CP-095-HUB-G-PR-30L - Datasheet
MBA
Category Information
Couplings - Geargrip - Precision HubsPrecision Hubs Geargrip Couplings. Match with sleeves from sleeves category
- An expanded range may be available on special order. Please enquire.
Product Data
- Bore
:
9.525
mm
(Equiv. 0.375 in.) - Sleeve OD For Long Series 40.4mm with OD 28.95 or 30.48 mm
- Overall Length Assembled When Complete 57.15 mm
- Description Single Hub Only
- Hub Protrusion Assembled 8.382 mm
- Number of Teeth 8 Nr.
- Hub Length 27.686 mm
- Hub Diameter (C) 29.210 mm
Product Compliance and Data
Additional Resources
Cross References
- GU-2302
- GU2302
