NAST45ZZUU - Datasheet

MBA

Category Information

Rollers - Track - With Inner Race

With Inner Race Track Rollers. This is the main category in this series

    Product Data

    • ID (d) : 45.00 mm
      (Equiv. 1.772 in.)
    • OD (D) 85.00 mm
      (Equiv. 3.346 in.)
    • Width (C) 25.80 mm
      (Equiv. 1.016 in.)
    • Inner Ring Width (B) 26.00 mm
    • OD Type Cylindrical
    • Dynamic Load Rating 3810.00 kgf
    • Static Load Rating 6770.00 kgf
    • Closures Shields with Seal
    • Material Steel
    Country of Origin: JP

    Product Compliance and Data

    Additional Resources

      Cross References

      • Nachi NAST-45-ZZUU
      • IKO NAST45-ZZUU
      • NAST45ZZUU
