Miniature Bearings Australia
COL-02500-038-38-AL - Datasheet
MBA
Category Information
Collars - Shaft - Standard - AluminiumAluminium Standard Shaft Collars. Standard one piece aluminium shaft collar with set screw
- Static torque and axial load are for reference only using steel cup point grub screw on soft steel shaft
Product Data
- Suitable Shaft Size (d)
:
25.000
mm
+ 0.10 / - 0.00
(Equiv. 0.984 in.) - Outside Diameter (D)
38.00
mm
+ 0.00 / - 0.10
(Equiv. 1.496 in.) - Overall Width (S)
12.0
mm
+ 0.00 / - 0.12
(Equiv. 0.472 in.) - Material Aluminium
Product Compliance and Data
Additional Resources
Cross References
- Misumi SC2512A
