6000-2RS - Datasheet

MBA

Category Information

Bearings - Single Row Ball - Unflanged - Precision - Chrome Steel

Chrome Steel Precision Unflanged Single Row Ball Bearings. Chrome steel radial ball bearings.

Single row radial ball bearings are arguably the most common, widely used type of bearing. They consist of an inner ring, an outer ring, a set of balls, and a cage that retains the balls in a circular path.
Single row radial ball bearings are commonly used in a wide range of applications, including electric motors, fans, pumps, gearboxes, agricultural equipment, appliances, and automotive components.
They are versatile, cost-effective bearings that provide reliable support for radial loads and some axial loads in one direction. An expanded range may be available on special order. Please enquire.
Standard single row radial ball bearings.

Product Data

ID (d) : 10.000 mm _{+ 0.000 / - 0.0075}
(Equiv. 0.394 in.)
OD (D) 26.000 mm _{+ 0.000 / - 0.010}
(Equiv. 1.024 in.)
Width (B) 8.000 mm _{+ 0.000 / - 0.125}
(Equiv. 0.315 in.)
Precision Grade Abec 1
Closure Type 2RS
Bearing Type Radial
Material Chrome Steel SAE 52100

Lubrication Type Grease
Lubrication Name Standard Unspecified
Basic Part 6000
Limiting Speed 21080
Cage Type Standard
Static Load Rating KGf 200
Dynamic Load Rating KGf 463
Radii 0.30 mm
Inner Shoulder (UI) 12.90mm
Outer Shoulder (UO) 22.40 mm
Number of Balls 7
Clearance CN (2 to 13)
Precision Grade Abec 1
Closure Type 2RS
Max Temperature 80 Deg. C

Country of Origin: JP

Product Compliance and Data

Additional Resources

Applications & Uses

Power Tool Parts
RC Nitro Engine Parts
Makita - 1900B Planer - Bearing 10-26-8mm
ASP - 108 All Models - Bearing 10-26-8mm
ASP - 91 Old - Front Bearing For 10-26-8mm
CMB - 21 - Bearing 10-26-8mm
CMB - 67 All Models - Bearing 10-26-8mm
CMB - CAM - 65 - Bearing 10-26-8mm
CMB - CAM Marine - 80 - Bearing 10-26-8mm
CMB - H Racing - Green Head - 65 - Bearing 10-26-8mm
Mac - 12 All Models - Bearing 10-26-8mm
Mac - 45 All Models - Bearing 10-26-8mm
Magnum Power - 120 4 Stroke - 21 - Bearing 10-26-8mm
Magnum Power - XL - 108 - Bearing 10-26-8mm
Magnum Power - XL - 46 - Bearing 10-26-8mm
Magnum Power - XL 4C - 30 - Bearing 10-26-8mm
MDS - FS Pro - 61 - Bearing 10-26-8mm
Moki - 1.8 All Models - Bearing 10-26-8mm
Moki - 51 All Models - Bearing 10-26-8mm
MVVS - Glow Engine - 40 - Bearing 10-26-8mm
OS - FR5 5Cylinder 4C - 60 - Bearing 10-26-8mm
OS - FS RC Surpass 4C - 40 - Bearing 10-26-8mm
OS - FS Supercharge - 120 - Bearing 10-26-8mm
OS - FS Supercharge - 61 - Bearing 10-26-8mm
OS - FS-120 II Surpass - 91 - Bearing 10-26-8mm
OS - FS-120 Non Surpass - 91 - Bearing 10-26-8mm
OS - FS-120 Surpass III With Pump - Bearing 10-26-8mm
OS - FS-120E Surpass - Bearing 10-26-8mm
OS - FSR - 50 - Bearing 10-26-8mm
OS - FSR - 60 - Bearing 10-26-8mm
OS - FSR RC LS - 61 - Bearing 10-26-8mm
OS - FSR RC W-Muffler - 50 - Bearing 10-26-8mm
OS - FSR Ring RN - 108 - Bearing 10-26-8mm
OS - FSR-M ABC RC - 61 - Bearing 10-26-8mm
OS - RX - 21 - Bearing 10-26-8mm
OS - RX-2 Cycle - 15 - Bearing 10-26-8mm
OS - RX-EFI - 21 - Bearing 10-26-8mm
OS - RX-FI - 140 - Bearing 10-26-8mm
RCV - 120SP - 15 - Bearing 10-26-8mm
RCV - 58 CD - 15 - Bearing 10-26-8mm
Saito - 160 - 120 - Bearing 10-26-8mm
Saito - 35 All Models - Bearing 10-26-8mm
Saito - FA 125 - 90 - Front Bearing 10-26-8mm
Saito - FA 90 - Bearing 10-26-8mm
Saito - FA180 - 91 - Front Bearing 10-26-8mm
Saito - S Goldhead - 50 - Bearing 10-26-8mm
Thunder Tiger - Pro - 12 - Bearing 10-26-8mm
Thunder Tiger - RP - 61 - Bearing 10-26-8mm
Thunder Tiger - SF - 120 - Bearing 10-26-8mm
Webra - 40 All Models - Bearing 10-26-8mm
Webra - Speed - 61 - Bearing 10-26-8mm

Cross References

5972K81
Sealed 6000 / 8
Nachi 6000-2NSEC3
WIB 6000-2RSR
NTN 6000-2RU
NTN 6000LLB
NTN 6000LLU
WIB 6000-RSR
FAFNIR 9100PP
60002RU
6000DDU
60002NSEC3
60002RSR
6000VV
6000RSR
6000 Basic Size Ref
