Miniature Bearings Australia
COL-00953-028-28-GF-S4 - Datasheet
MBA
Category Information
Collars - Shaft - Gripfast - 304 Stainless Steel304 Stainless Steel Gripfast Shaft Collars. Self Locking - Quick Release.
- 304 Stainless Body, Retention Ring, Balls and Springs.
Product Data
- Suitable Shaft Size (d)
:
9.525
mm
(Equiv. 0.375 in.) - Outside Diameter (D)
28.30
mm
(Equiv. 1.114 in.) - Overall Width (S)
27.9
mm
(Equiv. 1.098 in.) - Sleeve Length (D) 20.371 mm
- Material Stainless Steel 304 (Similar to A2, 18-8) HRB80
Product Compliance and Data
Additional Resources
Cross References
- A7X34-0375
- A7X340375
- SMI-375SS
- SMI375SS
