Miniature Bearings Australia
RNAST20R - Datasheet
MBA
Category Information
Rollers - Track - Without Inner raceWithout Inner race Track Rollers. This is the main category in this series
Product Data
- ID (d)
:
25.00
mm
(Equiv. 0.984 in.) - OD (D)
47.00
mm
(Equiv. 1.85 in.) - Width (C)
15.80
mm
(Equiv. 0.622 in.) - Inner Ring Width (B) 16.00 mm
- OD Type Radius (500mm)
- Dynamic Load Rating 1980.00 kgf
- Static Load Rating 2500.00 kgf
Product Compliance and Data
Additional Resources
Cross References
- Nachi RNAST-20R
- RNAST20R
