plastic - Iglidur Z Bush Regular price $272.32 AUD Regular price ~~$326.78 AUD~~ Sale price $272.32 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 20.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.787 in.)	Nominal Outside Diameter (D) 23.000 mm (Equiv. 0.906 in.)	Length (s) 21.500 mm _{+ 0.000 / - 0.330} (Equiv. 0.846 in.)	Flange OD (D1) 30.00 mm	Flange Thickness (s1) 1.50 mm
Material: Iglidur Z
Part Number: BF0200-0230-0215-PZ (10 Pcs) Flanged Bushes - 20x23x21.5 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $283.23 AUD Regular price ~~$339.87 AUD~~ Sale price $283.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 20.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.787 in.)	Nominal Outside Diameter (D) 23.000 mm (Equiv. 0.906 in.)	Length (s) 21.500 mm _{+ 0.000 / - 0.330} (Equiv. 0.846 in.)	Flange OD (D1) 30.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.50 mm
Part Number: BF0200-0230-0215-PZ (10 Pcs) Flanged Bushes - 20x23x21.5 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $283.23 AUD Regular price ~~$339.87 AUD~~ Sale price $283.23 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0200-0230-0215-PZ (10 Pcs) --- Flanged Bushes - 20x23x21.5 mm Plastic - Iglidur Z Bush Sale BF0200-0230-0215-PZ (10 Pcs) --- Flanged Bushes - 20x23x21.5 mm Plastic - Iglidur Z Bush Regular price $283.23 AUD Regular price ~~$339.87 AUD~~ Sale price $283.23 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 22.225 mm _{+ 0.020 / + 0.104} (Equiv. 0.875 in.)	Nominal Outside Diameter (D) 25.400 mm (Equiv. 1 in.)	Length (s) 19.050 mm _{+ 0.000 / - 0.330} (Equiv. 0.75 in.)	Flange OD (D1) 31.75 mm	Flange Thickness (s1) 1.58 mm
Material: Iglidur Z
Part Number: BF0222-0254-0191-PZ (10 Pcs) Flanged Bushes - 22.225x25.4x19.05 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $257.41 AUD Regular price ~~$308.89 AUD~~ Sale price $257.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 22.225 mm _{+ 0.020 / + 0.104} (Equiv. 0.875 in.)	Nominal Outside Diameter (D) 25.400 mm (Equiv. 1 in.)	Length (s) 19.050 mm _{+ 0.000 / - 0.330} (Equiv. 0.75 in.)	Flange OD (D1) 31.75 mm
Material: Iglidur Z Flange Thickness (s1): 1.58 mm
Part Number: BF0222-0254-0191-PZ (10 Pcs) Flanged Bushes - 22.225x25.4x19.05 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $257.41 AUD Regular price ~~$308.89 AUD~~ Sale price $257.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0222-0254-0191-PZ (10 Pcs) --- Flanged Bushes - 22.225x25.4x19.05 mm Plastic - Iglidur Z Bush Sale BF0222-0254-0191-PZ (10 Pcs) --- Flanged Bushes - 22.225x25.4x19.05 mm Plastic - Iglidur Z Bush Regular price $257.41 AUD Regular price ~~$308.89 AUD~~ Sale price $257.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 22.225 mm _{+ 0.020 / + 0.104} (Equiv. 0.875 in.)	Nominal Outside Diameter (D) 25.400 mm (Equiv. 1 in.)	Length (s) 25.400 mm _{+ 0.000 / - 0.330} (Equiv. 1 in.)	Flange OD (D1) 31.75 mm	Flange Thickness (s1) 1.58 mm
Material: Iglidur Z
Part Number: BF0222-0254-0254-PZ (10 Pcs) Flanged Bushes - 22.225x25.4x25.4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $296.86 AUD Regular price ~~$356.24 AUD~~ Sale price $296.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 22.225 mm _{+ 0.020 / + 0.104} (Equiv. 0.875 in.)	Nominal Outside Diameter (D) 25.400 mm (Equiv. 1 in.)	Length (s) 25.400 mm _{+ 0.000 / - 0.330} (Equiv. 1 in.)	Flange OD (D1) 31.75 mm
Material: Iglidur Z Flange Thickness (s1): 1.58 mm
Part Number: BF0222-0254-0254-PZ (10 Pcs) Flanged Bushes - 22.225x25.4x25.4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $296.86 AUD Regular price ~~$356.24 AUD~~ Sale price $296.86 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0222-0254-0254-PZ (10 Pcs) --- Flanged Bushes - 22.225x25.4x25.4 mm Plastic - Iglidur Z Bush Sale BF0222-0254-0254-PZ (10 Pcs) --- Flanged Bushes - 22.225x25.4x25.4 mm Plastic - Iglidur Z Bush Regular price $296.86 AUD Regular price ~~$356.24 AUD~~ Sale price $296.86 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 25.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.984 in.)	Nominal Outside Diameter (D) 28.000 mm (Equiv. 1.102 in.)	Length (s) 21.500 mm _{+ 0.000 / - 0.330} (Equiv. 0.846 in.)	Flange OD (D1) 35.00 mm	Flange Thickness (s1) 1.50 mm
Material: Iglidur Z
Part Number: BF0250-0280-0215-PZ (10 Pcs) Flanged Bushes - 25x28x21.5 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $310.41 AUD Regular price ~~$372.49 AUD~~ Sale price $310.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 25.000 mm _{+ 0.020 / + 0.104} (Equiv. 0.984 in.)	Nominal Outside Diameter (D) 28.000 mm (Equiv. 1.102 in.)	Length (s) 21.500 mm _{+ 0.000 / - 0.330} (Equiv. 0.846 in.)	Flange OD (D1) 35.00 mm
Material: Iglidur Z Flange Thickness (s1): 1.50 mm
Part Number: BF0250-0280-0215-PZ (10 Pcs) Flanged Bushes - 25x28x21.5 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $310.41 AUD Regular price ~~$372.49 AUD~~ Sale price $310.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0250-0280-0215-PZ (10 Pcs) --- Flanged Bushes - 25x28x21.5 mm Plastic - Iglidur Z Bush Sale BF0250-0280-0215-PZ (10 Pcs) --- Flanged Bushes - 25x28x21.5 mm Plastic - Iglidur Z Bush Regular price $310.41 AUD Regular price ~~$372.49 AUD~~ Sale price $310.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 25.400 mm _{+ 0.020 / + 0.104} (Equiv. 1 in.)	Nominal Outside Diameter (D) 28.575 mm (Equiv. 1.125 in.)	Length (s) 25.400 mm _{+ 0.000 / - 0.330} (Equiv. 1 in.)	Flange OD (D1) 34.93 mm	Flange Thickness (s1) 1.58 mm
Material: Iglidur Z
Part Number: BF0254-0286-0254-PZ (10 Pcs) Flanged Bushes - 25.4x28.575x25.4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $324.05 AUD Regular price ~~$388.85 AUD~~ Sale price $324.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 25.400 mm _{+ 0.020 / + 0.104} (Equiv. 1 in.)	Nominal Outside Diameter (D) 28.575 mm (Equiv. 1.125 in.)	Length (s) 25.400 mm _{+ 0.000 / - 0.330} (Equiv. 1 in.)	Flange OD (D1) 34.93 mm
Material: Iglidur Z Flange Thickness (s1): 1.58 mm
Part Number: BF0254-0286-0254-PZ (10 Pcs) Flanged Bushes - 25.4x28.575x25.4 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $324.05 AUD Regular price ~~$388.85 AUD~~ Sale price $324.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0254-0286-0254-PZ (10 Pcs) --- Flanged Bushes - 25.4x28.575x25.4 mm Plastic - Iglidur Z Bush Sale BF0254-0286-0254-PZ (10 Pcs) --- Flanged Bushes - 25.4x28.575x25.4 mm Plastic - Iglidur Z Bush Regular price $324.05 AUD Regular price ~~$388.85 AUD~~ Sale price $324.05 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 28.575 mm _{+ 0.020 / + 0.104} (Equiv. 1.125 in.)	Nominal Outside Diameter (D) 32.544 mm (Equiv. 1.281 in.)	Length (s) 19.050 mm _{+ 0.000 / - 0.330} (Equiv. 0.75 in.)	Flange OD (D1) 39.68 mm	Flange Thickness (s1) 1.98 mm
Material: Iglidur Z
Part Number: BF0286-0325-0191-PZ (10 Pcs) Flanged Bushes - 28.575x32.544x19.05 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $310.41 AUD Regular price ~~$372.49 AUD~~ Sale price $310.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 28.575 mm _{+ 0.020 / + 0.104} (Equiv. 1.125 in.)	Nominal Outside Diameter (D) 32.544 mm (Equiv. 1.281 in.)	Length (s) 19.050 mm _{+ 0.000 / - 0.330} (Equiv. 0.75 in.)	Flange OD (D1) 39.68 mm
Material: Iglidur Z Flange Thickness (s1): 1.98 mm
Part Number: BF0286-0325-0191-PZ (10 Pcs) Flanged Bushes - 28.575x32.544x19.05 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $310.41 AUD Regular price ~~$372.49 AUD~~ Sale price $310.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0286-0325-0191-PZ (10 Pcs) --- Flanged Bushes - 28.575x32.544x19.05 mm Plastic - Iglidur Z Bush Sale BF0286-0325-0191-PZ (10 Pcs) --- Flanged Bushes - 28.575x32.544x19.05 mm Plastic - Iglidur Z Bush Regular price $310.41 AUD Regular price ~~$372.49 AUD~~ Sale price $310.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 28.575 mm _{+ 0.020 / + 0.104} (Equiv. 1.125 in.)	Nominal Outside Diameter (D) 32.544 mm (Equiv. 1.281 in.)	Length (s) 38.100 mm _{+ 0.000 / - 0.390} (Equiv. 1.5 in.)	Flange OD (D1) 39.68 mm	Flange Thickness (s1) 1.98 mm
Material: Iglidur Z
Part Number: BF0286-0325-0381-PZ (10 Pcs) Flanged Bushes - 28.575x32.544x38.1 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $446.41 AUD Regular price ~~$535.69 AUD~~ Sale price $446.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 28.575 mm _{+ 0.020 / + 0.104} (Equiv. 1.125 in.)	Nominal Outside Diameter (D) 32.544 mm (Equiv. 1.281 in.)	Length (s) 38.100 mm _{+ 0.000 / - 0.390} (Equiv. 1.5 in.)	Flange OD (D1) 39.68 mm
Material: Iglidur Z Flange Thickness (s1): 1.98 mm
Part Number: BF0286-0325-0381-PZ (10 Pcs) Flanged Bushes - 28.575x32.544x38.1 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $446.41 AUD Regular price ~~$535.69 AUD~~ Sale price $446.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0286-0325-0381-PZ (10 Pcs) --- Flanged Bushes - 28.575x32.544x38.1 mm Plastic - Iglidur Z Bush Sale BF0286-0325-0381-PZ (10 Pcs) --- Flanged Bushes - 28.575x32.544x38.1 mm Plastic - Iglidur Z Bush Regular price $446.41 AUD Regular price ~~$535.69 AUD~~ Sale price $446.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 26.000 mm _{+ 0.000 / - 0.330} (Equiv. 1.024 in.)	Flange OD (D1) 42.00 mm	Flange Thickness (s1) 2.00 mm
Material: Iglidur Z
Part Number: BF0300-0340-0260-PZ (10 Pcs) Flanged Bushes - 30x34x26 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $358.05 AUD Regular price ~~$429.65 AUD~~ Sale price $358.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 26.000 mm _{+ 0.000 / - 0.330} (Equiv. 1.024 in.)	Flange OD (D1) 42.00 mm
Material: Iglidur Z Flange Thickness (s1): 2.00 mm
Part Number: BF0300-0340-0260-PZ (10 Pcs) Flanged Bushes - 30x34x26 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $358.05 AUD Regular price ~~$429.65 AUD~~ Sale price $358.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0300-0340-0260-PZ (10 Pcs) --- Flanged Bushes - 30x34x26 mm Plastic - Iglidur Z Bush Sale BF0300-0340-0260-PZ (10 Pcs) --- Flanged Bushes - 30x34x26 mm Plastic - Iglidur Z Bush Regular price $358.05 AUD Regular price ~~$429.65 AUD~~ Sale price $358.05 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 37.000 mm _{+ 0.000 / - 0.390} (Equiv. 1.457 in.)	Flange OD (D1) 42.00 mm	Flange Thickness (s1) 2.00 mm
Material: Iglidur Z
Part Number: BF0300-0340-0370-PZ (10 Pcs) Flanged Bushes - 30x34x37 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $548.41 AUD Regular price ~~$658.09 AUD~~ Sale price $548.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 30.000 mm _{+ 0.020 / + 0.104} (Equiv. 1.181 in.)	Nominal Outside Diameter (D) 34.000 mm (Equiv. 1.339 in.)	Length (s) 37.000 mm _{+ 0.000 / - 0.390} (Equiv. 1.457 in.)	Flange OD (D1) 42.00 mm
Material: Iglidur Z Flange Thickness (s1): 2.00 mm
Part Number: BF0300-0340-0370-PZ (10 Pcs) Flanged Bushes - 30x34x37 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $548.41 AUD Regular price ~~$658.09 AUD~~ Sale price $548.41 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0300-0340-0370-PZ (10 Pcs) --- Flanged Bushes - 30x34x37 mm Plastic - Iglidur Z Bush Sale BF0300-0340-0370-PZ (10 Pcs) --- Flanged Bushes - 30x34x37 mm Plastic - Iglidur Z Bush Regular price $548.41 AUD Regular price ~~$658.09 AUD~~ Sale price $548.41 AUD Unit price per Out of stock! Backorder Now Sale
Nominal Inside Diameter (d) 31.750 mm _{+ 0.025 / + 0.125} (Equiv. 1.25 in.)	Nominal Outside Diameter (D) 35.719 mm (Equiv. 1.406 in.)	Length (s) 31.750 mm _{+ 0.000 / - 0.390} (Equiv. 1.25 in.)	Flange OD (D1) 42.85 mm	Flange Thickness (s1) 1.98 mm
Material: Iglidur Z
Part Number: BF0318-0357-0318-PZ (10 Pcs) Flanged Bushes - 31.75x35.719x31.75 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $732.05 AUD Regular price ~~$878.45 AUD~~ Sale price $732.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
Nominal Inside Diameter (d) 31.750 mm _{+ 0.025 / + 0.125} (Equiv. 1.25 in.)	Nominal Outside Diameter (D) 35.719 mm (Equiv. 1.406 in.)	Length (s) 31.750 mm _{+ 0.000 / - 0.390} (Equiv. 1.25 in.)	Flange OD (D1) 42.85 mm
Material: Iglidur Z Flange Thickness (s1): 1.98 mm
Part Number: BF0318-0357-0318-PZ (10 Pcs) Flanged Bushes - 31.75x35.719x31.75 mm Plastic - Iglidur Z Bush Out of Stock \| Backorder Now \| Orders can be expected around Wed, Oct 01, 2025 Regular price $732.05 AUD Regular price ~~$878.45 AUD~~ Sale price $732.05 AUD Unit price per Per 10 Quantity Required Backorder: Out of Stock.
BF0318-0357-0318-PZ (10 Pcs) --- Flanged Bushes - 31.75x35.719x31.75 mm Plastic - Iglidur Z Bush Sale BF0318-0357-0318-PZ (10 Pcs) --- Flanged Bushes - 31.75x35.719x31.75 mm Plastic - Iglidur Z Bush Regular price $732.05 AUD Regular price ~~$878.45 AUD~~ Sale price $732.05 AUD Unit price per Out of stock! Backorder Now Sale
