Miniature Bearings Australia
NAST35ZZUUR - Datasheet
MBA
Category Information
Rollers - Track - With Inner RaceWith Inner Race Track Rollers. This is the main category in this series
Product Data
- ID (d)
:
35.00
mm
(Equiv. 1.378 in.) - OD (D)
72.00
mm
(Equiv. 2.835 in.) - Width (C)
24.80
mm
(Equiv. 0.976 in.) - Inner Ring Width (B) 25.00 mm
- OD Type Radius (500mm)
- Dynamic Load Rating 3300.00 kgf
- Static Load Rating 5170.00 kgf
- Closures Shields with Seal
- Material Steel
Product Compliance and Data
Additional Resources
Cross References
- Nachi NAST-35-ZZUUR
- IKO NAST35-ZZUUR
- NAST35ZZUUR
