SHM-1000-0200-0050-CRH - Datasheet
MBA
Category Information
Shim and Foil - SteelSteel Shim and Foil. Precision shim sheet selection. Includes cold rolled steel and hardened SK steel.
- Precision shim sheets allow you to fill small gaps and ensure precise fitting of components, preventing wear and tear, make very small adjustments to the alignment or spacing of parts in machinery and other assemblies.
- This product is meant for engineering applications not decorative applications. NOTE! Very thin sizes may experience some bending or indentations.
- Includes K&S Metals range and more
Product Data
- Thickness (t)
:
1.000
mm
+ 0.050 / - 0.050
(Equiv. 0.039 in.) - Width (w)
200.0
mm
+/- 0.3
(Equiv. 7.874 in.) - Length (l)
50.0
mm
+ 0.5 / - 0.5
(Equiv. 1.969 in.) - Pack Size Single Sheet
- Material Carbon Steel - Hardened 42-46 HRC
Product Compliance and Data
Additional Resources
Cross References
- Misumi TY50-200-10
- TY5020010
