COL-01270-028-28-GF-S4 - Datasheet
ENQUIRE
Category Information
Collars - Shaft - Gripfast - 304 Stainless Steel304 Stainless Steel Gripfast Shaft Collars. Self Locking - Quick Release.
- Simple, ring-shaped component, typically made of metal or plastic, that fastens around a round shaft to hold other parts in place or to act as a mechanical stop.
- Essential in power transmission applications for securing items like bearings, sprockets, and gear assemblies.
- 304 Stainless Body, Retention Ring, Balls and Springs.
Product Data
- Suitable Shaft Size (d) : 12.700 mm
- Outside Diameter (D) 28.30 mm
- Overall Width (S) 27.9 mm
- Sleeve Length (D) 20.371 mm
- Material Stainless Steel 304 (Similar to A2 or 18-8) HRB80
Product Compliance and Data
Additional Resources
Cross References
- Reid Tool® SMI-500SS-REFQt.6888442
- Reid Tool® SMI-500SS-REF-Qt.-6888442
- A7X34-0500
- A7X340500
- SMI500SSREFQt6888442
