Miniature Bearings Australia - MBA Minibearings
Miniature Bearings Australia

COL-00800-018-08-NY - Datasheet

MBA

Category Information

Collars - Shaft - Standard - Nylon

Nylon Standard Shaft Collars. Standard one piece nylon shaft collar with set screw

  • Static torque and axial load are for reference only using steel cup point grub screw on soft steel shaft

Product Data

  • Suitable Shaft Size (d) : 8.000 mm + 0.000 / + 0.022
    (Equiv. 0.315 in.)
  • Outside Diameter (D) 18.00 mm
    (Equiv. 0.709 in.)
  • Overall Width (S) 8.0 mm
    (Equiv. 0.315 in.)
  • Material Nylon (Polyamide 6/6)
Country of Origin: JP

Product Compliance and Data

Additional Resources

Cross References

  • COL0080001818NY
View full details
COL-00800-018-08-NYDiagramCOL-00800-018-08-NYImage
