Miniature Bearings Australia
687A-ZZ-MC3 - Datasheet
MBA
Category Information
Bearings - Single Row Ball - Unflanged - Precision - Chrome SteelChrome Steel Precision Unflanged Single Row Ball Bearings. Chrome steel radial ball bearings.
- Single row radial ball bearings are arguably the most common, widely used type of bearing. They consist of an inner ring, an outer ring, a set of balls, and a cage that retains the balls in a circular path.
- Single row radial ball bearings are commonly used in a wide range of applications, including electric motors, fans, pumps, gearboxes, agricultural equipment, appliances, and automotive components.
- They are versatile, cost-effective bearings that provide reliable support for radial loads and some axial loads in one direction. An expanded range may be available on special order. Please enquire.
- Standard single row radial ball bearings.
Product Data
- ID (d)
:
7.000
mm
+ 0.000 / - 0.0075
(Equiv. 0.276 in.) - OD (D)
14.000
mm
+ 0.000 / - 0.0075
(Equiv. 0.551 in.) - Width (B)
5.000
mm
+ 0.000 / - 0.125
(Equiv. 0.197 in.) - Precision Grade Abec 1
- Closure Type ZZ
- Bearing Type Radial
- Material Chrome Steel SAE 52100
- Lubrication Type Grease
- Lubrication Name Standard Unspecified
- Basic Part 687A
- Limiting Speed 40000
- Cage Type Ribbon
- Static Load Rating KGf 52
- Dynamic Load Rating KGf 120
- Radii 0.15 mm
- Inner Shoulder (UI) 8.50mm
- Outer Shoulder (UO) 12.70 mm
- Number of Balls 9
- Clearance MC3 (5 to 10)
- Precision Grade Abec 1
- Closure Type ZZ
- Max Temperature 120 Deg. C
Product Compliance and Data
Additional Resources
- Catalogue: Ceramic Bearings Catalogue
- Catalogue: Plastic Bearings Catalogue
- Catalogue: Standard Bearings Catalogue
- General: Bearing Cleanliness
- General: Bearing Clearances
- General: Bearing Flanges & Snap Rings
- General: Bearing Retainers (Cages)
- General: General Loads Information
- General: Lubrication
- General: Prefix & Suffix Guide
- General: Static vs Dynamic Loads
- Materials: 316 Stainless
- Materials: CASSTOP Anti-Corrosion Bearing Material
- Materials: Ceramic vs Ceramic Hybrid
- Materials: Ceramic Bearings in Vibratory Applications
- Materials: Ceramic Hybrid Bearings in Vibratory Applications
- Materials: General Bearing Materials
- Materials: Magnetism & Bearings
- Precision: 316 Stainless & Plastic Bearing Tolerances
- Precision: ABEC Basic Information
- Precision: Precision Bearing Tolerances
- Problem Solving: Bearing Failure
- Problem Solving: Fatigue (L10 Life)
- Problem Solving: Noise
Applications & Uses
- RC Car Parts
- RC Helicopter Parts
- Serpent - Impact-2 2WD Pro - Diff Inside Bearing
- Serpent - Impact-2 2WD Sport - Diff Rear Inside Bearing
- Kyosho - CONCEPT 10 - 28 Bearing
- Kyosho - CONCEPT 10 - Bearing 7-14-5mm
Cross References
- BOSCH 1900905048
- WIB 628-7-2Z
- WIB 628-7-ZZ
- Shielded Width A 687/5
- GRW 687-2Z
- Shielded 687A / 5
- NTN 687-ZZ
- Kyosho 9075
- ADR AX7-ZZ
- MPB UL70CHH
- NTN W687A-ZZ
- NTN W687-ZZ
- W687ZZ
- W687AZZ
- 62872Z
- 6287ZZ
- AX7ZZ
- L1470-ZZ
- L1470ZZ
- 6872Z
- 687SS
- 687A-ZZMC3
- 687AZZMC3
- 687A Basic Size Ref
