SCT0218-006-PLH-P-PH-CZ - Datasheet
MBA
Category Information
Screws - Self Tapping - Hard or Soft Plastics - Pan HeadPan Head Hard or Soft Plastics Self Tapping Screws. Tri-Lobe Course Thread Plastic Threading Screws
- Thread cutting screws for plastics
- Be sure to select correct screw for hard or soft plastic threadcutting
Product Data
- Approx Diameter : 2.18mm (2 Gauge) mm
- Thread Length (l) 6.4 mm
- Gauge 2
- Drive Type Phillips
- Head Diameter (dk) 4.24 mm
- Type Course Threadcutting For Hard or Soft Plastics
- Material Zinc Plated Steel
Product Compliance and Data
Additional Resources
- Screws & Nuts Catalogue
- Shoulder Screws Catalogue
- Socket Set (Grub) Screws Catalogue
- Thumb Screws & Thumb Nuts Catalogue
- Thread Size Chart - Combined Imperial & Metric
Cross References
- 90380A005
- MicroFast® TCPP0204
