Miniature Bearings Australia
RNAST12 - Datasheet
MBA
Category Information
Rollers - Track - Without Inner raceWithout Inner race Track Rollers. This is the main category in this series
Product Data
- ID (d)
:
16.00
mm
(Equiv. 0.63 in.) - OD (D)
32.00
mm
(Equiv. 1.26 in.) - Width (C)
11.80
mm
(Equiv. 0.465 in.) - Inner Ring Width (B) 12.00 mm
- OD Type Cylindrical
- Dynamic Load Rating 1070.00 kgf
- Static Load Rating 1110.00 kgf
- Material Steel
Product Compliance and Data
Additional Resources
Cross References
- Nachi RNAST-12
- RNAST12
