Miniature Bearings Australia
BL-00060-SP-G25 - Datasheet
MBA
Category Information
Balls - Ceramic - Synthetic - SapphireSapphire Synthetic Ceramic Balls. Extreme hardness, wear resistance, non-corrosiveness and chemical inertness.
- Grades shown are AFBMA and ISO3290-1 which relates primarily to the ovality of the ball rather than the diametrical tolerance
- General balls offered for sale may be from different ball lots, so the diametrical tolerance shown, indicates a variance that might be encountered if balls of different gauges are mixed, unless a ball gauge is specified for the part.
- For diametrically critical applications, a special quote can be obtained for balls of a specified ball gauge.
- Tolerances available on request. Grades shown are AFBMA / ISO3290-1.
- Specific Gravity: 3.98. Grade 25.
- Extreme hardness, wear resistance, non-corrosiveness and chemical inertness.
- High mechanical strength.
- Transparent (refractive index 1.76).
Product Data
- Diameter (D)
:
0.599
mm
+/- 0.00254
(Equiv. 0.024 in.) - Material Synthetic Sapphire
- Precision AFBMA Grade 25
- Hardness 9 Mohs
- Properties Extreme hardness and wear resistance
- Colour Transparent
- Specific Gravity 3.98
- Ovality +/-0.000635
- Material Synthetic Sapphire
