MAG-BK-02-06-025-C - Datasheet
MBA
Category Information
Magnets - Blocks CeramicBlocks Ceramic Magnets. Low cost, light weight, high energy material
- Non conductive hard brittle material
- Performs best at temperatures below 249 oC
- Can be cut with a diamond wheel
- Difficult to grind and can't be machined or drilled by normal methods
- Tolerance 0.13mm on all dimensions
Product Data
- Pull : 2.23 kg
- Thickness
6.35
mm
(Equiv. 0.25 in.) - Width
25.4
mm
(Equiv. 1 in.) - Length 50.8 mm
- Weight 0.04 kg
Product Compliance and Data
Additional Resources
Cross References
- IM468
- IM-468
