MR84A-ZZS-ECO - Datasheet

ECO

Category Information

Bearings - Single Row Ball - Unflanged - Precision - Chrome Steel

Chrome Steel Precision Unflanged Single Row Ball Bearings. Chrome steel radial ball bearings.

  • Single row radial ball bearings are arguably the most common, widely used type of bearing. They consist of an inner ring, an outer ring, a set of balls, and a cage that retains the balls in a circular path.
  • Single row radial ball bearings are commonly used in a wide range of applications, including electric motors, fans, pumps, gearboxes, agricultural equipment, appliances, and automotive components.
  • They are versatile, cost-effective bearings that provide reliable support for radial loads and minimal axial load in one direction. An expanded range may be available on special order. Please enquire.
  • Standard single row radial ball bearings.

Product Data

  • ID (d) : 4.000 mm
    (Equiv. 0.157 in.)
  • O.D. (D) 8.000 mm
    (Equiv. 0.315 in.)
  • Width (B) 3.000 mm
    (Equiv. 0.118 in.)
  • Precision Grade Economy
  • Closure Type ZZS
  • Bearing Type Radial
  • Material Chrome Steel SAE 52100
  • Lubrication Type Grease
  • Lubrication Name Standard Unspecified
  • Basic Part MR84A
  • Limiting Speed 53200
  • Cage Type Standard
  • Static Load Rating KGf 13.3
  • Dynamic Load Rating KGf 38
  • Radii 0.15 mm
  • Inner Shoulder (UI) 5.00mm
  • Outer Shoulder (UO) 7.40 mm
  • Number of Balls 7
  • Clearance ECO (5 to 23)
  • Precision Grade ECO
  • Closure Type ZZS
  • Max Temperature 120 Deg. C
Country of Origin: TW

Product Compliance and Data

Additional Resources

Applications & Uses

  • RC Boat Parts
  • RC Car Parts
  • RC Helicopter Parts
  • Kyosho® - Blade Runner - Bearing 4-8-3mm
  • Academy® & MRC® - STR-4 1/10 Scale - Bearing 4-8-3mm
  • A-Tech® - XMB4 Buggy - Bearing 4-8-3mm
  • A-Tech® - XMT-4 Truck - Bearing 4-8-3mm
  • Bergonzoni® - Flash 1/8 Special Modified - Bearing 4-8-3mm
  • Cox® - Tomahawk - Bearing 4-8-3mm
  • Cross Fire Force® - F1 Electric - Bearing 4-8-3mm
  • Dialed® - Lightning - Bearing 4-8-3mm
  • FSR - Bullet Modified Losi - Bearing 4-8-3mm
  • Hot Bodies® - Cyclone - Bearing 4-8-3mm
  • HPI - Nitro RS4 Sport - Bearing 4-8-3mm
  • HPI - R40 - Bearing 4-8-3mm
  • HPI - R40 With Clutch Bell And Steering - Bearing 4-8-3mm
  • HPI - RS4 - Bearing 4-8-3mm
  • HPI - RS4 Mini - Bearing 4-8-3mm
  • HPI - RS4 Mini Pro - Bearing 4-8-3mm
  • HPI - RS4 MT - Bearing 4-8-3mm
  • HPI - RS4 Nitro RaceR 2 Car - Bearing 4-8-3mm
  • HPI - RS4 Pro - Bearing 4-8-3mm
  • HPI - RS4 Pro 2 With Steering - Bearing 4-8-3mm
  • HPI - RS4 Pro 3 - Bearing 4-8-3mm
  • HPI - RS4 Pro Sport - Bearing 4-8-3mm
  • HPI - RS4 Pro3 Spec - Bearing 4-8-3mm
  • HPI - RS4 RaceR 2 - Bearing 4-8-3mm
  • HPI - RS4 Rally - Bearing 4-8-3mm
  • HPI - RS4 Sport 2 Complete Kit - Bearing 4-8-3mm
  • HPI - RTR Sprint - Bearing 4-8-3mm
  • HPI - Super Nitro RS4 - Bearing 4-8-3mm
  • HPI - Super Nitro RS4 Rally - Bearing 4-8-3mm
  • Kawada® - SV10GT - Bearing 4-8-3mm
  • Kyosho® - Aero Streak - Bearing 4-8-3mm
  • Kyosho® - Baha Bugs - Bearing 4-8-3mm
  • Kyosho® - Baja Bugs - Bearing 4-8-3mm
  • Kyosho® - Benitone B192 - Bearing 4-8-3mm
  • Kyosho® - Big Boss - Bearing 4-8-3mm
  • Kyosho® - Big Brute - Bearing 4-8-3mm
  • Kyosho® - Big Brute - Big Boss - Hi-Rider - Bearing 4-8-3mm
  • Kyosho® - Corvette - Bearing 4-8-3mm
  • Kyosho® - Double Dare USA-1 - Bearing 4-8-3mm
  • Kyosho® - EP Alpha 4WD - Bearing 4-8-3mm
  • Kyosho® - EP Spider - Bearing 4-8-3mm
  • Kyosho® - EP Ultima® RB Type R - Bearing 4-8-3mm
  • Kyosho® - F1 Impress - Bearing 4-8-3mm
  • Kyosho® - Ferrari F189 - Bearing 4-8-3mm
  • Kyosho® - Ferrari F92A - Bearing 4-8-3mm
  • Kyosho® - Formula 1 Benitone B192 - Bearing 4-8-3mm
  • Kyosho® - Formula 1 Ferrari F92A - Bearing 4-8-3mm
  • Kyosho® - Formula 1 Jordan Yam - Bearing 4-8-3mm
  • Kyosho® - Formula 1 Williams - Bearing 4-8-3mm
  • Kyosho® - Formula 1 Williams FW14 - Bearing 4-8-3mm
  • Kyosho® - FW14 Jordan Yam - Bearing 4-8-3mm
  • Kyosho® - Gallop MK-II - Bearing 4-8-3mm
  • Kyosho® - GP Alpha 4WD - Bearing 4-8-3mm
  • Kyosho® - GP Ultima® RB RTR - Bearing 4-8-3mm
  • Kyosho® - Half 8 Mini Inferno - Bearing 4-8-3mm
  • Kyosho® - Heavy Metal Tank - Bearing 4-8-3mm
  • Kyosho® - Hi-Rider - Bearing 4-8-3mm
  • Kyosho® - Indy Scotch - Bearing 4-8-3mm
  • Kyosho® - Laser ZX - Bearing 4-8-3mm
  • Kyosho® - Laser ZX Upgrade - Bearing 4-8-3mm
  • Kyosho® - Mclaren Formula 1 - Bearing 4-8-3mm
  • Kyosho® - Mclarin Formula 1 - Bearing 4-8-3mm
  • Kyosho® - Montero - Bearing 4-8-3mm
  • Kyosho® - Nissan 300ZX - Bearing 4-8-3mm
  • Kyosho® - Nitro Blizzard - Bearing 4-8-3mm
  • Kyosho® - Optionima-Mid - Bearing 4-8-3mm
  • Kyosho® - Optionima-Mid Optionima Mid Turbo SE - Bearing 4-8-3mm
  • Kyosho® - Optionima-Mid Turbo SE - Bearing 4-8-3mm
  • Kyosho® - Outlaw Rampage 1/10 Gas - Bearing 4-8-3mm
  • Kyosho® - Outlaw RMPG 1/10 Gas. - Bearing 4-8-3mm
  • Kyosho® - Outlaw Truck - Bearing 4-8-3mm
  • Kyosho® - Outlaw Truck Ultima® Pro XL - Bearing 4-8-3mm
  • Kyosho® - Outrage ST - Bearing 4-8-3mm
  • Kyosho® - Penske PC19 - Bearing 4-8-3mm
  • Kyosho® - Penske PC19 ZR1 Rampage Gas - Bearing 4-8-3mm
  • Kyosho® - Porsche 911 - Turbo - Nissan 300 ZX - Bearing 4-8-3mm
  • Kyosho® - Porsche 911 Turbo - Bearing 4-8-3mm
  • Kyosho® - ProX and Trans - Bearing 4-8-3mm
  • Kyosho® - Pure Ten - Bearing 4-8-3mm
  • Kyosho® - Pure Ten EP Alpha 4WD - Bearing 4-8-3mm
  • Kyosho® - Quad Rider Gas - Bearing 4-8-3mm
  • Kyosho® - Raider - Bearing 4-8-3mm
  • Kyosho® - Raider - Turbo Raider - Bearing 4-8-3mm
  • Kyosho® - Rampage 10 - ZR-1 Corvette Slingshot - Bearing 4-8-3mm
  • Kyosho® - Rampage Sport 31324 - Bearing 4-8-3mm
  • Kyosho® - Rocky - Bearing 4-8-3mm
  • Kyosho® - Sandmaster Gas - Bearing 4-8-3mm
  • Kyosho® - Shadow - Bearing 4-8-3mm
  • Kyosho® - Sideways - Bearing 4-8-3mm
  • Kyosho® - Slingshot - Bearing 4-8-3mm
  • Kyosho® - SR5 Truck - Bearing 4-8-3mm
  • Kyosho® - Stinger - Bearing 4-8-3mm
  • Kyosho® - TF3 Series - Bearing 4-8-3mm
  • Kyosho® - TF-4 Spider Type R - Bearing 4-8-3mm
  • Kyosho® - Thunderbird Gas - Bearing 4-8-3mm
  • Kyosho® - Triumph - Bearing 4-8-3mm
  • Kyosho® - Turbo Raider - Bearing 4-8-3mm
  • Kyosho® - Ultima - Bearing 4-8-3mm
  • Kyosho® - Ultima® II - Bearing 4-8-3mm
  • Kyosho® - Ultima® Pro XL - Bearing 4-8-3mm
  • Kyosho® - Ultima® ST EP Sports - Bearing 4-8-3mm
  • Kyosho® - Ultima® ST GP Evolution Type R - Bearing 4-8-3mm
  • Kyosho® - Ultima® ST GP Sports - Bearing 4-8-3mm
  • Kyosho® - Ultima® ST Truck - Bearing 4-8-3mm
  • Kyosho® - Ultima® ST Truck With Steering - Bearing 4-8-3mm
  • Kyosho® - V-One S 2 Speed - Bearing 4-8-3mm
  • Kyosho® - VW Beetle-Buick Stocker-Mini Cooper-Super Alta - Bearing 4-8-3mm
  • Kyosho® - ZR1 - Rampage Gas - Bearing 4-8-3mm
  • Kyosho® - ZR1 Rampage 10 - Bearing 4-8-3mm
  • Kyosho® - ZR1 Rampage Complete Gas - Bearing 4-8-3mm
  • Kyosho® - ZR1 Rampage Upgrade Gas - Bearing 4-8-3mm
  • Ofna® - Street Racer 1/10 Gas - Bearing 4-8-3mm
  • Schumaker® - 21XS - Bearing 4-8-3mm
  • Schumaker® - Cat 2000 SE - Bearing 4-8-3mm
  • Schumaker® - Cougar 2000 - Bearing 4-8-3mm
  • Schumaker® - Cougar 2000 1995 Team Car - Bearing 4-8-3mm
  • Schumaker® - Fire Blade 2000 - Bearing 4-8-3mm
  • Schumaker® - FireBlade Evo - Bearing 4-8-3mm
  • Schumaker® - Nitro Storm 10 - Bearing 4-8-3mm
  • Schumaker® - Storm Truck 2000 - Bearing 4-8-3mm
  • Tamiya® - DJ TRF 414 Pro Module Suspension - Bearing 4-8-3mm
  • Tamiya® - Max Climber TLT-1 - Bearing 4-8-3mm
  • Tamiya® - Nitro Force - Bearing 4-8-3mm
  • Tamiya® - Rock Buster TLT-1 - Bearing 4-8-3mm
  • Tamiya® - T-05 Upgrade - Bearing 4-8-3mm
  • Tamiya® - TA-05 - Bearing 4-8-3mm
  • Tamiya® - Terra Crusher - Bearing 4-8-3mm
  • Tamiya® - TFF 415MS X - Bearing 4-8-3mm
  • Tamiya® - TNX Nitro With Steering - Bearing 4-8-3mm
  • Tamiya® - TRF 414 - Bearing 4-8-3mm
  • Tamiya® - TRF 414-DJ Pro Module Suspension - Bearing 4-8-3mm
  • Tamiya® - TRF 415 - Bearing 4-8-3mm
  • Tamiya® - TRF 415MS - Bearing 4-8-3mm
  • Tamiya® - TRF 415MS Complete - Bearing 4-8-3mm
  • Team Associated® - YZ10 - Bearing 4-8-3mm
  • Team Losi® - JRX-S 4 Wheel Sedan - Bearing 4-8-3mm
  • Team Losi® - Mini LST - Bearing 4-8-3mm
  • Team Losi® - Mini T - Bearing 4-8-3mm
  • Team Losi® - Mini T Pro - Bearing 4-8-3mm
  • Team Losi® - Mini ZT - Bearing 4-8-3mm
  • Tenth Technology® - Predator - Bearing 4-8-3mm
  • Tower® - ST Nitro-15 - Bearing 4-8-3mm
  • Venom® Racing - Mini Giant RTR 4WD - Bearing 4-8-3mm
  • XTM Racing - Nitro X-Cellerator Racer - Bearing 4-8-3mm
  • XTM Racing - Nitro X-Cellerator RTR 2WD - Bearing 4-8-3mm
  • XTM Racing - X-Cellerator Stadium Truck RTR - Bearing 4-8-3mm
  • Yokomo® - GT-4R - Bearing 4-8-3mm
  • Yokomo® - Hot Dog - Bearing 4-8-3mm
  • Yokomo® - MR-4 Rally - Bearing 4-8-3mm
  • Yokomo® - MR-4BC Special - Bearing 4-8-3mm
  • Yokomo® - MR-4BX - Bearing 4-8-3mm
  • Yokomo® - MR-4MT - Bearing 4-8-3mm
  • Yokomo® - MR-4TC - Bearing 4-8-3mm
  • Yokomo® - MR-4TC BD - Bearing 4-8-3mm
  • Yokomo® - MR-4TC Custom - Bearing 4-8-3mm
  • Yokomo® - MR-4TC SD CGM - Bearing 4-8-3mm
  • Yokomo® - MR-4TC SD CM Drift Package - Bearing 4-8-3mm
  • Yokomo® - MR-4TC SD SSG /Black - Bearing 4-8-3mm
  • Yokomo® - MR-4TC SP - Bearing 4-8-3mm
  • Yokomo® - MR-4TC With Bell Crank Steering - Bearing 4-8-3mm
  • Yokomo® - MX4 - Belt Tensioner Bearing
  • Yokomo® - MX4 - Diff Assembly Bearing
  • Yokomo® - MX4 - Slipper Clutch Bearing
  • Yokomo® - MX4 - Steering - Servo Saver Bearing
  • Yokomo® - Works 93 - Bearing 4-8-3mm
  • Yokomo® - YR-4 II - Bearing 4-8-3mm
  • Yokomo® - YR-4GP - Bearing 4-8-3mm
  • Yokomo® - YR-4M - Bearing 4-8-3mm
  • Yokomo® - YRF-2 - Bearing 4-8-3mm
  • Yokomo® - YZ10 - Bearing 4-8-3mm
  • Yokomo® - YZ10W - Bearing 4-8-3mm
  • Align® - Trex 450 SE Special V2 - Bearing 4-8-3mm
  • Century® - Falcon 46/50 SE II - Bearing 4-8-3mm
  • Century® - Predator 60 SE - Bearing 4-8-3mm
  • Century® - Predator 60/70 - Bearing 4-8-3mm
  • Century® - Predator Gas SE Complete - Bearing 4-8-3mm
  • Century® - Predator Gasser Complete - Bearing 4-8-3mm
  • Century® - Predator Max 90 - Bearing 4-8-3mm
  • E-Flite® - Blade CX Coaxial - Bearing 4-8-3mm
  • E-Sky® - Lama V3 - 2345
  • E-Sky® - Lama V4 - 2345
  • GMP - Cobra - 9581 Bearing
  • GMP - Competition - 9581 Bearing
  • GMP - Cricket - 9581 Bearing
  • GMP - Elite Rotor Head - 9581 Bearing
  • GMP - Legend - 9581 Bearing
  • GMP - Rebel - 9581 Bearing
  • GMP - Stork - 9581 Bearing
  • Hirobo® - Lepton EX - Bearing 4-8-3mm
  • Hirobo® - Sceadu 30 Evolution - Bearing 4-8-3mm
  • Hirobo® - Sceadu 50 Evolution - Bearing 4-8-3mm
  • Hirobo® - SST Eagle Freya - Bearing 4-8-3mm
  • JR - Venture 50 ARF - Bearing 4-8-3mm
  • Kyosho® - CONCEPT 10 - 50 Bearing
  • Kyosho® - CONCEPT 10 - Bearing 4-8-3mm
  • Kyosho® - CONCEPT 60 R - 220 Bearing
  • Kyosho® - CONCEPT 60 SR - Bearing 4-8-3mm
  • Mikado® - Logo 20 - Bearing 4-8-3mm
  • Synergy® - N9 - Bearing 4-8-3mm
  • Thunder Tiger® - Raptor 30 Complete Kit - 30
  • Thunder Tiger® - Raptor 50 SE - 50
  • Thunder Tiger® - Raptor 50 SE Complete Kit - 50
  • Thunder Tiger® - Raptor 50 Titan - Bearing 4-8-3mm
  • Thunder Tiger® - Raptor 50 V2 - Double Shielded Bearing 4-8-3mm
  • Thunder Tiger® - Raptor 60 V2 - Double Shielded Bearing 4-8-3mm
  • Thunder Tiger® - Raptor 90 SE - Double Shielded Bearing 4-8-3mm
  • XTM Racing - X-Cellerator EP RTR - Bearing 4-8-3mm

Cross References

  • Similar Part MR84A-ZZ-ECO
  • MR84A-Z-ECO
  • MR84AZECO
  • MR84A Basic Size Ref
