Bearings - Double Row Ball - Radial

Bearings -> Double Row Ball -> Radial

There are 2 products in the sub-categories of Bearings - Double Row Ball - Radial. Browse the Bearings - Double Row Ball - Radial products table. To narrow down the selection, please choose a sub-category from the links below.

Category Details

This category includes various types of double row ball bearings.
  • Double row ball bearings are generally wider than a single row bearing of equivalent ID and OD.
  • The double row ball bearing accommodates much higher loads than a single row bearing.
  • An expanded range may be available on special order. Please enquire.

Miniature Bearings Australia - MBA Minibearings

Additional resources:


A more concise listing may be found in the Bearings - Double Row Ball - Radial category on the Small Parts & Bearings online store.
ID (d) OD (D) Width (B) Inner Ring Width (Bn) Radius (r) Basic Dynamic Load Cr Indicative
ID (d)
6.350
mm

(Equiv. 0.25 in.)
OD (D)
19.050
mm

(Equiv. 0.75 in.)
Width (B)
19.050
mm

(Equiv. 0.75 in.)
Inner Ring Width (Bn)
22.225
mm
Double Row Ball Bearings - 6.35x19.05x19.05 mm / 22.225 mm - Chrome Steel SAE 52100 - Cadmium Plated
Material: Chrome Steel SAE 52100 - Cadmium Plated    Precision Grade: Abec 7
Category: Bearings - Double Row Ball - Radial - Chrome Steel
Part Number: DR-WR4-12E-TTS-ECO
Double Row Ball Bearings - 6.35x19.05x19.05 mm / 22.225 mm Radial - Chrome Steel SAE 52100 - Cadmium Plated Bearing
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 10, 2025
$27.59 AUD
$33.11 AUD $27.59 AUD
Each
Quantity Required

Backorder: Out of Stock.
ID (d) OD (D) Width (B) Inner Ring Width (Bn) Indicative
ID (d)
6.350
mm

(Equiv. 0.25 in.)
OD (D)
19.050
mm

(Equiv. 0.75 in.)
Width (B)
19.050
mm

(Equiv. 0.75 in.)
Inner Ring Width (Bn)
22.225
mm
Double Row Ball Bearings - 6.35x19.05x19.05 mm / 22.225 mm - Chrome Steel SAE 52100 - Cadmium Plated
Material: Chrome Steel SAE 52100 - Cadmium Plated    Precision Grade: Abec 7
Category: Bearings - Double Row Ball - Radial - Chrome Steel
Part Number: DR-WR4-12E-TTS-ECO
Double Row Ball Bearings - 6.35x19.05x19.05 mm / 22.225 mm Radial - Chrome Steel SAE 52100 - Cadmium Plated Bearing
Out of Stock | Backorder Now | Orders can be expected around Fri, Oct 10, 2025
$27.59 AUD
$33.11 AUD $27.59 AUD
Each
Quantity Required

Backorder: Out of Stock.
ID (d)
15.000
mm

(Equiv. 0.591 in.)
OD (D)
26.000
mm

(Equiv. 1.024 in.)
Width (B)
10.000
mm

(Equiv. 0.394 in.)
Double Row Ball Bearings - 15x26x10 mm - Chrome Steel SAE 52100
Material: Chrome Steel SAE 52100    Precision Grade: Economy
Category: Bearings - Double Row Ball - Radial - Chrome Steel
Part Number: DMR2615B-2RS-ECO
Double Row Ball Bearings - 15x26x10 mm Radial - Chrome Steel SAE 52100 Bearing
75 Available Now | Further orders can be expected around Fri, Sep 26, 2025
$12.14 AUD
$12.14 AUD
Each
Quantity Required

75 Available Now. Backorder if more than 75.
ID (d)
15.000
mm

(Equiv. 0.591 in.)
OD (D)
26.000
mm

(Equiv. 1.024 in.)
Width (B)
10.000
mm

(Equiv. 0.394 in.)
Double Row Ball Bearings - 15x26x10 mm - Chrome Steel SAE 52100
Material: Chrome Steel SAE 52100    Precision Grade: Economy
Category: Bearings - Double Row Ball - Radial - Chrome Steel
Part Number: DMR2615B-2RS-ECO
Double Row Ball Bearings - 15x26x10 mm Radial - Chrome Steel SAE 52100 Bearing
75 Available Now | Further orders can be expected around Fri, Sep 26, 2025
$12.14 AUD
$12.14 AUD
Each
Quantity Required

75 Available Now. Backorder if more than 75.
