NT0095C-HX-AL - Datasheet
MBA
Category Information
Nuts - Hexagonal - Full - AluminiumAluminium Full Hexagonal Nuts. METRIC.
- An expanded range may be available on special order. Please enquire.
- Note! Thickness (H) and A/F (A) dimensions are usually considered not critical and may vary.
- If the A and H dimensions are critical for your application please consult us prior to ordering.
Product Data
- Thread Size : 3/8-16 UNC (9.53mm)
- Thickness (H) 8.33 mm
- Across Flats (A/F) 14.29 mm
- Type Hex Nut
- Pitch 1.588 mm
- Threads Per Inch 16 TPI
