Miniature Bearings Australia
RNAST30 - Datasheet
MBA
Category Information
Rollers - Track - Without Inner raceWithout Inner race Track Rollers. This is the main category in this series
Product Data
- ID (d)
:
38.00
mm
(Equiv. 1.496 in.) - OD (D)
62.00
mm
(Equiv. 2.441 in.) - Width (C)
19.80
mm
(Equiv. 0.78 in.) - Inner Ring Width (B) 20.00 mm
- OD Type Cylindrical
- Dynamic Load Rating 3110.00 kgf
- Static Load Rating 4630.00 kgf
- Material Steel
Product Compliance and Data
Additional Resources
Cross References
- Nachi RNAST-30
- RNAST30
