Download the MBA Taper Pins Catalogue
The Taper Pins Catalogue is available to download from the link above. The catalogue includes imperial - inch - sized pins with a 1:48 taper, and metric pins with a 1:50 taper. Several extractable pins are also available with internal or external threads. Carbon steel and stainless steel versions are available.
Imperial pins are identified by their large end diameter, whilst metric pins are identified by their small end diameter. If the length pin you require is not available, you may consider whether you can cut a longer pin to suit your requirement, but if using an extractable pin, keep in mind whether cutting the pin will necessitate removal of the extraction thread.
