P-020G-013-030FH-AL-G-030 - Datasheet
MBA
Category Information
Pulleys - Metric Timing - 2.000mm Pitch - GT - 3mm Wide3mm Wide GT 2.000mm Pitch Metric Timing Pulleys. Timing Pulleys to suit GT 2mm Pitch Timing Belts.Use with GT2 or GT3 type belts.
- Timing pulleys combined with timing belts, provide power transmission without slippage.
- Timing pulleys are toothed pulleys used with timing belts to synchronize the movement of different mechanical components, ensuring precise timing and coordination.
- Some uses for timing pulleys include 3D printers, CNC machines, robotics and automation components, textile machinery, office equipment such as scanners and copiers, and medical devices requiring precise movement control.
- Aluminium Alloy
- Finished Bores with Set Screws
Product Data
Deleted Item. Available while stocks last.
Please contact us first if you wish to use this item in a new design so we can check whether production can be resumed.
- Number of Teeth : 13
- Max Belt Width
3.00
mm
(Equiv. 0.118 in.) - Bore (d)
3.000
mm
(Equiv. 0.118 in.) - Bore Type Finished
- Locking Type Set Screw
- Type 1
- Pitch Dia. (PD) 8.27 mm
- Flange Diameter (FD) 12.8 mm
- Overall Length 11.1 mm
- Hub Diameter (HD) 12.8
- Material Aluminium
Product Compliance and Data
Additional Resources
Cross References
- A6A51M013DF0303
