Miniature Bearings Australia
COL-04000-060-60-AL - Datasheet
MBA
Category Information
Collars - Shaft - Standard - AluminiumAluminium Standard Shaft Collars. Standard one piece aluminium shaft collar with set screw
- Static torque and axial load are for reference only using steel cup point grub screw on soft steel shaft
Product Data
- Suitable Shaft Size (d)
:
40.000
mm
+ 0.10 / - 0.00
(Equiv. 1.575 in.) - Outside Diameter (D)
60.00
mm
+ 0.00 / - 0.10
(Equiv. 2.362 in.) - Overall Width (S)
18.0
mm
+ 0.00 / - 0.12
(Equiv. 0.709 in.) - Material Aluminium
Product Compliance and Data
Additional Resources
Cross References
- Misumi SC4018A
