Belts - Timing 5.000mm Pitch - GT - 9mm Wide - Double Sided

Belts -> Timing 5.000mm Pitch -> GT -> 9mm Wide -> Double Sided

There are 5 products in the sub-categories of Belts - Timing 5.000mm Pitch - GT - 9mm Wide - Double Sided. Browse the Belts - Timing 5.000mm Pitch - GT - 9mm Wide - Double Sided products table.

Category Details

A selection of Double Sided 9mm Wide GT Timing 5.000mm Pitch Belts. GT2 and GT3 Series Metric Timing Belts Double Sided

  • Timing belts combined with timing pulleys, provide power transmission without slippage.
  • Timing belts are toothed belts used to synchronize the movement of different mechanical components, ensuring precise timing and coordination.
  • Some uses for timing belts include 3D printers, CNC machines, robotics and automation components, textile machinery, office equipment such as scanners and copiers, and medical devices requiring precise movement control.
  • Breaking strength is not indicative of working strength. Belts working load should be rated at approximately 1/15th of their ultimate breaking strength.
  • Tooth Height (H) - 1.93mm
  • Belt Height (W) - 5mm
  • GT3 replaces GT2 as GT2 stock is depleted
  • Pitch (P) - 5mm

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Belts - Timing 5.000mm Pitch - GT - 9mm Wide - Double Sided category on the Small Parts & Bearings online store.
Number of Teeth Length Width Reinforcement Appearance Indicative
Number of Teeth
140

Length
700
mm

(Equiv. 27.559 in.)
Width
9.0

Reinforcement
Fibreglass (GT2) or Carbon Fibre (GT3)
Appearance
Black
Timing 5.000mm Pitch Belts - 140 tooth - 700 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0140-0090-NFB
Timing 5mm Pitch Belts - 140 tooth - 700 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$120.77 AUD
$120.77 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth Length Width Indicative
Number of Teeth
140

Length
700
mm

(Equiv. 27.559 in.)
Width
9.0

Timing 5.000mm Pitch Belts - 140 tooth - 700 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Reinforcement: Fibreglass (GT2) or Carbon Fibre (GT3)    Appearance: Black    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0140-0090-NFB
Timing 5mm Pitch Belts - 140 tooth - 700 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$120.77 AUD
$120.77 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
210

Length
1050
mm

(Equiv. 41.339 in.)
Width
9.0

Reinforcement
Fibreglass (GT2) or Carbon Fibre (GT3)
Appearance
Black
Timing 5.000mm Pitch Belts - 210 tooth - 1050 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0210-0090-NFB
Timing 5mm Pitch Belts - 210 tooth - 1050 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$151.95 AUD
$182.35 AUD $151.95 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
210

Length
1050
mm

(Equiv. 41.339 in.)
Width
9.0

Timing 5.000mm Pitch Belts - 210 tooth - 1050 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Reinforcement: Fibreglass (GT2) or Carbon Fibre (GT3)    Appearance: Black    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0210-0090-NFB
Timing 5mm Pitch Belts - 210 tooth - 1050 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$151.95 AUD
$182.35 AUD $151.95 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
319

Length
1595
mm

(Equiv. 62.795 in.)
Width
9.0

Reinforcement
Fibreglass (GT2) or Carbon Fibre (GT3)
Appearance
Black
Timing 5.000mm Pitch Belts - 319 tooth - 1595 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0319-0090-NFB
Timing 5.000mm Pitch Belts - 319 tooth - 1595 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$229.23 AUD
$275.07 AUD $229.23 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
319

Length
1595
mm

(Equiv. 62.795 in.)
Width
9.0

Timing 5.000mm Pitch Belts - 319 tooth - 1595 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Reinforcement: Fibreglass (GT2) or Carbon Fibre (GT3)    Appearance: Black    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0319-0090-NFB
Timing 5.000mm Pitch Belts - 319 tooth - 1595 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$229.23 AUD
$275.07 AUD $229.23 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
450

Length
2250
mm

(Equiv. 88.583 in.)
Width
9.0

Reinforcement
Fibreglass (GT2) or Carbon Fibre (GT3)
Appearance
Black
Timing 5.000mm Pitch Belts - 450 tooth - 2250 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0450-0090-NFB
Timing 5.000mm Pitch Belts - 450 tooth - 2250 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$321.95 AUD
$386.35 AUD $321.95 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
450

Length
2250
mm

(Equiv. 88.583 in.)
Width
9.0

Timing 5.000mm Pitch Belts - 450 tooth - 2250 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Reinforcement: Fibreglass (GT2) or Carbon Fibre (GT3)    Appearance: Black    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0450-0090-NFB
Timing 5.000mm Pitch Belts - 450 tooth - 2250 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$321.95 AUD
$386.35 AUD $321.95 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
686

Length
3430
mm

(Equiv. 135.039 in.)
Width
9.0

Reinforcement
Fibreglass (GT2) or Carbon Fibre (GT3)
Appearance
Black
Timing 5.000mm Pitch Belts - 686 tooth - 3430 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0686-0090-NFB
Timing 5.000mm Pitch Belts - 686 tooth - 3430 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$489.05 AUD
$586.85 AUD $489.05 AUD
Each
Quantity Required

Backorder: Out of Stock.
Number of Teeth
686

Length
3430
mm

(Equiv. 135.039 in.)
Width
9.0

Timing 5.000mm Pitch Belts - 686 tooth - 3430 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords
Material: Nylon Covered Neoprene Rubber with Fibreglass (GT2) or Carbon Fibre (GT3) Cords    Reinforcement: Fibreglass (GT2) or Carbon Fibre (GT3)    Appearance: Black    Breaking Strength: 3465 N    Min Temperature (C): -34 Deg C    Max Temperature (C): 85 Deg C
Part Number: BD-050G-0686-0090-NFB
Timing 5.000mm Pitch Belts - 686 tooth - 3430 mm - 9 - Nylon Covered Neoprene Rubber with Fibreglass GT2 or Carbon Fibre GT3 Cords Belt
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 17, 2025
$489.05 AUD
$586.85 AUD $489.05 AUD
Each
Quantity Required

Backorder: Out of Stock.
