LCP-0250-035-040-FJ - Datasheet

MBA

Category Information

Linear - Sliding Bearings - Frelon J Lined - Closed - Standard

Standard Closed Frelon J Lined Sliding Bearings Linear. Self lubricating. Eliminates galling and shaft damage. Dampens vibration for quiet smooth operation. High load capacity. Absorbs shock loads. Maintenance free. Chemically inert. Temp range -240 Deg C to +260 Deg C

Frelon J = 10000 PV
Dry Running Max Surface Speed Frelon J = 0.7 mtrs / sec (140 ft / min).
With Lubrication Max Surface Speed Frelon J = 2 mtrs / sec (400 ft / min)
Standard type has slightly larger running clearances.

Product Data

Deleted Item. Available while stocks last.

Please contact us first if you wish to use this item in a new design so we can check whether production can be resumed.

Nominal Shaft Size (T) : 25.000 mm
(Equiv. 0.984 in.)
Nom. Outer Diameter (D) 35.000 mm
(Equiv. 1.378 in.)
Overall Length (L) 40.000 mm
(Equiv. 1.575 in.)
Max. Load 10295 N
Series Standard
Type Closed
O-Ring To Suit OR-030.50x2.50-NE70
Retaining Ring To Suit N/A
Material Frelon J Lined

Country of Origin: US

Product Compliance and Data

Additional Resources

Cross References

S99BSCM25F035040
